Summary of Contents for CTC Union SHRM03b

  • Page 1 SHRM03b SHDSL.bis ATM 4U, 19(23)” 15 Slot...
  • Page 2 URL: http://www.ctcu.com SHRM03b ATM Manual G.SHDSL.bis ATM Rack SHRM03b-CH ATM SHRM03b-ET100R SHRM03bA-ET100R Version 1.0 Jun 2009 Copyright © 2008~2009, CTC Union Technologies, Inc. All rights reserved. All specifications are suject to change without prior notice. SHRM03b ATM Manual V1.0...
  • Page 3 CTC Union Technologies makes no warranty, representation, or guarantee regarding the suitability of its products for any particular purpose, nor does CTC Union assume any liability arising out of the application or use of any product and specifically disclaims any and all liability, including without limitation any consequential or incidental damages.
  • Page 4: Table Of Contents

    Attaching the Mounting Brackets....................... 2 2.3.2 Mounting the chassis on a Rack......................2 2.3.3 AC power Connection ......................... 2 2.3.4 DC Power Connection ......................... 2 ........................ 2 EMOVAL EPLACEMENT 2.4.1 Installing a Line Card .......................... 2 SHRM03b ATM Manual V1.0...
  • Page 5 IP QoS ................................2 3.2.3 Status ..............................2 3.2.3.1 SHDSL.bis ................................ 2 3.2.3.2 LAN ................................. 2 3.2.3.3 WAN................................2 3.2.3.4 ROUTE................................2 3.2.3.5 INTERFACE ..............................2 3.2.3.6 IP QoS ................................2 3.2.3.7 STP .................................. 2 3.2.4 Administration............................ 2 SHRM03b ATM Manual V1.0...
  • Page 6 System information............................2 3.3.4.2 Configuration information ..........................2 3.3.4.3 Configuration with Script format ........................2 3.3.5 Write..............................2 3.3.6 Reboot ..............................2 3.3.7 Ping ..............................2 3.3.8 Administration............................ 2 3.3.8.1 User Profile ..............................2 3.3.8.2 Security ................................2 SHRM03b ATM Manual V1.0...
  • Page 7 PAT ................................ 2 3.3.11.10.3 DMZ ..............................2 3.3.11.11 IPQoS................................2 3.3.11.12 DHCP ................................2 3.3.11.13 DNS proxy..............................2 3.3.11.14 Host name ..............................2 3.3.11.15 Default................................ 2 APPENDIX..............................2 ............................. 2 ONSOLE ABLE ............................. 2 THERNET CABLE SHRM03b ATM Manual V1.0...
  • Page 8: Introduction

    The Appendix includes the pin assignments of special cables. General Description The SHRM03b-CH chassis is a 4U 19(23)" rack that supports dual power and 15 slots for hot swappable ET100R Bridge/Router Ethernet cards. The SHDTU03b-ET100R and SHDTU03bA-ET100R are G.SHDSL.bis 2-wire/ 4-wire ATM line card which comply with G.991.2 &...
  • Page 9: General Features

    High density and compact and 4U high Hot swapping of cards Up to 15 cards can be installed Redundant power supplies (optional) Optional SNMP network management system card(under development) Different power source option , AC or DC SHRM03b ATM Manual V1.0...
  • Page 10: General Specifications

    CBR (Constant bit rate) VBR-rt (Variable bit rate real-time) VBR-nrt (Variable bit rate non-real-time) AAL5 Encapsulation VC multiplexing and SNAP/LLC Ethernet over ATM (RFC 2684/1483) PPP over ATM (RFC 2364) Classical IP over ATM (RFC 1577) SHRM03b ATM Manual V1.0...
  • Page 11 DC input: -36V to -72V , 6A AC input: 100V to 240VAC , 2A Power Consumption Total 200W Maximum Interface Line card: 12W maximum Environmental Requirement Temperature: 0°C to 45°C (operation) -40°C to 70°C (storage) Relative Humidity: Up to 95%(without condensation) SHRM03b ATM Manual V1.0...
  • Page 12 4U, 19”, 18-slot chassis with one AC + DC power card SHRM03b-AD AC 100 ~ 240V, DC 36 ~ 72V power card SHRM03b-ET100R 2 wire (5.7Mbps) 2Ch Ethernet 10/100Base-TX ATM bridge/router card SHRM03bA-ET100R 4 wire (11.4Mbps) Ethernet 10/100Base-TX ATM bridge/router card SHRM03b ATM Manual V1.0...
  • Page 13: Application

    Application SHRM03b ATM Manual V1.0...
  • Page 14: Front Panel

    Each slot will have a number from 1 to 15 indicating the slot number location of the line card. From the front view of the chassis, the numbers go from left to right. 1.5.2 Line card 1.5.2.1 View of Front Panel on Line Card SHRM03b-ET100R SHRM03bA-ET100R 2-wire 2-channel 4-wire 1-channel SHRM03b ATM Manual V1.0...
  • Page 15: Led Indicators

