9350/9450/9550 Sport
P935/P945/P955
9400
TYPE EC27--
OWNER'S MANUAL
|
|
ENGLISH
FRANÇAIS
ESPAÑOL
WARNING
FOR YOUR SAFETY - For anything other than the routine cleaning and maintenance described in this manual, this product must be serviced
by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state
or local requirements exist. In the event no such state or local requirement exists, the maintainer must be a professional with sufficient
experience in pool equipment installation and maintenance so that all of the instructions in this manual can be followed exactly. Improper
installation and/or operation will void the warranty.
AVERTISSEMENT
POUR VOTRE SÉCURITÉ – Pour toute opération autre que l'entretien de routine et la maintenance décrite dans ce manuel, ce produit doit
être pris en charge par une entreprise qui est autorisée et qualifiée pour la réparation des équipements de piscine par la juridiction où le
dit produit est installé lorsque de telles exigences locales ou provinciales sont édictées. Si aucune exigence locale ou provinciale n'est
disponible, l'agent d'entretien doit être un professionnel avec suffisamment d'expérience dans l'installation et la maintenance d'équipement
de piscine pour appliquer correctement les consignes du présent manuel. L'installation ou l'utilisation inappropriée annulera la garantie.
ADVERTENCIA
PARA SU SEGURIDAD – Este producto debe ser instalado y mantenido por un contratista que está autorizado y calificado en equipo de
piscina en las jurisdicción en la que el producto se instala donde existan requisitos estatales o locales. En el caso de ningún estado o
locales obligatorio, el responsable debe ser un profesional con experiencia suficiente en la piscina de la instalación y mantenimiento de
equipo para que todas las instrucciones en este manual puede ser seguido exactamente. Antes de instalar este producto, lea y siga todas
las advertencias y las instrucciones qu acompañan a este producto. El incumplimiento de los avisos de advertencia e instrucciones puede
resultar en daños a la propiedad, lesiones personales o la muerte. La instalación y/o operación se anulará la garantía.
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Polaris EC27
Summary of Contents for Polaris EC27
- Page 1 9350/9450/9550 Sport P935/P945/P955 9400 TYPE EC27-- OWNER’S MANUAL ENGLISH FRANÇAIS ESPAÑOL WARNING FOR YOUR SAFETY - For anything other than the routine cleaning and maintenance described in this manual, this product must be serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exist.
-
Page 2: Table Of Contents
(9450 Sport/P945 and 9550 Sport/P955) ..23 THANK YOU FOR PURCHASING THE POLARIS CLEANER. YOUR POLARIS ROBOTIC CLEANER HAS BEEN DESIGNED AND MANUFACTURED TO BE EASILY INSTALLED AND TO PROVIDE LOW MAINTENANCE OPERATION. PRIOR TO INSTALLING YOUR NEW POLARIS CLEANER, PLEASE DO THE FOLLOWING: Complete and return the warranty card. -
Page 3: Fcc Statement
Page 3 FCC Statement This device complies with Part 15 of the FCC Rules and IC licence-exempt RSS standard. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Section 1. Important Safety Instructions
• Do not bury cord. Locate cord so as to prevent it from being damaged by lawn mowers, hedge trimmers and other equipment. • To reduce the risk of electrical shock, do not use the Polaris robotic cleaner or control unit if the cord is worn or damaged. Contact Zodiac Pool Systems, Inc. -
Page 5: Section 2. Cleaner Specifications
Unscrew the handnut from the base unit (Figure 2). Section 3. Assembly Unpacking The packaging should contain the following items: • Polaris cleaner • Control unit • Remote Control (9550 Sport/ P955 only) • Transport and storage caddy assembly components... - Page 6 Page 6 Push base unit down (Figure 3) so the metal handle frame is seated in the recess on the underside of the base. Figure 5. Snap in Support Blocks and Attach Wheels Slide the control unit base / caddy handle attachment down over the metal tubing until it snaps into place.
