- Page 1 INSTRUCTION MANUAL DISHWASHER...
-
Page 2: Table Of Contents
Thank you for choosing this product. We advise you to carefully read all the instructions contained in this manual, in order to understand how to operate your dishwasher safely and correctly. The manual is divided into paragraphs, which provide a step by step description of the dishwasher functions, with clear instructions accompanied by detailed illustrations. -
Page 3: Safety And Operating Instructions
Safety instructions 1. Safety and operating instructions THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE: IT MUST ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER. BEFORE USING THE APPLIANCE, CAREFULLY READ ALL THE INSTRUCTIONS CONTAINED IN THIS MANUAL. INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN COMPLIANCE WITH THE REGULATIONS IN FORCE. -
Page 4: Safety Instructions
CHILDREN (LOCKS, DOORS, ETC.). THE APPLIANCE MUST THEN BE TAKEN TO A SORTED WASTE COLLECTION CENTRE. IN THE EVENT OF A FAULT, DISCONNECT THE DISHWASHER FROM THE ELECTRICAL POWER SUPPLY AND SHUT OFF THE WATER TAP. THEN CALL IN A QUALIFIED TECHNICIAN. - Page 5 CAUSE THE APPLIANCE TO OVERTURN, PUTING PEOPLE AT RISK. DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE THE DISHES OR DISHWASHER AT THE END OF THE WASHING PROGRAM AND BEFORE THE DRYING CYCLE. KNIVES OR OTHER SHARP-ENDED COOKING UTENSILS MUST BE PLACED IN THE CUTLERY BASKET BLADE-DOWN, OR LAID HORIZONTAL IN THE TOP BASKET.
-
Page 6: Installation Instructions
Position the appliance in the desired place of installation. The back or sides of the dishwasher may be placed up against walls or other furniture units. If the dishwasher is installed near a heat source, fit the special insulating panel to prevent overheating and malfunction of the appliance. -
Page 7: Connecting To The Water Supply
The dishwasher can also be connected to a hot water supply not exceeding 60°C. Supplying the appliance with hot water cuts down the washing time by approximately 20 minutes, but slightly reduces its effectiveness. -
Page 8: Description Of The Controls
NO RINSE AID LIGHT PROGRAM PHASES LIGHTS RECESSED DOOR HANDLE LIGHTING When the ON/OFF button (1) is pressed, the dishwasher switches on and the light (3) comes on. About 2 seconds later, the PROGRAM PHASES lights (7) will come on. PROGRAMMING In this model of dishwasher, all programming procedures can only be carried out with the door closed. -
Page 9: Table Of Programs
(*) Reference program as EN 50242 standard. (-) Not present. The washing cycle will not take place if the dishwasher door is left open or not properly closed. For any other information about use and maintenance of the dishwasher, read the enclosed manual carefully. -
Page 10: Start Program
User instructions SELECTION PROGRAM When the button relating to the program required (see enclosed programs chart) is pressed, the relative light will come on to confirm the operation. START PROGRAM To start the appliance, simply press the button of the chosen program and keep it pressed for a few seconds;... -
Page 11: End Program
(7) flash. Press any of the SELECTION PROGRAMS buttons (2), stops the light flashins, and the dishwasher is now ready to perform a new cycle; opening and shutting the door or switching the appliance off and on has the same effect. -
Page 12: Washing Programs
• Do not carry out any preliminary rinsing. • If available, connect the dishwasher to a hot water supply up to 60°C. • When possible, skip the drying cycle by leaving the door open when the washing cycle is complete; the air and the residual heat will dry the dishes perfectly. -
Page 13: Operating Instructions
Before replacing the cap, remove any salt residues from around the opening. • When using the dishwasher for the first time, in addition to the salt it is also necessary to add one litre of water to the container. •... -
Page 14: Adjusting The Water Softening System
ADJUSTING THE WATER SOFTENING SYSTEM The dishwasher is equipped with an device for the user to adjust the water softening system according to the hardness of the water supply. -
Page 15: Using The Rinse Aid And Detergent Dispensers
User instructions WATER HARDNESS TABLE WATER HARDNESS German Degrees (°dH) French Degrees (°dF) 0 - 4 0 - 7 5 - 9 8 - 15 10 - 17 16 - 30 18 - 26 31 - 45 27 - 35 46 - 60 36 - 47 61 - 80... -
Page 16: Adding The Rinse Aid
ADJUSTING THE RINSE AID DISPENSER SETTING The dishwasher is factory set for medium water hardness. However it possible to change the setting by turning the dispenser’s selector to the desired position: the amount of rinse aid dispensed is proportional to the selector position. -
Page 17: Adding The Detergent
• Do not use detergents formulated for washing dishes by hand, because they produce a great deal of foam and may negatively affect the operation of the dishwasher. • Add the correct amount of detergent. An insufficient amount of detergent will result in a partial removal of dirt from the dishes, whereas an excessive amount is wasteful and does not improve the washing results. - Page 18 - not enough detergent released during the cycle, with poor washing results; - the detergent forms a solid block in the distributor and is released during the final rinse cycle. The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. more easily...