    The front panel of each line card provides an RJ-45 connector for configuration, individually from each channel of each line cards. The terminal settings are 115200, 8 bit, no parity, 1 stop bit and no flow control. SHRM03b ATM Manual V1.0...
  • Page 16 SHRM03b-ET100R have two console connector for using on channel A and B individually. SHRM03b ATM Manual V1.0...
  • Page 17: Power Supply Module

    LEDs Active Description AC input is be used Blink AC input isn’t be used or no AC input DC input is be used Blink DC input isn’t be used or no DC input Power input failure SHRM03b ATM Manual V1.0...
  • Page 18: Rear Panel

    The rear panel provides all of the data connections for each line card. A total of 15 slots are available for SHDSL.bis ATM based Line Card. The following is a description of all the connectors for the line cards located on the rear panel. SHRM03b ATM Manual V1.0...
  • Page 19: Dsl Connector

    Ethernet connections for channel A (on upper side) and channel B (on below side). When using SHRM03bA-ET100R , only the upper side of RJ-45 connector can be used. 1.6.3 View of Rear Panel on Power Supply Module SHRM03b ATM Manual V1.0...
  • Page 20: Power Receptacle

    The circuit breakers provide over current protection for AC and DC inputs. They are resettable by pushing back to the closed position. 1.6.3.3 Mains Switch These mains switches control the input flow of AC and DC, depending on the input voltage type. SHRM03b ATM Manual V1.0...
  • Page 21: Terminal Block Connector

    Proper polarity must be observed for DC power connections or severe electrical damage may occur to the chassis. Always confirm the polarity with a voltage meter before inserting line cards or powering on the mains switches. SHRM03b ATM Manual V1.0...
  • Page 22: Installation

    The rack mount brackets that ship with the SHRM03b series chassis allow mounting in either 19" or 23" wide rack spaces. A total of four different mounting configurations are possible. Please see the chassis top view graphics below. SHRM03b ATM Manual V1.0...
  • Page 23: Attaching The Mounting Brackets

    (d) Do not install the chassis in an environment where the operation ambient temperature might exceed 40°C. Step 1. Insert the chassis into the 19-inch or 23-inch rack ensuring the rack-mounting holes on the chassis line up to the mounting hole on the rack. SHRM03b ATM Manual V1.0...
  • Page 24: Ac Power Connection

    “OFF” position and the DC power is OFF. NOTE: A qualified electrician must perform all connections to DC power and to safety grounds. All electrical wiring must comply with applicable local or national codes and practices. SHRM03b ATM Manual V1.0...
  • Page 25: Line Card Removal / Replacement

    Step 3. After you have the card partially out of the chassis, place one hand under the card to support it. Step 4. Slide the card completely out of the slot and place in an anti-static protective bag. SHRM03b ATM Manual V1.0...
  • Page 26: Operation

    User: admin Password: ***** If you haven’t set any user profile for line card before, enter the factory default user “admin” and password “admin” to login the device. 3.1.2 Telnet SHRM03b ATM Manual V1.0...
  • Page 27: Web Browser

    IP address for this device. Make sure your computer’s subnet mask is as same. And then press Enter. A user name and password prompt will appear. The default username and password is “root”. Click OK button and you will login this line card. SHRM03b ATM Manual V1.0...
  • Page 28 The factory default management IP and subnet mask are 192.168.0.1 and 255.255.255.0. If you haven’t any user profile for line card before, enter the factory default user name “root” and password “root” to login the device. SHRM03b ATM Manual V1.0...
  • Page 29: Configuration By Web Browser

    Click Basic for basic installation. 3.2.1.1 Bridge Mode Parameter Table: System mode Bridge SHDSL □CO side □CPE side IP address Subnet Mast Gateway Host Name WAN1 Encapsulation □VC-mux □LLC SHRM03b ATM Manual V1.0...
  • Page 30 SHDSL.bis line card working mode is CO. For “LAN to LAN” connection, one side must be CO and the other side must be CPE. Set up (a) LAN IP address , Subnet Mask, Gateway and Host Name (b) WAN1 VPI,VCI and Encapsulation LAN: SHRM03b ATM Manual V1.0...
  • Page 31 Click Next to review Review The screen will prompt the new configured parameters. Checking the parameters and Click Restart The line card will reboot with the new setting or Continue to configure another parameters. SHRM03b ATM Manual V1.0...
  • Page 32: Routing Mode