-
Page 7: Connecting The Control Unit To The Caddy
Page 7 Align cleaner hook pins with the top holes in the handle tube and snap into place (Figure 7). Figure 7. Snap Cleaner Hook into Place Figure 9. Fully Assembled Transport Caddy Locate pin on the remote (9550 Sport/P955) Connecting the Control Unit to the control holder and align it with the recepticle Caddy... -
Page 8: Connecting To Power Source
Page 8 Figure 12. Remove Protective Cap Figure 11. Attach the Control Unit onto Caddy Connecting to a Power Source WARNING Failure to comply with the following warnings can result in permanent injury, electrocution or drowning. PREVENT ELECTRICAL SHOCK • U.S.: Per NEC requirements, keep the control unit ®... -
Page 9: Section 4. Operation
(see Figure 17). The Polaris robotic cleaner includes a safety feature that automatically stops the cleaner if it is powered on but not submerged in water. For pools equipped with a... -
Page 10: The Polaris 9350/P935 Cleaner Control Unit
Pool Cleaner Error Indicator Start/Stop Cleaner Operation Select Cleaning Surface • Bottom • Bottom and Sides The Polaris 9450 Sport/P945 Cleaner Control Unit Navigate Day/Hour Display Current Time/ Set Time Validate Time Setting Selection Program Cleaning Cycles / Set Time... -
Page 11: The Polaris 9550 Sport/P955 Cleaner Control Unit
• Bottom and Sides • Waterline only Starting the Cleaner Select Pool Shape (9550 Sport/P955 only): The default cleaning surface setting for the Polaris cleaners is Bottom Surface . To change the to choose pool shape. current programmed cycle, see Section 5. Programming the Cleaner. -
Page 12: Stopping The Cleaner And Removing From The Pool
Remote Control ( 9550 Sport/P955 only The automated Lift System makes removing the cleaner The Polaris 9550 Sport and P955 robotic cleaner comes from the pool simple. The Lift System will move the with a handheld remote control stored on the cleaner cleaner toward the edge of the pool then drive it to the caddy next to the control unit. -
Page 13: Synchronizing The Remote Control
Page 13 • To remove the cleaner from the pool using the remote control, press (see Figure 20). Synchronizing the Remote Control Even though the remote control is factory-synchronized to your cleaner's control unit, it may be necessary to synchronize again if you need to replace either the control unit or the remote control. -
Page 14: Section 5. Programming The Cleaner
Page 14 Section 5. Programming the NOTE: Control unit is set to display time in 24-hour clock format. Time setting will cycle through 1-24. Cleaner (9450 Sport/P945 and 9550 Sport/P955 only) Press to select. You can program up to seven preset cleaning cycles to run the cleaner on a specific day and time when you are away from the pool. -
Page 15: Programming Cleaning Cycles
Page 15 Programming Cleaning Cycles Press to select. You can program up to seven cleaning cycles. Program cleaning for either seven consecutive cycles or the same cycle repeated over several weeks (e.g., every Wednesday and Saturday for three weeks). Choose pool cleaning settings to program. Minutes setting flashes zero. -
Page 16: Section 6. Cleaning And Maintenance
Page 16 Section 6. Cleaning and Press and hold for 3 to 5 seconds to Maintenance delete programming for the selected day. Press to exit. WARNING To avoid electric shock and other hazards which To Cancel All Programs: could result in permanent injury or death, disconnect (unplug) the cleaner from the power source before performing any cleaning and maintenance. -
Page 17: Cord Tangling
Page 17 Figure 28. Wash Filter Canister Figure 25. Remove Filter Canister Assembly Push the quick release button on the canister assembly (4) and pull open the filter assembly (5), as shown in Figure 26. 6.2. Cord Tangling Tangling can occur more frequently when operating the cleaner on the automatic timer 7-Day Programmed Cycle (9450/P945 and 9550/P955). -
Page 18: Replacing The Brushes
Page 18 Remove filter canister and rinse with clean IMPORTANT water. Plug power cord back into control unit Cleaner power cable may become tangled if correct and store cleaner for next use. procedure is not followed after each cleaning cycle. Replacing the Brushes The cleaner is fitted with PVC brushes. There are ''wear'' indicators on the brushes (Figure 29). To After every cleaning cycle: maintain cleaner performance at its best you need to replace the brushes as soon as one of the wear... -
Page 19: Replacing The Tires
Page 19 Figure 31. Undo the Tabs of the Brush Figure 34. Cut Tabs To install a new brush, position the new Repeat this procedure to install the second brush on the roller with the spikes facing brush. downwards (Figure 32). Replacing the Tires Pull on the inside of the old tire to remove the tire lip from the wheel (Figure 35). -
Page 20: Section 7. Spare Parts
(Figure 38). Section 7. Spare Parts The complete spare parts list and exploded view is available on the Polaris website at www.polarispool.com. In Canada, parts list and exploded view is available at www.polarispool.ca Figure 38. Start on One Side of the Tire... -
Page 21: Section 8. Troubleshooting
Check brushes for debris. Start a new cleaning cycle. If the problem is not resolved through troubleshooting, first contact your local retailer to request a diagnostic review, or contact Polaris Technical Support at (USA) 1-800-822-7933. LED flashes three times with one Check the pump axis for debris. -
Page 22: General Troubleshooting
20 seconds before reconnecting. If the problem cannot be resolved through troubleshooting, first contact your local retailer to request a diagnostic review, then contact Polaris Technical Support at (USA) 1-800-822-7933. Cable is tangling in the pool Too much cable length in the water. -
Page 23: Control Unit Error Codes (9450 Sport/P945 And 9550 Sport/P955)
• If problem is not resolved through troubleshooting, contact Polaris Technical Support at (USA) 1-800-822-7933. Pump motor overconsumption • Check for small debris or hair in the fan. - Page 24 Zodiac Pool Systems, Inc. 2620 Commerce Way, Vista, CA 92081 1.800.822.7933 | www.ZodiacPoolSystems.com Zodiac Pool Systems Canada, Inc. 2115 South Service Road West, Unit 3 Oakville, Ontario • Canada L6L 5W2 1.888.647.4004 | www.ZodiacPoolSystems.ca ZODIAC is a registered trademark of Zodiac International, S.A.S.U., used under license. ®...
