1.
IMPORTANT SAFETY INSTRUCTIONS ____________________ 2
1.1
Disposal _______________________________________________ 10
2.
INSTALLATION AND HOOK-UP _________________________ 11
2.1
Technical characteristics __________________________________ 11
Appliance dimensions _________________________________________ 11
2.2
General Information ______________________________________ 12
2.3
Water supply connection __________________________________ 14
2.4
Electrical connection _____________________________________ 16
3.
DESCRIPTION OF THE CONTROLS _____________________ 21
3.1
Front panel ____________________________________________ 21
4.
OPERATING INSTRUCTIONS ___________________________ 26
4.1
Adding the rinse aid ______________________________________ 26
4.2
Adjusting the rinse aid dispenser mode ______________________ 26
4.3
Adding the detergent _____________________________________ 27
5.
CLEANING AND MAINTENANCE ________________________ 28
6.
TROUBLESHOOTING _________________________________ 29
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use
of your dishwasher.
This manual contains only the basic information required to use the
appliance. The complete manual can be obtained from
www.smeg.com/download-manuals
by entering the product code shown on the plate attached to the inner
right hand edge of the dishwasher door.
The manual can be accessed quickly via the QR code using a device
with a QR reader application.
1
Installation
Advertisement
Table of Contents
Related Manuals for Smeg DW8610
Summary of Contents for Smeg DW8610
-
Page 1: Table Of Contents
This manual contains only the basic information required to use the appliance. The complete manual can be obtained from www.smeg.com/download-manuals by entering the product code shown on the plate attached to the inner right hand edge of the dishwasher door. -
Page 2: Important Safety Instructions
Installation TRANSLATION ORIGINAL INSTRUCTIONS 1. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS Before using the appliance, carefully read all the instructions contained in this manual. During installation, take care not to injure yourself on the sharp edges of the appliance: wear safety gloves. - Page 3 Installation Certified residential dishwashers are not intended for licensed food establishments. Do not use appliances which have been damaged during transit! If in doubt, contact your dealer. Do not operate your dishwasher unless all enclosure panels are properly in place. ...
- Page 4 Installation from each for several minutes. This will release any accumulated hydrogen gas. As the gas is flammable, do not smoke or use an open flame during this time. Never leave waste packaging unattended. Do not allow children to play with packaging materials. Separate waste packaging materials by type and consign them to the nearest recycling centre.
- Page 5 Installation information, contact the manufacturer of the equipment to ensure that the appliance can be installed above or below it. Building-in the appliance underneath a cooktop is absolutely forbidden. Installing a cooktop on top of free-standing appliance is absolutely forbidden. ...
- Page 6 Installation If the appliance is provided with a plugless supply cord, an omnipolar circuit breaker providing a full disconnection in overvoltage protection class III must be installed in an easily accessible position on the supply lineile. The appliance must be connected to the water supply by means of new hoses.
- Page 7 Installation Keep children away from the dishwasher when the door is open. Always check that the detergent distributor is empty after completion of the wash cycle. Cleaning and regular maintenance of the appliance by children is only permitted under the supervision of a person responsible for their safety.
- Page 8 Installation Load sharp knives with the handles up to reduce the risk of cut-type injuries. The appliance satisfies all applicable safety regulations governing electrical equipment. Any technical checks should be conducted exclusively by trained authorised technicians: repairs performed by unauthorised persons not only void the warranty but may also put the user’s safety at risk.
- Page 9 Installation case of damage to the water intake hose, disconnect the appliance from the electrical and water supply. Warning: The device only works dishwasher is connected to the mains.
-
Page 10: Disposal
Installation 1.1 Disposal The appliance does not contain substances in quantities sufficient to be considered hazardous to health and the environment, in accordance with current European directives: To dispose of the appliance: Remove the washing compartment door. Cut the power cable, ... -
Page 11: Installation And Hook-Up
15 standard place settings Class of protection against IPX0 moisture Protection against electric class I shock Electrical data see the data plate Appliance dimensions Dimen sions 32”-13/64 23”-1/2 818 mm; 597 mm 22”-7/16 DW8610 570 mm 34”-61/64 23”-5/8 888 mm 600 mm... -
Page 12: General Information
Installation 2.2 General Information This appliance may be placed up against walls or other furniture units. If the appliance is installed near a heat source, fit a special insulating panel to prevent overheating and malfunction of the appliance. ... - Page 13 Installation Building-in a dishwasher underneath a cooktop is absolutely forbidden. Moreover, dishwashers may not be installed directly touching appliances which are not conventional built-in kitchen appliances (e.g. fireplaces, stoves, etc.). When installing the dishwasher in a compartment next to one or more other appliances, it is essential to comply with all the recommendations provided appliance’s manufacturer...
