Summary of Contents for Kyocera MITA PF-35

  • Page 1 SERVICE MANUAL Published in Feb.’02 845CY111 Revision 1...
  • Page 2 CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. CAUTION Double-pole/neutral fusing.

  • Page 3: Safety Precautions

    Safety precautions This booklet provides safety warnings and precautions for our service personnel to ensure the safety of their customers, their machines as well as themselves during maintenance activities. Service personnel are advised to read this booklet carefully to familiarize themselves with the warnings and precautions described here before engaging in maintenance activities.

  • Page 4: Safety Warnings And Precautions

    Safety warnings and precautions Various symbols are used to protect our service personnel and customers from physical danger and to prevent damage to their property. These symbols are described below: DANGER: High risk of serious bodily injury or death may result from insufficient attention to or incorrect compliance with warning messages using this symbol.

  • Page 5: Installation Precautions

    1. Installation Precautions WARNING • Do not use a power supply with a voltage other than that specified. Avoid multiple connections to one outlet: they may cause fire or electric shock. When using an extension cable, always check that it is adequate for the rated current..................... •...
  • Page 6 2. Precautions for Maintenance WARNING • Always remove the power plug from the wall outlet before starting machine disassembly....• Always follow the procedures for maintenance described in the service manual and other related brochures............................• Under no circumstances attempt to bypass or disable safety features including safety mechanisms and protective circuits.
  • Page 7 • Do not pull on the AC power cord or connector wires on high-voltage components when removing them; always hold the plug itself....................... • Do not route the power cable where it may be stood on or trapped. If necessary, protect it with a cable cover or other appropriate item.
  • Page 8 General Information Chapter 1...

  • Page 9: Table Of Contents

    Chapter 1 Contents 1-1 General .............................. 1-3 1-2 Product description ......................... 1-4 1-2-1 Unpacking ............................1-5 1-2-2 Caster kit ............................1-5 1-2-3 Installing the paper feeder ......................1-6 (1) Installing the paper feeder to the copier ..................... 1-6 (2) Installing the paper feeder to the printer ................... 1-10 (3) Place the paper size indicator plate ....................

  • Page 10: General

    5CY/3B7 1-1 General This chapter explains basic information and precautions to be observed when repairing, maintaining and inspecting the paper feeder. Topics covered in this chapter are: • Product description • Precautions • Specifications...

  • Page 11: Product Description

    5CY/3B7 1-2 Product description The paper feeder is for the copier/page printers. One paper feeder is attached to the copier/printer as a standard equipment. Furthermore, as an option, one can be installed to the copier and two can be installed to the printer. Each paper feeder is provided with two paper feed cassettes and there is the type (the total capacity of approximately 500 sheets) can be set approximately 250 sheets, and the other type (the total capacity of approximately 1000 sheets) can be set approximately 500 sheets.

  • Page 12: Unpacking

    5CY/3B7 1-2-1 Unpacking To unpack the paper feeder, proceed as diagrammed below. WARNING The paper feeder weighs approximately 20 kg (44 lbs.). Figure 1-2-2 Unpacking Place the paper feeder on a stable, level surface (table, floor, etc.). The paper feeder package contains each of the following items in the indicated quantities. Paper feeder ×...

  • Page 13: Installing The Paper Feeder

    5CY/3B7 1-2-3 Installing the paper feeder (1) Installing the paper feeder to the copier Fitting the shield gaskets (220-240 V specifications only) 1. Remove the release coated paper of the double-faced tape located on the rear face of the shield gaskets. 2.
  • Page 14 5CY/3B7 2. Place the copier on top of the paper feeder. 3. Join the copier and paper feeder(s) with the junction plate using the binding tap tight screw M4 × 8. Junction plate Binding tap tight screw M4 × 8 Figure 1-2-5 Joining the copier and paper feeder(s) Fixation of the copier 1.
  • Page 15 5CY/3B7 Installing the desk stay covers and attaching the labels 1. Attach the two desk stay covers to the front part of the two caster stays using the two M4 × 8 chrome screws (1 screw for each cover). M4 × 8 chrome screws Desk stay cover Desk stay...
  • Page 16 5CY/3B7 3. Attach the caution label at the shown in the diagram. Caution label Figure 1-2-9 Attaching the caution label...

