14 seer single--packaged air conditioner system with r--410a refrigerant single phase 2--5 nominal tons (sizes 24-60) three phase 3-5 tons (sizes 36-60) (38 pages)
Page 1
2-5 Nominal Tons (Sizes 24-60) Owner’s Information Manual A09034 Fig. 1 – Unit PAR5 NOTE TO EQUIPMENT OWNER: For your convience, please record the model and serial numbers of your new equipment in the spaces provided. This information, along with the installation data and dealer contact information, will be helpful should your system require maintenance or service.
PAR5: Owner’s Information Manual Safety Considerations CAUTION Improper installation adjustment, alteration, service, maintenance, or use can cause explosion, fire, electrical shock, or other conditions which CUT HAZARD may cause death, personal injury, or property damage. Consult a Failure to follow this caution may result in personal injury.
Page 3
PAR5: Owner’s Information Manual To assure proper functioning of the unit, flow of condenser air must not CAUTION be obstructed from reaching the unit. Clearance from the top of the unit is 48 in. (1219 mm). Clearance of at least 36 in.(914 mm) is required on UNIT OPERATION HAZARD sides except the power entry side (42 in.
Page 4
PAR5: Owner’s Information Manual Warranty Certificate WARNING Your unit has a limited warranty. Be sure to read the warranty carefully to determine the coverage for your unit. EXPLOSION, BURN AND ENVIRONMENTAL HAZARD Before you call for service... Failure to follow this warning could result in personal injury, death or ...check for several easily-solved problems.
Page 5
PAR5: Owner’s Information Manual Table 2 – Maintenance Checklist Monthly maintenance items and outdoor unit rinsing may be performed by the consumer. All other maintenance items and all service work must be performed by a qualified service technician. Read all Warning labels.