-
Page 19: General Warnings And Recommendations
User instructions 4.3 General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading. There are generally no constraints on the washing of domestic dishes, but in certain cases it is necessary to take their characteristics into account. - Page 20 • Glass and crystal: in general, glass and crystal objects can be washed in the dishwasher. However, certain types of glass and crystal may become dull and lose their clearness after many washings. Therefore, for these items we recommend using the least aggressive program available.
-
Page 21: Loading The Lower Basket
User instructions 4.4 Using the baskets The dishwasher has a capacity of 9 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling. -
Page 22: Cutlery Basket
User instructions CUTLERY BASKET The cutlery should be arranged in an orderly manner inside the basket, with the handles pointing downwards. Take care during loading to avoid injury from the knife blades. The basket is suitable for all types of cutlery, except those long enough to interfere with the upper spray arm. -
Page 23: Loading The Upper Basket
User instructions LOADING THE UPPER BASKET Load plates facing forward; cups, bowls etc. must always be facing downwards. The left-hand side of the basket can be loaded with two layers of cups and glasses. The centre can be filled with plates and side- plates, fitted upright into the supports provided. -
Page 24: Cleaning And Maintenance
5.1 General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces. Clean the door gaskets with a damp sponge. -
Page 25: Cleaning The Filter Unit
The filters should be cleaned under running water using a stiff brush. • It is essential to thoroughly clean the filters according to the above instructions: the dishwasher cannot function if the filters are clogged. • Carefully replace the filters in their seats, to avoid damaging the wash pump. - Page 26 In some cases it is possible to remedy minor problems by referring to the following instructions: If the program fails to start, check that: • the dishwasher is connected to the electrical power supply; • there is no power failure; •...
-
Page 27: Troubleshooting
User instructions If the dishes fail to dry or remain dull, check that: • there is rinse aid inside the special container; • the rinse aid dispenser setting is correct; • the detergent used is of good quality and has not lost its effectiveness (for example, through incorrect storage, with the box left open). -
Page 28: Troubleshooting
User instructions 6. Troubleshooting In case of a malfunction, the dishwasher will identify the program by switching on a combination of lights. When an alrm is present, PROGRAMS lights (4) come on, while the PROGRAM PHASES lights (7) identify the error code:... - Page 29 User instructions TECHNICAL DATA Width Depth measured flush with the outer edge of the control panel Height Capacity Water supply pressure Electrical characteristics 447 ÷ 449 mm Free standing: 600 mm Semi-integrated: 590 mm Free standing from 850 mm to 870 mm Semi-integrated from 820 mm to 870 mm 9 Standard place settings min.
- Page 30 820- 820- 1/2” S N SF 3/4” 0,3-10 bar 0,3-10 bar 1,14 m 1,14 m 1,23 m 1,23 m 1,78 m 1,78 m 0,3-10 bar 0,3-10 bar 1,25 m 1,25 m 1,50 m 1,50 m 1,66 m 1,66 m 3x16 820- 820-...
- Page 31 Superficie interna Superficie interna Surface interne Surface interne Inner surface Inner surface Innenfläche Innenfläche Lato superiore Lato superiore Bord supérieure Bord supérieure Upper edge Upper edge Oberkante Oberkante...