  • Page 17: Installing The Paper Feeder To The Printer

    5CY/3B7 (2) Installing the paper feeder to the printer Attaching the casters (option) Caution To prevent the printer from tipping over because of weight of the printer and the paper cassettes, the caster kit must be installed at the bottom-most paper feeder, when an optional paper feeder or duplex unit is installed with the printer.
  • Page 18 5CY/3B7 Joining the printer and paper feeder(s) 1. Using the topple-resistant bracket (supplied with the caster kit), stack and join the bottom and middle paper feeders. Side view Topple-resistant bracket Figure 1-2-11 Joining the paper feeders 2. Place the printer on top of the paper feeders (by more than two persons). 3.
  • Page 19 5CY/3B7 4. Place the printer in a proper location. 5. Lock the stopper for each caster and turn the height adjuster clockwise until the adjuster reaches the floor. This fixes the printer in place. Stopper Height adjuster Figure 1-2-13 Fixation of the printer 1-12...

  • Page 20: Place The Paper Size Indicator Plate

    5CY/3B7 (3) Place the paper size indicator plate Place these on the front of the cassette according to the paper size inside to make it easy to know the current paper size. Paper size indication plate Figure 1-2-14 Place the paper size indicator plate 1-13...

  • Page 21: Names Of Parts

    5CY/3B7 1-2-4 Names of parts Figure 1-2-15 Paper feeder 1 Connector Plugs into a connector located inside the bottom of the copier/printer. When using 2 or 3 paper feeders, this connector plugs into a connector located inside the bottom of the upper feeder. 2 Positioning pins These pins fit into two holes in the bottom of the copier/printer.
  • Page 22 5CY/3B7 Figure 1-2-16 Paper feed cassette 1 Bottom plate Paper is placed on top of this. After the paper feed cassette is inserted into the feeder, the bottom plate rises as the paper stack decreases. 2 Paper guides Keeps the sides of the paper aligned. The paper guides should be repositioned for different paper size.

  • Page 23: Precautions Concerning Service And Maintenance

    5CY/3B7 1-3 Precautions concerning service and maintenance Only a qualified technician should perform service on the equipment, who is familiar with fundamental safety countermeasures as dictated for all electronics technicians. Observe the following precautions during service and maintenance of the paper feeder. These are to prevent the possible personal injuries to the technician and the damage to the equipment.

  • Page 24: Replacement Parts

    5CY/3B7 1-3-2 Replacement parts Be sure to use only the recommended supplies and components. We assume no liability in the event of damage resulting from the use of unauthorized components. 1-3-3 Notes concerning paper storage Use of paper with a high moisture content in the paper feeder can adversely affect printing quality through the occurrence of paper jams, wrinkling, and other difficulties.

  • Page 25: Specifications

    5CY/3B7 1-4 Specifications 1-4-1 Mechanical specifications Table 1-4-1 Mechanical specifications Item Specification Applicable paper standard paper See next page. Universal cassette × 2 Paper feed cassette ISO A3 (297 mm × 420 mm) Loadable paper size ISO A4 (210 mm × 297 mm) ISO A5 (148 mm ×...

  • Page 26: Paper Specifications

    5CY/3B7 1-4-2 Paper specifications Table 1-4-2 Paper specifications Item Specification Weight 64 to 90 g/m (17 to 24 lbs/ream) Thickness 0.086 to 0.110 mm (3.4 to 4.3 mils) ±0.7 mm (±0.0276 inches) Dimensional accuracy 90° ±0.2° Squareness of corners Moisture content 4 to 6 % Direction of grain Long...
  • Page 27 Assembly and Disassembly Chapter 2...
  • Page 28 Chapter 2 Contents 2-1 Introduction ............................2-3 2-2 Disassembly procedures ........................ 2-4 2-2-1 Precautions ............................. 2-4 2-2-2 Disassembly ........................... 2-5 (1) Removing the rear cover ........................2-5 (2) Removing the main board ........................2-6 (3) Removing the feed roller and pickup roller ..................2-7 (4) Removing the retard roller ........................

  • Page 29: Introduction

    5CY/3B7 2-1 Introduction This chapter explains the disassembly procedures required to replace parts. Note that the paper feeder requires no lubrication at any part.

  • Page 30: Disassembly Procedures

    5CY/3B7 2-2 Disassembly procedures This section provides procedures for disassembling of the paper feeder. When replacing parts for which there is no specific procedure described, refer to the exploded view shown in the Parts List (separate). 2-2-1 Precautions Before beginning disassembly, be sure to read the precautions below. •...