    DNS Server 1 DNS Server 2 DNS Server 3 Lease time Host Entries MAC : MAC : MAC : MAC : MAC : MAC : MAC : MAC : MAC : MAC : DHCP Relay IP address SHRM03b ATM Manual V1.0...
  • Page 33 Routing mode contains DHCP server, DHCP client, DHCP relay, Point-to-Point Protocol over ATM and Ethernet and IP over ATM and Ethernet over ATM. You have to clarify which Internet protocol is provided by ISP. Setup up system mode and SHDSL mode click ROUTE and CPE Side then press Next. SHRM03b ATM Manual V1.0...
  • Page 34 If the DHCP server is “Enable,” you have to setup the following parameters for processing it as DHCP server. The embedded DHCP server assigns network configuration information at most 253 users accessing the Internet in the same time. SHRM03b ATM Manual V1.0...
  • Page 35 00:03:79:0A:01:3F Press Next to setup WAN1 parameters. Some of the ISP provides DHCP server service by which the PC in LAN can access IP information automatically. To setup the DHCP client mode, follow the procedure SHRM03b ATM Manual V1.0...
  • Page 36 Set up the DHCP Server Press Next to setup Remote DHCP server parameter. If using DHCP relay service, there must set up the remote DHCP server IP address Enter DHCP server IP address in IP address field. Press Next SHRM03b ATM Manual V1.0...
  • Page 37 IP address when SHDSL.bis connection is established. On the other hand, you do not need to type the IP address of WAN1. Some of the ISP will provide fixed IP address over PPP. For fixed IP address: IP Type: Fixed IP Address: 192.168.1.1 SHRM03b ATM Manual V1.0...
  • Page 38 Set up : WAN1 VPI, VCI, Encap. and Protocol WAN: VPI: 0 VCI: 33 AAL5 Encap: LLC Protocol: IPoA , EoA , IPoA + NAT or EoA + NAT Click Next to setup the IP parameters. For more understanding about NAT, review NAT/DMZ chapter. SHRM03b ATM Manual V1.0...
  • Page 39 This is the line card subnet mask seen by external users on Internet. Your ISP will provide it to you. Gateway: 10.1.2.2 Your ISP will provide you the default gateway. DNS Server 1: 168.95.1.1 Your ISP will provide at least one DNS (Domain Name System) Server IP address. Click Next to review. SHRM03b ATM Manual V1.0...
  • Page 40 The screen will prompt the parameters that will be written in NVRAM. Check the parameters before writing in NVRAM. Press Restart to restart the line card working with new parameters or press Continue to setup another parameter. SHRM03b ATM Manual V1.0...
  • Page 41: Reference Diagram

    ISP's network and their customer's as if the networks were on the same physical LAN. Bridged connections do not use the IP protocol. EoA can also be configured to provide a routed connection with the ISP, which uses the IP protocol to exchange data. SHRM03b ATM Manual V1.0...
  • Page 42 Ethernet protocol or ATM protocol, which supports multiple users in a local area network. The PPP protocol information is encapsulated within an Ethernet frame or ATM frame. Bridge IP: 192.168.0.1 IP: 192.168.0.254 Netmask: 255.255.255.0 Gateway: 192.168.0.254 DSLAM VPI:0, VCI:32 IP: 192.168.0.2 Encapsulation: LLC Netmask: 255.255.255.0 Gateway: 192.168.0.254 SHRM03b ATM Manual V1.0...
  • Page 43: Advanced Setup

    Advanced setup contains SHDSL.bis, WAN, Bridge, VLAN, Ethernet, Route, NAT/DMZ, Virtual SERVER, FIREWALL and IP QoS parameters. 3.2.2.1 SHDSL.bis You can setup the Annex type, data rate and SNR margin for SHDSL.bis parameters in SHDSL.bis. Click SHDSL.bis Enter Parameters in SHDSL.bis SHRM03b ATM Manual V1.0...
  • Page 44: Annex Type

    It also has the Conexant M-pair standard used with connection to other ATM router/bridge Conexant chip set solution. Auto Fall Back Mode Two DSL pairs are working simultaneously. When one pair of both is disconnect, the other pair will keep working. Stanby Mode SHRM03b ATM Manual V1.0...
  • Page 45: Tcpam Type

    TCPAM16 ; 192Kbps ~ 2304Kbps (Nx64kbps, N=3~36) For 4-wire model (n*128kbps) You can setup the SHDSL.bis data rate in the multiple of 128kbps. The default data rate is 11392Kbps (n=89). For using Annex AF or BG SHRM03b ATM Manual V1.0...
  • Page 46: Snr Margin

    The screen will prompt the parameters that will be written in NVRAM. Check the parameters before writing in NVRAM. Press Restart to restart the line card working with new parameters or press continue to setup another parameter. SHRM03b ATM Manual V1.0...
  • Page 47: Wan

