The PSR6000-ACV power module provides system power and PoE power. In Figure 1-17 the switch
indicated by callout 6 is used to control the system power and the socket indicated by callout 5 is used
for system power input, while the switch indicated by callout 2 is used to control the PoE power and the
sockets indicated by callout 8 are used for PoE power inputs.
To provide PoE power by the PSR6000-ACV, you need to
Switch on the system power and make sure that the system power output is normal
Switch on the PoE power and make sure that one of the three PoE power inputs is alive
The PoE output power of the PSR6000-ACV depends on the number of PoE power inputs that are
selected as needed. For detailed technical specifications, refer to Table 1-13.
If the system power input and multiple PoE power inputs are used at the same time, the input
voltage must be the same, that is, either 110 VAC or 220 VAC, but not be intermixed.
Keep the PoE switch in the off position unless the device is equipped with appropriate PoE-capable
cards and needs to offer PoE supply.
On the right of the panel are the system power input LED (SYS IN), system power output LED (SYS
OUT), system power fan LED (SYS FAN), PoE input LEDs (PoE IN1, PoE IN2, and PoE IN3), PoE
output LED (PoE OUT), and PoE power fan LED (PoE FAN). For the descriptions of these LEDs, refer
to section 7.2.6 "Troubleshooting PSR6000-ACV."
Table 1-13 Technical specifications of the PSR6000-ACV power module
Item
Rated voltage range
Maximum input current for each socket
Maximum system output current
Maximum PoE output current
Maximum system output power
Maximum PoE
output power
Dimensions (H × W × D)
Operating temperature
Storage temperature
100 VAC to 240 VAC, 50 Hz or 60 Hz
16 A
117 A
100 A
1150 W (110 VAC)
1400 W (220 VAC)
1200 W (110 VAC)
One PoE input
1800 W (220 VAC)
2400 W (110 VAC)
Two PoE inputs
3600 W (220 VAC)
3600 W (110 VAC)
Three PoE inputs
5300 W (220 VAC)
128 × 196 × 380 mm (5.04 × 7.72 × 14.96 in.)
0°C to 45°C (32°F to 113°F)
–40°C to +70°C (–40°F to +158°F)
