SERVICE MANUAL
TECHNICAL INFORMATION
FOR SERVICE PERSONNEL ONLY
RAF-25NH5
RAF-35NH5
RAF-50NH5
RAK-65NH5
RAI-25NH5
RAI-35NH5
RAI-50NH5
SPECIFICATIONS
TYPE
MODEL
POWER SOURCE
TOTAL INPUT
TOTAL AMPERES
COOLING CAPACITY
HEATING CAPACITY
DIMENSIONS
NET WEIGHT
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
ROOM AIR CONDITIONER
JANUARY 2006
RAD-25NH5
RAD-35NH5
RAK-18NH5, RAK-25NH5
RAK-35NH5, RAK-50NH5
RAM-72QH5
RAK-18NH5
RAK-25NH5
RAK-35NH5
RAK-50NH5
(W)
(A)
(kW)
(B.T.U.)
W
780
(mm)
H
280
D
210
(kg)
9.5
INDOOR UNIT + OUTDOOR UNIT
https://splitsystema48.ru/instrukcii-po-ekspluatacii-kondicionerov.html
,
Refrigeration & Air-Conditioning Division
PM
RAK-18NH5, RAK-25NH5,
RAK-35NH5, RAK-50NH5,
RAK-65NH5,
RAI-25NH5, RAI-35NH5,
RAI-50NH5
RAF-25NH5, RAF-35NH5,
RAF-50NH5,
RAD-25NH5, RAD-35NH5
REFER TO THE FOUNDATION MANUAL
SPECIFICATIONS ------------------------------------------------------------------- 5
FEATURES -------------------------------------------------------------------------- 17
HOW TO USE ---------------------------------------------------------------------- 21
INSTALLATION --------------------------------------------------------------------- 45
CONSTRUCTION AND DIMENSIONAL DIAGRAM --------------------- 49
MAIN PARTS COMPONENT --------------------------------------------------- 55
WIRING DIAGRAM ---------------------------------------------------------------- 61
CIRCUIT DIAGRAM --------------------------------------------------------------- 67
BLOCK DIAGRAM ----------------------------------------------------------------- 81
BASIC MODE ----------------------------------------------------------------------- 85
REFRIGERATING CYCLE DIAGRAM -------------------------------------- 109
DESCRIPTION OF MAIN CIRCUIT OPERATION ---------------------- 113
TROUBLE SHOOTING ---------------------------------------------------------- 136
SERVICE CALL Q & A --------------------------------------------------------- 185
DISASSEMBLY AND REASSEMBLY --------------------------------------- 201
PARTS LIST AND DIAGRAM ------------------------------------------------- 210
DC INVERTER DUAL SYSTEM MULTI
INDOOR UNIT
RAK-65NH5
RAI-25NH5
RAI-35NH5
RAI-50NH5
1ø, 220 - 240V, 50Hz
REFER TO THE SPECIFICATIONS PAGE
1030
580
295
285
191
580
12.0
20.0
,
NO. 0322E
RAM-72QH5
CONTENTS
OUTDOOR UNIT
RAM-72QH5
RAF-25NH5
RAD-25NH5
RAF-35NH5
RAD-35NH5
RAF-50NH5
750
750
600
235
215
400
15.0
14.0
After installation
,
.
850
800
298
52