    The parameters in WAN Number 1 has been setup in Basic Setup. If you want to setup another PVC, you can configure in WAN 2 to WAN 8. Enter the parameters: Protocol: If WAN Protocol is PPPoA or PPPoE with dynamic IP, leave the default WAN IP Address and SHRM03b ATM Manual V1.0...
  • Page 48 This bandwidth is characterized by Peak Cell Rate (PCR). Based on the PCR of the CBR traffic, specific cell slots are assigned for the VC in the schedule table. The ATM always sends a signle cell during the CBR connection’s assigned cell slot. SHRM03b ATM Manual V1.0...
  • Page 49 The screen will prompt the parameters that will be written in NVRAM. Check the parameters before writing in NVRAM. Press Restart to restart the line card working with new parameters or press continue to setup another SHRM03b ATM Manual V1.0...
  • Page 50 SHRM03b ATM Manual V1.0...
  • Page 51: Bridge

    3.2.2.3 Bridge If you want to setup advanced filter function while line card is working in bridge mode, you can use BRIDGE menu to setup the filter function, blocking function. Click Bridge to setup. SHRM03b ATM Manual V1.0...
  • Page 52 The screen will prompt the parameters that will be written in NVRAM. Check the parameters before writing in NVRAM. Press Restart to restart the line card working with new parameters or press Continue to setup another parameter. SHRM03b ATM Manual V1.0...
  • Page 53: Vlan

    With VLAN, all broadcasts are confined to a specific broadcast domain. The IEEE 802.1Q defines the operation of VLAN bridges that permit the definition, operation, and administration of VLAN topologies within a bridged LAN infrastructure. SHRM03b ATM Manual V1.0...
  • Page 54: Q Tag-Based Vlan

    VLAN table to store them. Ports in the same VLAN group share the same frame broadcast domin thus increase network performance through reduced boardcast traffic. VLAN groups can be modified at any time by adding, SHRM03b ATM Manual V1.0...
  • Page 55: Port-Based Vlan

    As with other VLAN approaches, the packets forwarded using this method do not leak into other VLAN domains on the network. After a port has been assigned to a VLAN, the port cannot send to or receive from devices in another VLAN. SHRM03b ATM Manual V1.0...
  • Page 56 The default setting is all ports (LAN1 to LAN4 and WAN1 to WAN8) connected together which means all ports can communicate with each other. That is, there are no virtual LANs. The option is the most flexible but the least secure. SHRM03b ATM Manual V1.0...
  • Page 57: Stp

    Protocol costs change, the spanning-tree algorithm reconfigures the spanning-tree topology and reestablishes the link by activating the standby path. Spanning-Tree Protocol operation is transparent to end stations, which are unaware whether they are connected to a single LAN segment or a switched LAN of multiple segments. SHRM03b ATM Manual V1.0...
  • Page 58: Route

    The line card, using the RIP protocol, determines the network packets’ route based on the fewest number of hops between the source and the destination. The RIP protocol regularly broadcasts routing information to other devices on the network. Click Route to modify the routing information. SHRM03b ATM Manual V1.0...
  • Page 59 RIP exchange with other router. If set Enable, the router broadcasts the routing table of the router on the LAN and incoporates RIP broadcast by other routers into it’s routing table. If set silent, the router does SHRM03b ATM Manual V1.0...
  • Page 60 Poison Reserve is for the purpose of promptly broadcast or multicast the RIP while the route is changed. (ex shuting down one of the routers in routing table) Enable: the gateway will actively broadcast or multicast the information. SHRM03b ATM Manual V1.0...
  • Page 61 Disable: the gateway will not broadcast or multicast the information. After modifying the RIP parameters, press finish. The screen will prompt the modified parameter. Check the parameters and perss Restart to restart the line card or press Continue to setup another parameters. SHRM03b ATM Manual V1.0...
  • Page 62: Nat/Dmz

    In the event that an outside user penetrated the DMZ host’s security, the Web pages might be corrupted, but no other company information would be exposed. Press NAT/DMZ to setup the parameters. SHRM03b ATM Manual V1.0...
  • Page 63 If you want to enable the NAT/DMZ functions, click Enable. Enable the DMZ host Function is used the IP address assigned to the WAN for enabling DMZ function for the virtual IP address. SHRM03b ATM Manual V1.0...
  • Page 64: Multi-Dmz

    The screen will prompt the parameters that will be written in NVRAM. Check the parameters before writing in NVRAM. Press Restart to restart the line card working with new parameters or Continue to configure another parameter. SHRM03b ATM Manual V1.0...
  • Page 65: Virtual Server

    3.2.2.8 Virtual Server Click Virtual Server to configure the parameters. There have ten virtual server index form 1 to 10 can been set up. SHRM03b ATM Manual V1.0...
  • Page 66 SHRM03b ATM Manual V1.0...
  • Page 67: Ip Qos

