PART NUMBERING SYSTEM

DNT 04
Product
Input Voltage
Series
DNT- 3A/5A 04 - 2.4V~5.5V

MODEL LIST

Model Name Package
DNT04S0A0S03NFA SMD
DNT04S0A0R03NFA SIP
DNT04S0A0S05NFA SMD
DNT04S0A0R05NFA SIP
CONTACT: www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email: DCDC@delta-corp.com
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon
request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta
for its use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license
is granted by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these
specifications at any time, without notice
DS_DNT04SIP3A_09262007
S 0A0
Numbers Output Package
of Outputs Voltage
S - Single 0A0 - R - SIP
Programmable
Input Voltage
2.4V ~ 5.5Vdc
2.4V ~ 5.5Vdc
2.4V ~ 5.5Vdc
2.4V ~ 5.5Vdc
Europe:
Telephone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email: DCDC@delta-es.tw
.
R 03 N
On/Off
Output
logic
Type Current
03 - 3A N- negative
(Default)
P- positive
Output Voltage Output Current
0.75V ~ 3.63Vdc
0.75V ~ 3.63Vdc
0.75V ~ 3.63Vdc
0.75V ~ 3.63Vdc
Asia & the rest of world:
Telephone: +886 3 4526107 x6220
Fax: +886 3 4513485
Email:
F A
Option Code
A - Standard Function
F- RoHS 6/6
(Lead Free)
Efficiency
5Vin, 3.3Vdc full load
93.5%
3A
94%
3A
94%
5A
93%
5A
DCDC@delta.com.tw
