Smeg Universale DWAI6314X2 Manual
  1. Manuals
  2. Brands
  3. Smeg Manuals
  4. Dishwasher
  5. Universale DWAI6314X2
  6. Manual

Smeg Universale DWAI6314X2 Manual

Hide thumbs

Advertisement

Quick Links

Contents
1.
Safety and operating instructions __________________________ 2
1.
Installation and hook-up _________________________________ 8
2.
Description of the controls ______________________________ 11
3.
Operating instructions __________________________________ 21
4.
Cleaning and maintenance ______________________________ 29
5.
Troubleshooting ______________________________________ 44
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use of
your dishwasher.
The individual sections are laid out to provide you with a step-by-step
guide to all your appliance's functions; the texts are easy to understand
and are complete with detailed illustrations.
Recommendations are given for the correct use of the baskets, spray
arms, containers, filters, washing programs, and for operating the controls.
Following the cleaning instructions provided here will keep your
dishwasher's performance at peak levels in the long term.
This user-friendly manual will provide answers to all your questions about
use of the dishwasher.
INSTALLATION INSTRUCTIONS: these are intended for the qualified
technician who must carry out the installation, hook-up and testing of the
appliance.
USER INSTRUCTIONS: these consist of recommendations for using the
appliance, a description of its controls and of the correct cleaning and
maintenance procedures.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Universale DWAI6314X2 and is the answer not in the manual?

Questions and answers

RICHARD CAMERON JACKSON DOBIE
March 25, 2025

how does the door lock on a DWA6314 DISHWASHER OPERATE

0
1 comments:
Mr. Anderson
March 25, 2025

The door lock on the Smeg Universale DWAI6314X2 dishwasher operates based on the condition of the lock hook. If the lock hook has not triggered (reference N), the door opens and closes normally. If it has triggered (reference S), the door must be closed with force until it resets, after which the door can be opened and closed again. Additionally, if the door does not close, users should check the position of the door lock catch (D) and, if necessary, adjust it by raising the plastic screw (V) next to the catch. If the issue persists after troubleshooting, users are advised to contact the nearest After-Sales Centre.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Smeg Universale DWAI6314X2

Summary of Contents for Smeg Universale DWAI6314X2

  • Page 1: Table Of Contents

    Contents Safety and operating instructions __________________________ 2 Installation and hook-up _________________________________ 8 Description of the controls ______________________________ 11 Operating instructions __________________________________ 21 Cleaning and maintenance ______________________________ 29 Troubleshooting ______________________________________ 44 Thank you for choosing one of our products. You are advised to read this manual carefully; it contains all the information you need about the right conditions for the proper, safe use of your dishwasher.

