Summary of Contents for Simpsons NSPSC0800
- Page 1 NSPSC0800 CLICK SIDE PANEL NSPSC0900 NSPSC1000 INSTALLATION INSTRUCTIONS...
-
Page 2: Care And Cleaning
Check the contents of the pack carefully before installation. you do not fit the enclosure onto a tiled surface, or seal the tiles Simpsons will not be held responsible for any de-fit / re-fit costs to the tray before installation, water may soak into the wall behind the wall profiles. - Page 3 CONTENTS CLICK SIDE PANEL Sealing Strip x 1 M4 *40mm Screw x 4 Cover x 1 Steady x 1 Wall Plug x 7 Cover x 1 Waterproof Strip x 1 ST4 *40mm Screw x 3 Corner Part (LH)x 1 L=1906mm Corner Part(RH) x 1 Top Cover x 1 Magnetic Strip x 1...
- Page 4 Step 1 - FITTING AND POSITIONING WALL CHANNEL A (mm) PRODUCT Remove both wall channels from the glass panel frame. Place each wall channel in position on the tray (10 - 15mm in from the outer edge of the tray), 800 Hinge Door 770~790 use a spirit level to ensure that they are vertical and mark all 6 fixing holes...
- Page 5 Step 3 Fix the seals & handle. Step 4...
- Page 6 Step 5 Place wall bracket (N) in position Use a spirit level to check the level. Mark the hole positions on to the wall. Drill holes in the positions marked using a 6mm masonry drill bit. Insert wall plugs (B) into the two holes. (beyond the thickness of the tile).
- Page 7 Step 6 Step 7 1.5mm...
- Page 8 Step 8 For any further information please contact Simpsons on: 0845 873 5808 Or visit our web-site at www.simpsons-enclosures.co.uk The manufacturer reserves the right to make technical modifications without prior notice.