  • Page 31: Disassembly

    5CY/3B7 2-2-2 Disassembly (1) Removing the rear cover Remove four screws 1. Remove the rear cover 2. Figure 2-1-1a Removing the rear cover (250-sheet cassette paper feeder) Figure 2-1-1b Removing the rear cover (500-sheet cassette paper feeder)

  • Page 32: Removing The Main Board

    5CY/3B7 (2) Removing the main board Remove the rear cover (See page 2-5). Remove the all connectors from the main board 1. Remove five screws 2. Remove the main board 1. Figure 2-1-2a Removing the main board (250-sheet cassette paper feeder) Figure 2-1-2b Removing the main board (500-sheet cassette paper feeder)

  • Page 33: Removing The Feed Roller And Pickup Roller

    5CY/3B7 (3) Removing the feed roller and pickup roller Remove the four E-rings 1 from the feed roller’s shaft 2. Remove the feed roller 3 from the feed roller’s shaft 2. Remove the one E-ring 4 from the pickup roller’s shaft 5. Remove the pickup roller 6.

  • Page 34: Removing The Retard Roller

    5CY/3B7 (4) Removing the retard roller Remove the four screws 1. Remove the feed stay 2. Remove the retard plate 3. Remove the retard roller 4. NOTE Use care not forget the retard springs lost. Be sure to fit the red-colored retard spring on the front side of the retard roller. Retard spring Red-colored retard spring Figure 2-1-4 Removing the retard roller...

  • Page 35: Removing The Upper And Lower Cassette Base Elevation Motors (250-Sheet Cassette Paper Feeder)

    5CY/3B7 (5) Removing the upper and lower cassette base elevation motors (250-sheet cassette paper feeder) Remove the rear cover (See page 2-5). Open the side cover 1. Remove four screws 2. Remove the right cover 3. Figure 2-1-5 Removing the right cover Remove one connector 4.
  • Page 36 5CY/3B7 Remove six screws 7. Remove the mount plate 8. Figure 2-1-7 Removing the mount plate Remove one connector 9. Remove two screws 0. Remove the upper cassette base elevation motor !. Remove one connector @. Remove two screws #. Remove the lower cassette base elevation motor $.

  • Page 37: Removing The Upper And Lower Cassette Base Elevation Motors (500-Sheet Cassette Paper Feeder)

    5CY/3B7 (6) Removing the upper and lower cassette base elevation motors (500-sheet cassette paper feeder) Remove the rear cover (See page 2-5). Remove one connector 1. Remove two screws 2. Remove the upper cassette base elevation motor 3. Remove one connector 4. Remove two screws 5. Remove the lower cassette base elevation motor 6.
  • Page 38 Paper Specifications Chapter 3...
  • Page 39 Chapter 3 Contents 3-1 General guidelines ........................... 3-3 3-1-1 Paper availability..........................3-3 3-1-2 Selecting the right paper ......................... 3-4 3-2 Paper specifications ........................3-5 3-2-1 Points of consideration ........................3-5 (1) Condition of the paper ........................3-5 (2) Composition ............................3-5 (3) Paper size ............................

  • Page 40: General Guidelines

    5CY/3B7 3-1 General guidelines The paper feeder may not be used to print on paper not satisfying the requirements below. Also, special types of print media such as overhead projection (OHP) film, envelopes, adhesive backed labels, and paper containing watermarks must not be used with printing with the paper feeder. These types can result in jams, misfeeds, and paper waste, and in extreme cases can damage the paper feeder.

  • Page 41: Selecting The Right Paper

    5CY/3B7 3-1-2 Selecting the right paper Copier/printer printing is a process involving laser light, electrostatic discharge, toner, and heat. In addition, as the paper passes through the copier/printer it undergoes considerable sliding, bending, and twisting motions. A high-quality printing paper matching the requirements withstands all these stresses, enabling the paper feeder and the copier/printer to turn out clean, crisp printed copy consistently.

  • Page 42: Paper Specifications

    5CY/3B7 3-2 Paper specifications The following table summarizes the basic paper specifications that should be applied to the paper used with the paper feeder. Details are given following the table. Table 3-2-1 Specifications Item Specification Weight 64 to 90 g/m (17 to 24 lbs./ream) Thickness 0.086 to 0.110 mm (3.4 to 4.3 mils)

  • Page 43: Paper Size

    5CY/3B7 (3) Paper size The paper feeder is usable with the paper sizes as tabled below. Table 3-2-1 Paper size Paper size Dimension 297 mm × 420 mm ISO A3 210 mm × 297 mm ISO A4 148 mm × 210 mm JIS A5 257 mm ×...