-
Page 14: Water Supply Connection
Installation 2.3 Water supply connection CONNECTING TO THE WATER SUPPLY Connect the intake hose to a cold water supply with ¾” gas thread. Take care to screw the hose firmly into place with your hands and then complete by tightening about ¼ of a turn with pliers. -
Page 15: Drain Connection
Installation DRAIN CONNECTION Insert the dishwasher’s drain hose into a drain pipe having a diameter of at least 4 cm (1"37/64), or alternatively, place it inside the kitchen sink using the plastic support provided, taking care not to crush or excessively bend the hose. -
Page 16: Electrical Connection
Installation 2.4 Electrical connection Check that the voltage and the frequency of the mains match the ratings on the name plate of the appliance positioned on the inner edge of the door. This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. - Page 17 Installation Do not use adaptors or shunt connections in order to avoid the possibility of overheating or burning. The power cable must be replaced by the manufacturer or by an Authorized Service Centre. ELECTRICAL CONNECTION WITH JUNCTION BOX Follow all the instructions, including those in the user manual.
- Page 18 Installation by a qualified technician. The appliance must be earthed in accordance with electrcial safety regulations. The manufacturer accepts no liability for injury or damage resulting from failure to provide a proper earth connection. Junction box Needed tools Minimum features: IP55-UL94V0 WARNING! Avoid the risk of electric shock or fire.
- Page 19 Installation - Use the junction box cabel grip correctly. DISHWASHER ELECTRICAL DATA Volt Hertz Amperes Watt 1300 (max) Remove the screws and junction box cover Disconnect the system from the power supply. Remove the plug: Loosen and remove the screws “A”; Remove the cable grip “P»...
- Page 20 Installation Secure the wires in the junction box using the cable clamp. Close the junction box, Connect to the system.
-
Page 21: Installation
Installation 3. DESCRIPTION OF THE CONTROLS Front panel All the dishwasher controls are grouped on the upper panel. Switch-on, programming, switch-off, etc. procedures are only possible when the door is open. ON/OFF BUTTON AND WARNING LIGHT SANITIZED LIGHT NO RINSE AID LIGHT PROGRAM SELECTION BUTTONS START/PAUSE BUTTON PROGRAM INDICATOR LIGHTS... - Page 22 Installation SWITCHING ON When the ON/OFF button (1) is pressed, the dishwasher switches on. The indicator lights will display the dishwasher's "status". PROGRAMMING Programming operations are only possible with the door closed. As long as the door is open, the PROGRAMS (6) lights remain off. PROGRAM SELECTION Press the PROGRAM SELECTION button (4) several times until the light of the program required comes on.
- Page 23 User instructions INTERRUPTION A PROGRAM To interrupt a program in progress: press the START/PAUSE button (5); the light of the program in progress remains on (confirmation beep); you may now restart the program by pressing button (5) again until it restarts, or change or annul the program (see "C HANGING ", or "A...
- Page 24 User instructions PROGRAMS TABLE Program RINSE cold 0,02 1,2 gal. 11.7 45°C AUTO (2) cold 53°C (127,4°F) ● 0,5-0,6 (**) (113°F) 3,1 gal. 11,8l 65°C EXPRESS 60’ cold 70°C (158°F) ● 1,15 (149°F) 3,1 gal 65°C NORMAL cold 55°C (131°F) ●...
- Page 25 User instructions Description of the programs: RINSE Pans and dishes while waiting for another wash cycle AUTO (2) Normally soiled dishes including dried-on residues, for daily use. EXPRESS 60’ Quick cycle for normally soiled mixed loads such as dishes and pans, even with dried-on residues.
-
Page 26: Operating Instructions
User instructions 4. OPERATING INSTRUCTIONS After having installed the dishwasher, remove the basket retainers. Adding the rinse aid The rinse aid helps to dry the dishes more quickly. To add rinse aid: Open the dispenser by pressing and lifting the tab on the cover. -
Page 27: Adding The Detergent
User instructions RINSE AID ADJUSTMENT TABLE All indicator lights off 0 – not dispensed One indicator light on minimum 2 ml Two indicator lights on 3 ml Three indicator lights on Four indicator lights on Five indicator lights on maximum 6 ml Default settings: b4 - 5 ml ... -
Page 28: Cleaning And Maintenance
User instructions 5. CLEANING AND MAINTENANCE Before carrying out any work, always unplug the appliance from the electrical supply or switch off the omnipolar circuit breaker. The water filter at the inlet to the intake hose should be cleaned periodically. Close the water supply tap, unscrew the water intake hose and make sure that the filter at the inlet to the hose is not dirty or clogged (the filter cannot be removed from the hose). -
Page 29: Troubleshooting
User instructions 6. TROUBLESHOOTING The dishwasher is capable of signalling a number of faults through the simultaneous illumination of several indicator lights, with the following meanings: FAULT DESCRIPTION Acquastop failure (some models only) Safety level Water heating fault Water temperature detection fault Water intake fault Water drainage fault Turbine flow-meter fault (some models only) - Page 30 User instructions...