    25, schedule always. 3.2.2.9 IP QoS IP QoS is a good function to decide which PCs can get the priorities to pass though line card once if the bandwidth is exhausted or fully saturated. SHRM03b ATM Manual V1.0...
  • Page 68 Click Enable at item Trigger IP QoS Service in General IP QoS Parameter, which will turn on this IP QoS function. SHRM03b ATM Manual V1.0...
  • Page 69 Precedence: type the session’s prioritized level you classify, “0” is lowest priority, “5” is highest priority. Click OK when all parameters are finish. You can modify or delete the policies by click Modify or Delete command SHRM03b ATM Manual V1.0...
  • Page 70 Click Finish can make a review for all IP QoS parameter To let the IP QoS configuration you have changed and want those take effect immediately, please click Restart button to reboot the system. To continue the setup procedure, please click Continue button. SHRM03b ATM Manual V1.0...
  • Page 71: Status

    IP routing table including Flags, Destination IP/Netmask.Gateway, Interface and Portname. INTERFACE LAN and WAN statistics information. FIREWALL Current DoS protection status and dropped packets statistics. IP QoS IP QoS statistics on LAN interface STP information include Bridge parameter and Ports Parameter SHRM03b ATM Manual V1.0...
  • Page 72: Shdsl.bis

    SHRM03b-ET100R It the line card is 2-wire model ( ), no any channel B information you can see. Click Clear CRC Error can clear the CRC error count. SHRM03b ATM Manual V1.0...
  • Page 73: Lan

    3.2.3.2 This information shows the LAN interface status and DHCP client table. SHRM03b ATM Manual V1.0...
  • Page 74: Wan

    3.2.3.3 This information shows all eight WAN interface. SHRM03b ATM Manual V1.0...
  • Page 75: Route

    3.2.3.4 ROUTE This information shows the IP routing table. SHRM03b ATM Manual V1.0...
  • Page 76: Interface

    3.2.3.5 INTERFACE This table shows the interface statistics. SHRM03b ATM Manual V1.0...
  • Page 77: Ip Qos

    3.2.3.6 IP QoS This information shows IP QoS statistics. SHRM03b ATM Manual V1.0...
  • Page 78: Stp

    MAC address of the switch. The high order two-byte (unsigned 16-bit integer) field is the bridge priority number. Designated Root ID: The unique Bridge Identifier of the Bridge assumed to be the Root, this parameter is used as the value of the Root Identifier parameter in all CBPDUs transmitted by the Bridge. SHRM03b ATM Manual V1.0...
  • Page 79 Forwarding: When a port receives or sends data. In other words, this is operating normally. Disabled: This is when the network administrator has disabled the port. Blocking: this means the port was blocked to stop a looping condition. SHRM03b ATM Manual V1.0...
  • Page 80: Administration

    For greater security, change the Supervisor ID and password for the line card. If you don’t set them, all users on your network can be able to access the gateway using the default IP and Password root. SHRM03b ATM Manual V1.0...
  • Page 81 On trust host list, configured 0.0.0.0 will allow all hosts on Internet or LAN to access the line card. Leaving blank of trust host list will cause blocking all PC from WAN to access the line card. On the other SHRM03b ATM Manual V1.0...
  • Page 82 Click Finish to finish the setting. The browser will prompt the all configured parameters and check it before writing into NVRAM. Press Restart to restart the gateway working with the new parameters and press Continue to setup other parameters. SHRM03b ATM Manual V1.0...
  • Page 83: Snmp

    SNMP security. This line card support both MIB I and MIB II. Click SNMP to configure the parameters. 3.2.4.2.1 Community pool Press Modify to modify the community pool. You can setup the access authority. SHRM03b ATM Manual V1.0...
  • Page 84: Trap Host Pool

    Version: select version for trap host. (Version 1 is for SNMPv1; Version 2 for SNMPv2). IP Address: type the trap host IP address Community: type the community password. The community is setup in community pool. Press OK to finish the setup. SHRM03b ATM Manual V1.0...
  • Page 85 The browser will prompt the configured parameters and check it before writing into NVRAM. Press Restart to restart the gateway working with the new parameters and press Continue to setup other parameters. SHRM03b ATM Manual V1.0...
  • Page 86: Time Sync

    Sync with PC Synchronization with PC SNTP v4.0. Simple Network Time Protocol with Version 4 3.2.4.3.1 Synchronization with PC For synchronization with PC, select Sync with PC. The line card will synchronize the time with the connecting PC. SHRM03b ATM Manual V1.0...
  • Page 87 Update Period: How many times the line card can resynchronize to time server. The unit is second. Press Finish to finish the setup. The browser will prompt the configured parameters and check it before writing into NVRAM. SHRM03b ATM Manual V1.0...
  • Page 88: Utility

