PA4G- -- -B,
PA4G- -- -C
For your convenience, please record the model and serial numbers of your new equipment in the spaces
provided. This information, along with the installation data and dealer contact information, will be helpful
should your system require maintenance or service.
UNIT INFORMATION
Model # _____________________________________
Serial # ______________________________________
ACCESSORIES (List type and model #)
_____________________________________________
_____________________________________________
_____________________________________________
Our products are designed, tested and built in accordance with DOE standardized procedures; however, actual operating results and
efficiencies may vary based on manufacturing and supplier tolerances, equipment configuration, operating conditions and installation
practices.
SINGLE ---PACKAGED AIR CONDITIONER SYSTEM
Owner's Guide
Fig. 1 - - Unit PA4G- -- -B, PA4G- -- -C
NOTE TO EQUIPMENT OWNER:
NOTE TO INSTALLER:
This manual must be left with the equipment owner.
WITH R ---410A REFRIGERANT
SINGLE AND THREE PHASE
2 TO 5 NOMINAL TONS
INSTALLATION INFORMATION
Date Installed ________________________________
DEALERSHIP CONTACT INFORMATION
Company Name_______________________________
Address______________________________________
_____________________________________________
Phone Number _______________________________
Technician Name _____________________________
_____________________________________________
1
14 SEER
SIZES 24 TO 60
A09183