  • Page 2: Safety And Operating Instructions

    Installation instructions 1. Safety and operating instructions THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE; IT MUST ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER FOR FUTIRE REFERENCE. BEFORE USING THE APPLIANCE, CAREFULLY READ ALL THE INSTRUCTIONS CONTAINED IN THIS MANUAL. THEY CONTAIN IMPORTANT INFORMATION FOR THE INSTALLATION, USE AND MAINTENANCE OF THE APPLIANCE.
  • Page 3 Installation instructions THE APPLIANCE MUST BE PROVIDED WITH AN EARTH CONNECTION IN ACCORDANCE WITH THE ELECTRICAL SAFETY REGULATIONS IN FORCE. THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR DAMAGE TO PERSONS OR PROPERTY RESULTING FROM THE FAILURE TO EARTH THE APPLIANCE OR FROM A DEFECTIVE EARTH CONNECTION. DURING THE INSTALLATION THE APPLIANCE MUST BE DISCONNECTED FROM THE NETWORK..
  • Page 4 Installation instructions IF THE APPLIANCE IS PROVIDED WITH A PLUGLESS SUPPLY CORD, A CIRCUIT BREAKER PROVIDING A FULL DISCONNECTION IN OVERVOLTAGE PROTECTION CLASS III MUST BE INSTALLED IN AN EASILY ACCESSIBLE POSITION ON THE SUPPLY LINE. THE DISHWASHER MUST ALWAYS BE CONNECTED TO THE WATER SYSTEM USING NEW HOSE SETS.
  • Page 5 Installation instructions THE DISHWASHER MEETS ALL THE REQUIREMENTS SET OUT BY THE REGULATIONS IN FORCE CONCERNING SAFETY AND ELECTRICAL EQUIPMENT. TECHNICAL CHECKS SHOULD BE CONDUCTED EXCLUSIVELY BY TRAINED AND AUTHORISED TECHNICIANS: REPAIRS CARRIED OUT BY UNAUTHORISED PERSONS WILL INVALIDATE THE WARRANTY, AS WELL AS POSING A POTENTIAL HAZARD TO THE USER.
  • Page 6 Installation instructions IN ACCORDANCE TO ART. 26 OF THE LEGISLATIVE DECREE 14 MARCH 2014, NR. 49 “IMPLEMENTATION OF THE DIRECTIVE 2012/19/EU ON WASTE OF ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)”. THE SYMBOL OF A CROSSED OUT WHEELIE BIN ON THE DEVICE OR PACKAGE SHOWS THAT THE PRODUCT MUST BE COLLECTED SEPARATE FROM OTHER WASTE, AT THE END OF ITS SERVICE LIFE.
  • Page 7 Installation instructions TECHNICAL DATA TECHNICAL DATA 597  599 mm Width Depth measured flush with the Free standing: 600 mm outer edge of the control panel Semi-integrated: 570 mm Free standing: from 850 mm to 890 mm from 890 mm to 930 mm Height (depending on models) Semi-integrated: from 820 mm to 890 mm from 860 mm to 930 mm...

  • Page 8: Installation And Hook-Up

    Installation instructions 2. Installation and hook-up Remove the polystyrene basket retainers. Position the appliance in the desired place of installation. The back or sides of the dishwasher may be placed up against walls or other furniture units. If the dishwasher is installed near a heat source, fit the special insulating panel to prevent overheating and malfunction of the appliance.
  • Page 9 Installation instructions Water supply connection Preventing the risk of clogging or damage: if the water pipe is new or has not been used for a long time, before connecting to the water supply check that the water is clear and free of impurities, to prevent damage to the appliance.
  • Page 10 Installation instructions DRAIN CONNECTION Insert the dishwasher’s drain hose into a drain pipe having a diameter of at least 4 cm, or alternatively, place it inside the kitchen sink using the plastic support provided, taking care not crush or excessively bend the hose. It is important to prevent the hose from coming loose and falling.