  • Page 44: Moisture Content

    5CY/3B7 (7) Moisture content Moisture content is defined as the percent ratio of moisture to the dry mass of the paper. Moisture can affect the paper's appearance, feedability, curl, electrostatic properties, and toner fusing characteristics. The moisture content of the paper varies with the relative humidity in the room. When the relative humidity is high and the paper absorbs moisture, the paper edges expand, becoming wavy is appearance.

  • Page 45: Other Paper Properties

    5CY/3B7 3-2-2 Other paper properties (1) Porosity Refers to the density of the paper structure; that is, to how openly or compactly the fibers are bonded. (2) Stiffness Limp paper can buckle inside the paper feeder and the copier/printer, while paper that is too stiff may bind.

  • Page 46: Special Paper

    5CY/3B7 3-2-3 Special paper The following types of special paper can be used: Colored paper Preprinted paper Use paper that is sold specifically for use with photocopies and/or laser printers. Since the composition and quality of special paper very considerably, special paper is more likely than white bond paper to give trouble during printing.
  • Page 47 Mechanical Construction Chapter 4...
  • Page 48 Chapter 4 Contents 4-1 Introduction ............................4-3 4-2 Main board ............................4-4 4-3 Feeder interface ..........................4-5 4-3-1 Connector configuration ........................4-5 4-4 Paper feeding system ........................4-7 4-4-1 Paper control signals ........................4-9 4-4-2 Electrical components........................4-10 4-4-3 Paper cassette feeding ......................... 4-14 4-4-4 Paper cassette feeding drive system ....................

  • Page 49: Introduction

    5CY/3B7 4-1 Introduction This chapter describes the operation of the electrical circuits in the paper feeder. General diagram is provided in Appendix A.

  • Page 50: Main Board

    5CY/3B7 4-2 Main board The main board includes the driver circuits for motors and LEDs, reset circuit (U3), and other circuits diagrammed in Figure 4-2-1 below, that are controlled by CPU (U1). CPU incorporates a ROM that includes the program to operate the paper feeder which in turn provides control over the entire feeder system according to the program.

  • Page 51: Feeder Interface

    5CY/3B7 4-3 Feeder interface 4-3-1 Connector configuration The paper feeder and the copier/printer exchange signals between them through feeder interface connector which is provided on top of the paper feeder. The other end of the connector appears on the bottom of the paper feeder and exchanges the same signals with other paper feeder(s) that is installed with the copier/printer.
  • Page 52 5CY/3B7 Table 4-3-1 Feeder interface connector (Top) pin assignment PinNo. Signal Description Ground Ground OP24V +24V power OP24V +24V power SDOUT Serial communication input data SEL2 Select bit 2 SEL1 Select bit 1 SEL0 Select bit 0 OP5V +5 V power OP5V +5 V power Serial communication output data...

  • Page 53: Paper Feeding System

    5CY/3B7 4-4 Paper feeding system The paper feeding system picks up paper from the paper cassette. At a precise timing, it feeds it to the copier/printer. The printed page is finally delivered to the internal tray/face-down tray, eject tray/face-up tray, or optional document finisher/sorter , document finisher and stacker. The figure below shows the components in the paper path within the copier/printer and paper feeder.
  • Page 54 5CY/3B7 Duplex paper feeder Figure 4-4-1b Paper path (printer and paper feeders)

  • Page 55: Paper Control Signals

    5CY/3B7 4-4-1 Paper control signals The following diagram shows the signals that control the sensors and the rollers for guiding paper. Engine board Paper full sensor Feed drive Face down board board Paper feeder/ Paper feed options relay board board Paper Upper paper feed...