    Show the system information Load the factory default configuration, restore configuration and backup CONFIG TOOL configuration UPGRADE Upgrade the firmware Logout the system LOGOUT RESTART Restart the line card 3.2.5.1 System Info Click System Info for review the information. SHRM03b ATM Manual V1.0...
  • Page 89 Host Name: This is the system name you enter in BASIC Setup. It is for identification purposes. System Time: This field display your modem’s present date and time. System Up Time: This is the total time on the modem has been on. SHRM03b ATM Manual V1.0...
  • Page 90: Config Tool

    Load Factory Default: It will load the factory default parameters to the line card. Note: This action will change all of the settings to factory default value. On the other hand, you will lose all the existing configured parameters. 3.2.5.2.2 Restore Configuration SHRM03b ATM Manual V1.0...
  • Page 91: Backup Configuration

    Backup Configuration and then press Finish. Browse the place of backup file name or put the name. Then press OK. The line card will automatically backup the configuration. If you don’t put the file name, the system will use the default: config1.log SHRM03b ATM Manual V1.0...
  • Page 92: Upgrade

    You can upgrade the gateway using the upgrade function. Press Upgrade in UTILITY. Select the firmware file name by click Browse on your PC or NB and press OK button to upgrade. The system will reboot automatically after finish the firmware upgrade operation. SHRM03b ATM Manual V1.0...
  • Page 93: Logout

    To logout the line card, press LOGOUT in UTILITY. For logout system and close window, click the LOGOUT in UTILITY When click the Yes button, the line card will logout and browser window will be closed. SHRM03b ATM Manual V1.0...
  • Page 94: Restart

    When the restart button been clicked, the line card will restarting and the browser session will be disconnected. This may appear as if your browser session is hung up. After the line card restarts, you may either click the browser’s reload button or close the browser and re-open it later. SHRM03b ATM Manual V1.0...
  • Page 95: Configuration By Serial Console And Telnet

    For example, to show the system information, just logon to the line card, move down the cursor by pressing key K twice and select “show” command by key L, you shall see a submenu and select “system” command in this submenu, then the system will show you the general information. SHRM03b ATM Manual V1.0...
  • Page 96: Window Structure

    3.3.1.3 Menu Driven Interface Commands Before changing the configuration, familiarize yourself with the operations list in the following table. The operation list will be shown on the bottom field of the window. SHRM03b ATM Manual V1.0...
  • Page 97: Main Menu Before Enable

    Modify command privilege status Show running system status show View system configuration ping Packet internet groper command exit Quit system ------------------------------------------------------------------------ If you need setup and manage the line card, you must set enable command before SHRM03b ATM Manual V1.0...
  • Page 98: Enable

    Modify command privilege. When you login via serial console or Telnet, the line card defaults to a program execution (read-only) privileges to you. To change the configuration and write changes to nonvolatile RAM (NVRAM), you must SHRM03b ATM Manual V1.0...
  • Page 99: Status

    “reboot” command, or all of your changes will not take effect. ping Internet ping command. admin You can setup management features in this command. utility Upgrade software and backup and restore configuration are working via “utility” command. exit Quit system SHRM03b ATM Manual V1.0...
  • Page 100: Shdsl.bis

    CRC Error Count SHDSL Remote Side Status Channel Current SNR Margin : Attenuation CRC Error Count ----------------------------------------------------------------------------- Show SHDSL.bis status includes the Mode, Line Rate, Current SNR Margin, Attenuation and CRC error count on both side. SHRM03b ATM Manual V1.0...
  • Page 101: Wan

    Move cursor “ >> “ to Route and press enter. ------------------------------------------------------------------------ Monitoring Window... Flag Destination Netmask Gateway Interface Portname ---- ------------------------------------------------ ----------- ------- 192.168.0.0/ 255.255.255.0/ directly 192.168.0.1 127.0.0.1/255.255.255.255/ directly 127.0.0.1 Loopback ------------------------------------------------------------------------ You can view the routing table on here. SHRM03b ATM Manual V1.0...
  • Page 102: Interface

    Monitoring Window... <Current IP QoS Statistics - LAN Interface> Preced. InBytes InPackets OutBytes OutPackets OutDropByts OutDropPkts ------- ---------- ---------- ---------- ---------- ----------- ----------- ----------------------------------------------------------------------------- You can view current IP QoS statistics for six produces per ports. SHRM03b ATM Manual V1.0...
  • Page 103: Stp

    Forwarding - A port receiving and sending data, normal operation. STP still monitors incoming BPDUs that would indicate it should return to the blocking state to prevent a loop. Disabled - Not strictly part of STP, a network administrator can manually disable a port SHRM03b ATM Manual V1.0...
  • Page 104: Show