  • Page 11: Description Of The Controls

    User instructions 3. Description of the controls Front panel All the dishwasher controls are grouped on the front panel. Programming and option selection are only possible with the door closed. ON/OFF BUTTON AND WARNING LIGHT OPTION SELECTION BUTTONS AND WARNING LIGHTS “CHILD LOCK”...
  • Page 12 User instructions Control LEDS In this area there are control LEDS for the washing progression state, salt and rinse aid lack warning, and delayed start. Salt lack warning indicator (on some models only) Water hardness adjustment on indicator light (on some models only) Rinse aid lack warning indicator The four LEDs have double function: - Once the program is running, they highlight the...
  • Page 13 User instructions PROGRAMS TABLE CONSUMPTION DURATION PROGRAMME LOAD CROCKERY AND PROGRAM NUMBER CUTLERY PROGRESS MINUTES POWER WATER & SYMBOL kWh (1) LITRES 1 RAPID 27’ Dishes with light dirt, Wash at 38°C 0,70 washed immediately after Rinse at 50°C NORMAL Cold prewash ECO (*) Crockery and cutlery...
  • Page 14 User instructions QUICK TIME PROGRAMS (ENERSAVE option non available) (see relevant section for explanation of functioning modes) DURATION CONSUMPTION PROGRAMME PROGRAM LOAD CROCKERY AND NUMBER E PROGRESS MINUTES WATER POWER CUTLERY SYMBOL LITRES KWh (1) 6 SOAK Pans and dishes awaiting 0,02 Cold prewash completion of the load...
  • Page 15 User instructions Washing programs The dishwasher is equipped with a control panel, described in chapter "3. Description of the controls", from which it is possible to carry out all the power switch-on, switch-off and programming operations. Before starting a washing program make sure that: ...
  • Page 16 User instructions END OF PROGRAM At the end of the program the beeper sounds briefly and the program lights 4 and 5 (marked "end") flash. INTERRUPTION A PROGRAM To interrupt a program in progress:  press the START/PAUSE button (6); the light of the program in progress remains on (confirmation beep);...
  • Page 17 User instructions In case that the door is opened during the operation, to the next door closing it is going to be necessary to start the program as shown in paragraph “ ”. The program will resume from the TARTING THE PROGRAM point in which it was interrupted.
  • Page 18 User instructions Flexi Tabs Specifically for washing with combination detergents in tablets, which also contain salt and rinse aid (3in1) or other agents such as glass protector, steel rinse aids, etc. (4in1, 5in1…). When this option is selected, salt and rinse aid will not be dispensed even if the relative compartments contain them.
  • Page 19 User instructions PROGRAM DELAY The PROGRAM DELAY button can be pressed to delay the start of the washing program by 3, 6, 9 or 12 hours. This function allows you to set the dishwasher to work at your preferred time of day. After selecting the delay, start the program (see relative section).
  • Page 20 User instructions ENERGY MANAGEMENT At the end of the program, afterwards 5 minutes, the washing machine switches off automatically in order to reduce standby power consumption. In order to switch it on again, it is necessary to press the ON/OFF button. REMOVING THE DISHES At the end of the washing program, wait at least 20 minutes before removing the dishes, to allow them to cool down.

  • Page 21: Operating Instructions

    User instructions 4. Operating instructions Once the dishwasher has been correctly installed, prepare for use as follows:  Adjust the water softening system (on some models only);  Add the regenerating salt (on some models only);  Add the rinse aid and detergent. Using the water softening system (on some models only) The amount of scale contained in the water...
  • Page 22 User instructions  Do not use table salt as it contains insoluble substances which, over time, may damage the water softening system.  When necessary, refill the regenerating salt container before starting the washing program. In this way, the excess saline solution will be immediately removed by the water;...
  • Page 23 User instructions WATER HARDNESS TABLE WATER HARDNESS SETTING German French degrees (°dH) Degrees (°dF) H0 - All lights off 0 - 6 0 - 11 (no salt) H1 - One light on 7 - 10 12 - 18 H2 - Two lights on 11 - 15 19 - 27 H3 - Three lights...
  • Page 24 User instructions ADDING THE RINSE AID The rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle, from the container situated on the inner side of the door. To add rinse aid: ...
  • Page 25 User instructions ADJUSTING THE RINSE AID DISPENSER MODE Press and hold the PROGRAM SELECTION button (7), after about 15" the salt indicator flashes; keep still pressed until the RINSE AID DISPENSER MODE INDICATOR LIGHT (4) flashes and the SELECTED PROGRAM LIGHTS (8) indicate the current setting. Press several times to choose the desired dosage according to the following table: >...
  • Page 26 User instructions ADDING THE DETERGENT To open the detergent dispenser cover, lightly press button P. Add the detergent or tablet and close the cover by sliding it until it stops, indicated by a click. The dispenser will open automatically during the wash cycle. Only add the detergent (also in tablet form) if the dispenser is dry ...
  • Page 27 User instructions The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
  • Page 28 User instructions WARNING!  Make sure that the dishes are securely in place so that they cannot tip over or obstruct the rotation of the spray arms during the washing cycle.  Do not place very small objects in the baskets as these could fall and obstruct the spray arms or the wash pump.

