PART NUMBERING SYSTEM

Q 48
Form Factor Input
Voltage
Q – Quarter 36V~75V
Brick

MODEL LIST

MODEL NAME
Q48DR1R533NRFA
Q48DR1R833NRFA
Q48DR2R533NRFA
Q48DR3R350NRFA
CONTACT: www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email: DCDC@delta-corp.com
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available
upon request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta
for its use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license
is granted by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise
these specifications at any time, without notice
DS_Q48DR1R533_03152007
D R
Number of Product Output
Outputs Series Voltage 1
D- Dual R-Open frame 1R5-1.5V
Output 1R8-1.8V
2R5-2.5V
3R3-3.3V
INPUT
36V~75V
36V~75V
36V~75V
36V~75V
Europe:
Phone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email: DCDC@delta-es.com
.
1R5 33 N
Output ON/OFF
Voltage 2 Logic
33-3.3V N-Negative
50-5.0V (Default)
P-Positive
OUTPUT
2.8A 1.5V/15A
2.9A 1.8V/15A
3.3A 2.5V/15A
3.8A 3.3V/15A
R F
Pin Length Option Code
R-0.170" A - Standard
F- RoHS 6/6
(Default)
(Lead Free)
N-0.145"
K-0.110" B - with second
EFF @ Full Load
3.3V/15A 87.5%
3.3V/15A 88.0%
3.3V/15A 88.0%
5.0V/10A 88.5%
Asia & the rest of world:
Telephone: +886 3 4526107 ext 6220
Fax: +886 3 4513485
Email: DCDC@delta.com.tw
A
Functions
(Default)
trim pin