  • Page 56: Electrical Components

    5CY/3B7 4-4-2 Electrical components The figure below shows the locations of the sensors, switches, motors and LEDs. Each number corresponds to the description in the table on the next page. & Figure 4-4-3a Electrical components layout (250-sheet paper feeder) 4-10...
  • Page 57 5CY/3B7 Table 4-4-1 Electrical components Symbol Title Locations Main board Right side cover switch Upper cassette switch Drive plate Lower cassette switch Drive plate Upper jam sensor Upper cassette paper sensor/bottom limit sensor Upper cassette (Pickup board) Lower cassette paper sensor/bottom limit sensor Lower cassette (Pickup board) Upper cassette paper size sensors 1/2/3...
  • Page 58 5CY/3B7 & Figure 4-4-3b Electrical components layout (500-sheet paper feeder) 4-12...
  • Page 59 5CY/3B7 Table 4-4-1 Electrical components Symbol Title Locations Main board Right side cover switch Upper cassette switch Drive plate Lower cassette switch Drive plate Upper jam sensor Lower jam sensor Upper cassette paper sensor/bottom limit sensor Upper cassette (Pickup board) Lower cassette paper sensor/bottom limit sensor Lower cassette (Pickup board)

  • Page 60: Paper Cassette Feeding

    5CY/3B7 4-4-3 Paper cassette feeding Paper sensor/ Bottom limit sensor Interrupter (for bottom limit sensor) Paper feed roller Feed shaft Pickup lift bracket Feed stay Pickup roller Acutuator Retard roller Sheets of (for paper sensor) (Torque limitter) paper Bottom plate Bottom plate lift bracket Figure 4-4-4 Paper cassette feeding Inserting the paper cassette causes the cassette switch to turn on and L level signal is sent to the...
  • Page 61 5CY/3B7 As the copier/printer requests feeding paper, the main board activates the feed stepping motor, drives the feed shaft on the cassette, thus rotating the feed roller and the pickup roller, according to the paper feed timing. The pickup roller rotates to pull and feed the topmost paper on the stack on the bottom plate.

  • Page 62: Paper Cassette Feeding Drive System

    5CY/3B7 4-4-4 Paper cassette feeding drive system Rotation of the feed stepping motor rotates the feed shaft combined by feed gear. The drive of the feed shaft rotates the pickup roller through the feed roller and gear, and feeds paper from the cassette. Rotation of the feed stepping motor is always transmitted to the upper and lower feed shaft with the combination of the gear, and has become as rotate in the opposite direction.

  • Page 63: Paper Size Sensing

    5CY/3B7 4-4-5 Paper size sensing The size of the paper currently in the selected cassette is acknowledged to the engine board of the copier/printer by means of the on-off status of the paper size sensors PT1, PT2, and PT3 behind the paper stopper of the paper cassette.

  • Page 64: Paper Gauge Sensing

    4 stages at the operation panel. When the paper feeder is installed in the printer, it has the facility for allowing the Kyocera Printer Monitor software show the amount of remaining paper in the paper cassettes on the client’s display monitor.
  • Page 65 5CY/3B7 The paper gauge on the Kyocera Print Monitor indicates how much paper is remaining in the cassette in the rate of either of 25%, 50%, 75% or 100%, directly. These levels are given by the logic provided by the paper level switches using 2-bit signals of UPSEN1, LPSEN1, UPSEN2, and LPSEN2 in the manner explained below.
  • Page 66 5CY/3B7 Upper paper cassette Main board Copier/Printer OP5V UPURL* UPAP* Bottom Engine Paper Serial limit board (U1) level switch communi- Paper sensor cations sensor PAPER* UPSEN2 PVOL1 PVOL2 UPSEN1 USEL Selector (U13) Lower paper cassette LPURL* Paper level switch output logic LPAP* Paper Bottom...
  • Page 67 5CY/3B7 The rotating angle at which the paper level switch stops revolving depends on the amount of paper remaining, therefore, the more the paper remains in the cassette the greater the angle is. The rotating angle of the gear for the paper level switch varies in proportion with the rotating angle of the cassette base elevation motor in four positions.

