RH850 Evaluation Platform
RH850/P1H-C,
RH850/P1M-C -
32
292BGA
PiggyBack board
Y-RH850-P1XC-292PIN-PB-T1-V1
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
website (http://www.renesas.com).
www.renesas.com
R20UT3314ED0100, Rev. 1.0
2015-01-19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Renesas RH850/P1H-C
Summary of Contents for Renesas RH850/P1H-C
- Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
-
Page 2: Table Of Contents
Table of Contents Chapter 1 Introduction ................. 3 Chapter 2 Overview ................4 Overview ....................4 Mounting of the device ................ 5 Chapter 3 Power supply ............... 6 Board power connection ..............6 Voltage distribution ................7 Chapter 4 Clock sources ..............9 4.1.1 MainOsc ......................... -
Page 3: Chapter 1 Introduction
Chapter 1 Introduction The RH850/P1H-C and RH850/P1M-C Application Board is part of the RH850 Evaluation Platform and serves as a simple and easy to use platform for evaluating the features and performance of Renesas Electronics 32-bit RH850/P1H-C and RH850/P1M-C microcontrollers in a BGA292 package. The PiggyBack board (Y-RH850-P1XC-292PIN-PB-T1-V1) can be used as a standalone board, or can be mated with a mainboard (e.g. -
Page 4: Chapter 2 Overview
Chapter 2 Overview Overview Figures 1 and 2 provide a schematic view of the PiggyBack board. Figure 1 PiggyBack Board Schematic Top View The black arrow denotes the position of socket pin #1. Figure 2 PiggyBack Board Schematic Bottom View R20UT3314ED0100 Rev. -
Page 5: Mounting Of The Device
Mounting of the device The board is designed for use with the following devices: RH850/P1H-C in BGA292 package and RH850/P1M-C in BGA292 package The device must be placed inside the socket IC1. To insert the device align the corner of the device package marked with a white triangle (see picture below) with the #1pin of the socket. -
Page 6: Chapter 3 Power Supply
Chapter 3 Power supply Board power connection For operation of the device, a supply voltage must be connected to the board. There are several possibilities to power the device. Within this document the following voltages are considered as ‘typical’ connections: Voltage1 = 3.3V Voltage2 = 1.25V Direct voltage supply... -
Page 7: Voltage Distribution
Voltage distribution The table shows the required device power supply pins and their function. For detailed explanation of their function, please refer to the user documentation of the corresponding device: Device Supply Pin SYSVCC EnVCC (n = 0, 1) AnVCC (n = 0, 1) AnVREFH (n = 0, 1) VDD (VCL) Additional one power supply for the MainBoard can be selected:... - Page 8 CAUTION: Jumper JP12 must not be connected in case of an eVR device. In this case the connected pins function as VCL pins and must not be supplied with a voltage. R20UT3314ED0100 Rev. 1.0 2015-01-19...
-
Page 9: Chapter 4 Clock Sources
Chapter 4 Clock sources One external crystal oscillator for the device clock supply is provided with the board. 4.1.1 MainOsc A crystal or ceramic resonator can be mounted on socket X1. A 16Mhz oscillator is supplied with the board. 4.1.2 Programmable Oscillator It is possible to mount a programmable crystal oscillator on the PiggyBack board at OSC1. -
Page 10: Chapter 5 Debug And Programming Interface
Chapter 5 Debug and Programming interface For connection of the microcontroller debug and flash programming tools, the connector CN25 with fourteen pins is provided. The signal connection of the connector CN25 is shown in the table below: CN25 Pin Device Port Device Signal JP0_2 TCK / LPDCLK / FLSCI3SCKI... -
Page 11: Chapter 6 Connectors For Ports Of Device
Chapter 6 Connectors for ports of device Connection to each functional pin of the devices is possible via the connectors CN5 to CN8. Some functions might not be available for every device. Therefore, please refer to the corresponding User’s Manual for available pins on the used device, and a detailed explanation of their function. -
Page 12: Connectors To Mainboard
Note: Pin 1 of the jumpers is marked by a small circle. CAUTION: Be careful in configuration of mode related pins, as wrong configuration can cause irregular behaviour of the devices. Be sure to check the corresponding User Manual, for details, which modes can be selected for the used device. -
Page 13: Connector Cn1
Function on Function on Device Port Device Port MainBoard MainBoard ETH0RXD2 P4_5 EH0TXD2 P3_12 ETH0RXD3 P4_6 EH0TXD3 P3_13 ETH0RXDCLK P4_2 ETH0TXCLK P4_1 ETH0RXER P4_0 ETH0TXER P3_8 ETH0CRSDV P3_7 ETH0TXEN P3_14 ETH0RXDV P4_7 ETH0COL P3_5 ETH0RESET P3_0 ETH0LINK P3_1 DIGIO_0 P6_0 DIGIO_1 P6_1 DIGIO_2... - Page 14 Function on Function on Device Port Device Port MainBoard MainBoard LIN2TX P7_5 LIN3TX P9_1 LIN2RX P7_4 LIN3RX P9_2 R20UT3314ED0100 Rev. 1.0 2015-01-19...
- Page 15 Function on Function on Device Port Device Port MainBoard MainBoard R20UT3314ED0100 Rev. 1.0 2015-01-19...
-
Page 16: Chapter 7 Other Circuitry
Chapter 7 Other circuitry Signalling for CVMOUTZ and ERROROUTZ Two red LEDs, LED1 and LED4 are available two indicate a “low” output signal from CVMOUTZ and ERROROUTZ, respectively. Pin Headers for Pull-Down and Pull-Up A connector CN9 is available to enable easy connection to Voltage1 (3.3V) or GND via pull-up or pull-down resistances, respectively. -
Page 17: Chapter 8 Precautions
Chapter 8 Precautions No limitations are known at the release of this document. R20UT3314ED0100 Rev. 1.0 2015-01-19... -
Page 18: Chapter 9 Mechanical Dimensions
Chapter 9 Mechanical dimensions 100.00mm. 50.00mm. R20UT3314ED0100 Rev. 1.0 2015-01-19... -
Page 19: Chapter 10 Schematic
Chapter 10 Schematic CAUTION: The schematic shown in this document is not intended to be used as a reference for mass production. Any usage in an application design is in sole responsibility of the customer. The following components described in the schematic are not provided with the board: ... - Page 20 R20UT3314ED0100 Rev. 1.0 2015-01-19...
- Page 21 R20UT3314ED0100 Rev. 1.0 2015-01-19...
- Page 22 R20UT3314ED0100 Rev. 1.0 2015-01-19...
-
Page 23: Chapter 11 Revision History
Chapter 11 Revision History The table provides information about the major changes of the document versions. Date Version Description 2015-01-19 Initial release R20UT3314ED0100 Rev. 1.0 2015-01-19... - Page 24 "Specific" without the prior written consent of Renesas Electronics. Further, you may not use any Renesas Electronics product for any application for which it is not intended without the prior written consent of Renesas Electronics. Renesas Electronics shall not be in any way liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for an application categorized as "Specific"...