    Move cursor to “ >> “ to config and press enter. You can view all setting using table format. 3.3.4.3 Configuration with Script format Move cursor to “ >> “ to script and press enter. You can view all setting using script format. SHRM03b ATM Manual V1.0...
  • Page 105: Write

    To reboot the line card, please use “reboot” command. Move cursor to “ >> “ to reboot and press enter. ---------------------------------------------------------------------- Command: reboot <CR> Message: Please input the following information. Do you want to reboot? (y/n): y ---------------------------------------------------------------------- Press “y” to confirm the reboot operation. SHRM03b ATM Manual V1.0...
  • Page 106: Ping

    Default: It will send 4 packets only 1~65534: Set the number of ping request packets from 1 to 65534 -t : It will continuous until you key Ctrl+C to stop Data Size: From 1 to 1999 SHRM03b ATM Manual V1.0...
  • Page 107: Administration

    Move the cursor to Attrib to change the UI mode on this profile Move the cursor to Profile and press enter, you can change the username and their password on this profile. The screen will prompt as follow: SHRM03b ATM Manual V1.0...
  • Page 108 Finally, you can use list command to check the listing of five profiles including on user name and their UI mode. The screen will prompt as follow: ------------------------------------------------------------------------ Legal Access User Profile User Name UI Mode ---- ------------------ ----------- test Menu test-1 Menu test-2 Command test-3 Command superman Menu ------------------------------------------------------------------------ SHRM03b ATM Manual V1.0...
  • Page 109: Security

    0.0.0.0. It means that there is no restriction of IP to access the line card via telnet. Move the cursor to list and press enter, you can view full listing on security profile including the Telnet listing TCP port and 16 host IP address. SHRM03b ATM Manual V1.0...
  • Page 110 ---------------------------------------------------------------------- The screen will prompt as follow: >> edit Edit trap host parameter list Show trap configuration Move the cursor to edit and press enter, you can setup the following: Version : Disable, 1 or 2 SHRM03b ATM Manual V1.0...
  • Page 111: Supervisor Password And Id