  • Page 29: Cleaning And Maintenance

    User instructions Using the baskets The dishwasher has a capacity of 14 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling. All types and combinations of loads are permitted, provided that the dishes, pots and pans are arranged with all the soiled surfaces...
  • Page 30 User instructions LOADING THE LOWER BASKET Carefully load flat plates, soup plates, dessert and serving dishes, positioning them vertically. Pots, pans and their covers must be loaded upside down. When loading soup plates and dessert bowls, be sure to leave a gap between them. Loading examples: UPPER BASKET The upper basket should be loaded with small or medium-sized items...
  • Page 31 User instructions CUTLERY BASKET The basket is suitable for all types of cutlery, except long items that may interfere with the upper spray arm. The cutlery should be arranged in the spaces in the upper racks to allow the water to pass effectively between the items.
  • Page 32 User instructions TOP CUTLERY BASKET (on some models only) The basket is designed to take cutlery, placed in the spaces provided, and long utensils, positioned lengthwise. The “drawer” extraction system makes the basket easier to load, but it can also be taken completely off its runners by removing the retainers (as shown here).
  • Page 33 User instructions Fold-down shelves For mugs, cups and long objects. The ends are designed to hold long stemmed glasses When not used they can be moved to a vertical position (until a click is heard). Shelves with expandable wings For small objects, mugs and cups. They can be used either closed or open (pull the upper, sliding part).
  • Page 34 User instructions Fold-down tines These can be secured in a vertical position, resting on the bottom of the basket if unused, or placed in an intermediate position, as required. The single tine on the right is ideal for supporting long stemmed glasses.
  • Page 35 User instructions ADJUSTING THE UPPER BASKET The height of the top basket can be adjusted to allow large dishes or pans to be placed in the bottom basket. The adjustment procedure may be type A or B, depending on the dishwasher model purchased.
  • Page 36 User instructions 5. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or switch off the all-pole disconnection device. General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces.
  • Page 37 User instructions  To remove the lower spray arm, simply lift it up, pulling by the central part.  To remove the orbital spray arm assembly, take hold of the longer arm and pull the orbital unit upward. Wash the arms under a jet of running water and return them carefully to their seat.
  • Page 38 User instructions CLEANING THE FILTER UNIT (models with planetarium sprayer)  It is advisable to periodically inspect the centre filter and, if necessary, to clean it.  remove the planetarium sprayer follow the instructions provided.  push the centre filter D from the underside to remove it from the micro- filter: ...
  • Page 39 User instructions BEFORE STARTING THE DISHWASHER AFTER PROLONGED DISUSE:  Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. ...
  • Page 40 User instructions If the dishes fail to dry or remain dull, check that:  there is rinse aid inside the special container;  the rinse aid dispenser setting is correct;  the detergent used is of good quality and has not lost its effectiveness (for example, through incorrect storage, with the box left open).
  • Page 41 User instructions Only for models with this lock version. If the door does not close: 1 - Check the position of the door lock catch (D) 2 - If necessary, raise it by adjusting the plastic screw (V) next to the catch.
  • Page 42 User instructions If the door does not close: 1 - Check the position of the door lock catch (D) 2 - If necessary, raise it by adjusting the plastic screw (V) next to the catch. 3 - Check the condition of the lock hook; if it has not triggered (reference N), the door opens and closes normally.
  • Page 43 User instructions If after following the above troubleshooting instructions the problem persists, call the nearest After-Sales Centre. WARNING: any operations performed on the appliance by unauthorised persons are not covered by the warranty and shall be paid for by the user.

  • Page 44: Troubleshooting

    User instructions 6. Troubleshooting The dishwasher is capable of signalling a number of faults through the simultaneous illumination of several indicator lights, with the following meanings: FAULT DESCRIPTION Acquastop failure The anti-flooding system has been activated (for the relevant models only). The system is tripped in case of water leaks.
  • Page 45 User instructions FAULT DESCRIPTION Turbine flow-regulator malfunction (for the relevant models only) The appliance is not able to "measure" the amount of water loaded accurately. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle.