  • Page 68: Paper Feeder Identifying System

    5CY/3B7 4-4-7 Paper feeder identifying system Copier/Printer Identifying codes Example: Output When engine board (CPU) Engine board of the copier/printer Paper identified paper feeder 1. feeder PFSDI Serial communication PFSDO Main board Paper feeder 1 (standard (U1) equipment) Crossed Decoder circuit UNTSEL* wiring (U4, U5)
  • Page 69 5CY/3B7 2. Since the installation bus lines are electrically "crossed" within the paper feeder as indicated in the diagram below, the decoder circuit of paper feeder 2 and 3 receive the first identifying code signals (PFSEL0= H, PFSEL1= L, and PFSEL2= L) in different ways (L-L-H for paper feeder 2 and L-H-L for paper feeder 3).
  • Page 70 Troubleshooting Chapter 5...
  • Page 71 Chapter 5 Contents 5-1 Introduction ............................5-3 5-2 Self-diagnosis ..........................5-4 5-2-1 Self-diagnostic function ........................5-4 5-2-2 Error messages ..........................5-6 5-3 Clearing Paper Jams ........................5-7 5-3-1Paper misfeed detection (installed to the copier) ................5-7 (1) Paper misfeed indication ........................5-7 (2) Paper misfeed detection conditions ....................
  • Page 72 5CY/3B7 5-1 Introduction This chapter explains procedures for identifying and clearing paper jams.

  • Page 73: Self-Diagnosis

    5CY/3B7 5-2 Self-diagnosis 5-2-1 Self-diagnostic function The copier/printer is equipped with a self-diagnostic function. When a problem is detected, copying/ printing is disabled. The problem displayed as a code consisting of "C" followed by a number of four digits, indicating the nature of the problem when the paper feeder is installed in the copier. The problem displayed as a code consisting of four digits, indicating the nature of the problem when the paper feeder is installed in the printer.
  • Page 74 5CY/3B7 Remarks Code Contents Causes Check procedures/corrective measures 1050 Overcurrent detection of Defective Replace the upper cassette base upper cassette base upper cassette elevation motor. elevation motor (Paper base elevation feeder 3) motor. • Excessive current has Defective Check whether there is an object flowed through the upper bottom plate that prevents the bottom plate of...

  • Page 75: Error Messages

    5CY/3B7 5-2-2 Error messages When the following error messages appear on the printer’s message display, check the paper feeder. Table 5-2-2 Error messages Message Corrective Action Add paper (paper source) The paper has run out in the paper source displayed. Supply paper according to the paper source displayed.

  • Page 76: Clearing Paper Jams

    5CY/3B7 5-3 Clearing Paper Jams 5-3-1 Paper misfeed detection (installed to the copier) (1) Paper misfeed indication When a paper misfeed occurs, the copier immediately stops copying and displays the jam location on the operation panel. Paper misfeed counts sorted by the detection condition can be checked in maintenance item U903.

  • Page 77: Timing Chart

    5CY/3B7 • No paper feed from the upper cassette (jam code 12) Jam sensor 3 (JS3) does not turned on within 830 ms of the paper feed clutch (PFCL) turning on (when paper is fed from the upper cassette of paper feeder 2). PFCL 830 ms Timing chart 5-3-1...

  • Page 78: Paper Misfeeds

    5CY/3B7 (3) Paper misfeeds Problem Causes/check procedures Corrective measures Paper in the upper Change the paper. A paper jam in cassette is extremely the paper feed curled. section is Check if the paper feed Check visually and replace any deformed pulleys. indicated pulley, separation during copying...
  • Page 79 5CY/3B7 Problem Causes/check procedures Corrective measures Broken jam sensor 1 Check visually and replace jam sensor 1 if its A paper jam in actuator. actuator is broken. the paper feed Defective jam sensor 1. Run maintenance item U031 and turn jam sensor section is 1 on and off manually.
  • Page 80 5CY/3B7 5-3-2 Paper misfeed detection (installed to the printer) (1) Paper misfeed indication When a paper misfeed occurs, the printer immediately stops printing and displays the jam location on the operation panel. To remove paper jammed in the paper feeder, open the side cover and paper cassette. Paper misfeed detection can be reset by opening and closing the respective covers.
  • Page 81 Timing Chart / Appendix A Wiring Diagram...

  • Page 82: Appendix A Contents

    Appendix A Contents Timing chart No. 1 ..........................A-3 Timing chart No. 2 ..........................A-4 Wiring diagram ............................A-5...
  • Page 83 5CY/3B7-1...
  • Page 84 5CY/3B7...

  • Page 85: Wiring Diagram

    5CY/3B7-1 Wiring diagram Upper cassette Main board OP5V LED board ULMPD To copier/printer or OP5V OP5V OP5V upper paper feeder OP5V OP5V OP5V OP5V UPCAS1 UPCAS1 UPCAS1 UPCAS1 Paper size UPCAS2 UPCAS2 UPCAS2 UPCAS2 sensor board UPCAS4 UPCAS4 UPCAS4 UPCAS4 ULMPD ULMPD ULMPD...
