Model
UV Lamp
Power
PXSCA75000
60w
rated voltage of 220-240V, 50Hz
Introduction
Congratulations on the purchase of your pondXpert filter. Once your filter is connected you can
look forward to many years of healthy pond water.
Your filter is pump fed so must be connected to a suitable pond pump in order to work correctly.
Ideally a solids-handling pump will be used as this will push dirty waste and debris into the filter.
PondXpert filters are carefully inspected and tested to ensure both safety and operating
performance. However, failure to follow the instructions and warnings in the manual may result
in product damage and/or serious injury. Be sure to read and save this manual for future
reference.
General safety Instructions
Read and observe all of the instructions before installing, connecting and operating.
Make sure the filter is securely and correctly installed before switching on.
SpinClean Auto 75 PRO
UV Biological Pond Filter
Dimensions
Dia x height
75 X 88 cm
Inlet /Outlet
Max Pond
Size
Vol. (Ltrs)
32/38/40/50mm
75000 (37500 koi)
Recomended
Flow Rate
20,000 LPH
Advertisement
Related Manuals for PondXpert SpinClean Auto 75 PRO
Summary of Contents for PondXpert SpinClean Auto 75 PRO
- Page 1 220-240V, 50Hz Introduction Congratulations on the purchase of your pondXpert filter. Once your filter is connected you can look forward to many years of healthy pond water. Your filter is pump fed so must be connected to a suitable pond pump in order to work correctly.
- Page 2 Children should be supervised to ensure that they do not play with the appliance. For safety reasons, servicing or repair of this item should only be carried out by PondXpert. Never hang or carry the pump by the power cord.
- Page 3 Exposed cable runs should be sensibly positioned, and protected if necessary by armoured conduit. A 10mA or 30mA Residual Current Circuit Breaker (RCD) MUST be fitted to the mains supply. Permanent installations to the mains supply (hard wiring) must comply with the regulations of the local electricity authority which may stipulate the use of metal or plastic conduit to protect the cable.If in any doubt about wiring to the mains supply contact a qualified electrician or your local electricity authority.The supply cable cannot be replaced.
- Page 4 PondXpert filters are pump-fed, external filters with an integral UVC unit. Your filter is supplied with a black hosetail. This should be screwed into the threaded filter inlet.
- Page 5 Exploded Diagram “Full Clean” / Switch Off & Strip Down Cleaning Procedure:...
- Page 6 The filter requires minimum maintenance. If your pond is very dirty, initially you may need to clean the filter every couple of days. When the filtering process kicks in your water will become clearer and there will be less debris to remove. The red domed indicator turns completely red when pressure builds inside the filter suggesting that cleaning is necessary.
- Page 7 The actual media is hidden inside the ‘second skin’ of the filter. To gain access you first need to lid the lid off the filter (this will remove the UV, cleaning motor and filter sponges). You should be now able to see the bio-media at the base of the unit. Remove Inner ‘Dirt Catcher’...
- Page 8 The glass surrounding your UV bulb is called the ‘Quartz Sleeve’ – this allows the UV rays to affect the algae inside the water but prevents the water gaining access to the UV electrics. Over time this quartz sleeve can become cloudy – often due to calcium deposits in hard water areas. If cloudy this will negatively affect the performance of the UV.
- Page 9 The UV bulb, quartz sleeve and foams are not guaranteed. If your pondXpert filter fails please take it back to the retail outlet from where it was purchased. You will be required to provide your receipt/proof of purchase. This does not affect your statutory rights.