    Input old Supervisor password: **** Input new Supervisor password: ******** Re-type Supervisor password: ******** ---------------------------------------------------------------------- ---------------------------------------------------------------------- Command: admin id <pass_conf> Message: Please input the following information. Legal user name (Enter for default) <root> : test ---------------------------------------------------------------------- SHRM03b ATM Manual V1.0...
  • Page 112 Time server address(Enter for default) <ntp-2.vt.edu> : ntp-2.vt.edu ---------------------------------------------------------------------- You can configure three time servers in this system with time_server1, time_server2 and time_server3. The default time servers are the following: time_server1 : ntp-2.vt.edu time_server2 : ntp.drydog.com SHRM03b ATM Manual V1.0...
  • Page 113 Time Synchronization Parameters Method : SNTP v4.0 Service : Enable Time Server 1 : ntp-2.vt.edu Time Server 2 : ntp.drydog.com Time Server 3 : ntp1.cs.wisc.edu Update Period : 3600 secs GMT Time Zone Offset : 8 hours ---------------------------------------------------------------------- SHRM03b ATM Manual V1.0...
  • Page 114 Type TFTP server IP address and backup filename of system configuration.. 3.3.9.3 Restore Move the cursor “ >> “ to restore and press enter. ------------------------------------------------------------------------ Command: utility restore <ip> <file> Message: Please input the following information. TFTP server IP address (ENTER for default) <192.168.0.2>: 192.168.0.150 SHRM03b ATM Manual V1.0...
  • Page 115 If you want to exit the system without saving, use exit command to quit system. ------------------------------------------------------------------------ Command: exit <CR> Message: Please input the following information. Do you want to disconnect? (y/n): ------------------------------------------------------------------------ Press “y” to confirm the exit operation. SHRM03b ATM Manual V1.0...
  • Page 116 You can setup the data rate by the multiple of 64Kbps where n is from 3 to 89. If the line card is 4 wire models (5120B) and doesn’t use on 2-wire mode, the line rate will double from SHRM03b ATM Manual V1.0...
  • Page 117 WAN interface configuration There are four types of protocols, IPoA, EoA, PPPoA and PPPoE, which you can setup. For dynamic IP of PPPoA and PPPoE, you do not need to setup IP address and subnet mask. SHRM03b ATM Manual V1.0...
  • Page 118 Most of the ISP use dynamic IP for PPP connection but some of the ISP use static IP. You can configure the IP type: Dynamic, Fixed and Unnumbered. The setting is via ip_type command. You can review the WAN interface configuration via list command. SHRM03b ATM Manual V1.0...
  • Page 119 Configure WAN3 interface bridging type wan4_port Configure WAN4 interface bridging type wan5_port Configure WAN5 interface bridging type wan6_port Configure WAN6 interface bridging type wan7_port Configure WAN7 interface bridging type wan8_port Configure WAN8 interface bridging type SHRM03b ATM Manual V1.0...
  • Page 120 4MSBs and 8MSB represents LAN ports and WAN port, respectively. For example: the above setting means that the VID 20 member port includes LAN1, LAN2 and WAN. The member ports are tagged members. Use PVID command to change the member port to untagged members SHRM03b ATM Manual V1.0...
  • Page 121 You can setup the routing parameters in route command. If the line card is configured as a bridge mode, you don’t need to setup the route parameters. Move the cursor “ >> “ to route and press enter. >> static Configure static routing table Configure RIP tool SHRM03b ATM Manual V1.0...
  • Page 122 Command: setup route rip wan <1~8> <more...> Message: Please input the following information. Active interface number <1~8>: 1 ---------------------------------------------------------------------- The screen will prompt as follow: >> attrib Operation, authentication and Poison reverse mode version RIP protocol version authe Authentication code SHRM03b ATM Manual V1.0...
  • Page 123 Virtual IP address pool global Global IP address pool Fixed Fixed IP address mapping The virtual menu contains range of virtual IP address, delete virtual IP address, and show virtual IP address. >> range Edit virtual IP address pool SHRM03b ATM Manual V1.0...
  • Page 124 You can create up to 10 fixed NAT mapping entry via range command. ---------------------------------------------------------------------- Command: setup ip_share nat fixed modify <1~1o> <ip> <ip> Message: Please input the following information. Fixed NAT mapping entry number <1~10>: 1 Local address: 192.168.0.250 SHRM03b ATM Manual V1.0...
  • Page 125 Message: Please input the following information. Virtual server entry number <1~10>: 1 ---------------------------------------------------------------------- After key in enter, the screen will prompt as below. >> interface Active interface port TCP/UDP port number server Host IP address and port number SHRM03b ATM Manual V1.0...
  • Page 126 After enabling the DMZ, shift the cursor to address and press enter. ---------------------------------------------------------------------- Command: setup ip_share dmz address <ip> <1~10> Message: Please input the following information. Virtual IP address: 192.168.0.251 Active interface number (Enter for default) <1>: 1 ---------------------------------------------------------------------- SHRM03b ATM Manual V1.0...
  • Page 127 Protocol: Identify the transportation layer protocol type you want to prioritize: TCP or UDP. The default is ANY. ----------------------------------------------------------------------------------------------------------------------------------- Command: setup ip_qos add protocol <ANY|TCP|UDP> Message: Please input the following information. Protocol (TAB Select) : ------------------------------------------------------------------------------------------------------------------------------------ SHRM03b ATM Manual V1.0...
  • Page 128 Precedence: Type the session’s prioritized level you classify, “0” is lowest priority, “5” is highest priority. ------------------------------------------------------------------------------------------------------------------------------------ Command: setup ip_qos add precedence <0~5> Message: Please input the following information. Precedence value (ENTER for default) : ------------------------------------------------------------------------------------------------------------------------------------ SHRM03b ATM Manual V1.0...
  • Page 129 Set up the IP address of name server #2 Name server 3 Set up the IP address of name server #3 Fixed Host IP Address list are setup via fixed command. >> add Add a fixed host entry delete Delete a fixed host entry SHRM03b ATM Manual V1.0...
  • Page 130: Dns Proxy

    Some of the ISP requires the Host Name as identification. You may check with ISP to see if your Internet service has been configured with a host name. In most cases, this field can be ignored. SHRM03b ATM Manual V1.0...
  • Page 131 If you want to restore factory default, move the cursor “ >> “ to default and then press enter. ---------------------------------------------------------------------- Command: setup default <name> Message: Please input the following information. Are you sure? (Y/N): y ---------------------------------------------------------------------- Press “y” to confirm the restore factory setting operation. SHRM03b ATM Manual V1.0...
  • Page 132: Console Cable

    4 Appendix Console Cable The front view of RJ-45 console cable socket on front panel: The wire connection of console cable DB-9(Female) to RJ-45: DB9 (Female) RJ-45 The signal direction of console cable: SHRM03b ATM Manual V1.0...
  • Page 133 The pin assignment of RJ-45 modular jack on the console cable: Pin Number Abbrev. Description Figure DCE ready Received Line Signal Detector DTE ready Signal Ground Received Data Front View Transmitted Data Clear to Send Top View Request to Send SHRM03b ATM Manual V1.0...
  • Page 134: Ethernet Cable

    The front view of RJ-45 Ethernet cable socket on rear panel: The pin out of RJ-45 Ethernet Connector: Pin number Signal Name Transmit Data + Transmit Data - Receive Date + Not used Not used Receive Date - Not used Not used SHRM03b ATM Manual V1.0...
  • Page 135 SHRM03b ATM Manual V1.0...
