INSTALLATION INSTRUCTIONS
R- -410A Single Package Electric Cooling
These instructions must be read and understood completely before attempting installation
DANGER, WARNING, CAUTION, and NOTE
The signal words DANGER, WARNING,
CAUTION, and NOTE are used to identify levels
of hazard seriousness. The signal word DANGER
is only used on product labels to signify an
immediate hazard. The signal words WARNING,
CAUTION, and NOTE will be used on product
labels and throughout this manual and other
manual that may apply to the product.
DANGER -- Immediate hazards which will result in
severe personal injury or death.
WARNING --Hazards or unsafe practices which
could result in severe personal injury or death.
CAUTION -- Hazards or unsafe practices which
may result in minor personal injury or product or
property damage.
NOTE -- Used to highlight suggestions which will
result in enhanced installation, reliability, or
operation.

TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
PAD424- -60
1 & 3 Phase
Safety Labeling and Signal Words
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . . . . . .
Signal Words in Manuals
The signal word WARNING is used throughout
this manual in the following manner:
WARNING
!
The signal word CAUTION is used throughout
this manual in the following manner:
CAUTION
!
Signal Words on Product Labeling
Signal words are used in combination with
colors and/or pictures or product labels.
WARNING
!
2
2
PERSONAL INJURY, AND/OR PROPERTY
2
DAMAGE HAZARD
2
Failure to carefully read and follow this warning
could result in equipment malfunction, property
3
damage, personal injury and/or death.
3
Installation or repairs made by unqualified
3
persons could result in equipment malfunction,
7
property damage, personal injury and/or death.
7
The information contained in this manual is
9
intended for use by a qualified service technician
11
familiar with safety procedures and equipped
11
with proper tools and test instruments.
11
Installation must conform with local building
codes and with the national Electrical Code
12
NFPA70 current edition or Canadian Electrical
13
Code part 1 CSA C.22.1.
15
22
25
27
519 01 1803 00
04/21/10
