Summary of Contents for Simpsons DBTSC1500
- Page 1 DBTSC1500 DESIGN TRIPLE PANE BATH SCREEN INSTALLATION INSTRUCTIONS...
-
Page 2: Care And Cleaning
Check the contents of the pack carefully before installation. Simpsons will not be held responsible for any de-fit / re-fit costs before installation, water may soak into the wall behind the wall where faulty product has been fitted. - Page 3 CONTENTS TRIPLE PANE BATH SCREEN M4 *50mm Screw x 6 Fixed Part x 1 Waterproof Strip x 1 Cover x 2 Waterproof Strip x 1 Wall Plug x 6 M4 *12mm Screw x 4 Mat x 1 Waterproof Strip x 2 Glass Clamp x 1 Allen Key 3mm x 1 Washer x 4...
- Page 4 Please follow diagram below for the correct assembly for Left or Right hand installation. Left - Assemble pivot door (LH) Ensure that the fixed panel with waterproof strip is positioned for assembly, so that the lip of the waterproof strip is going to be on the inside of the bath. Right - Assemble pivot door (RH) Ensure that the fixed panel with waterproof strip is positioned for assembly, so that the lip of the waterproof strip is going to be on the inside of the bath.
- Page 5 Step 1 - FITTING AND POSITIONING WALL CHANNEL Place wall channel in position on the bath (20mm in from the edge of the bath), use a spirit level to ensure that it is vertical, and mark all 4 fixing holes on the wall. Drill holes in the positions marked using a 6mm masonry drill bit.
- Page 6 Step 4 - FITTING THE BRACING BAR Place wall bracket (I) in position (Diagram “ ” for the detail position.) Use a spirit level to check the level. Mark the hole positions on to the wall. Drill holes in the positions marked using a 6mm masonry drill bit.
-
Page 7: Step 5 - Hinge Assembly
Step 5 - HINGE ASSEMBLY Fix Hinges to a glass door. Support door and fix hinges to pivot door. Do not fully tighten. Check that the door closes and that the top is aligned with the side panels. Fully tighten screws. Step 6 - FITTING SEALS Cut Line... - Page 8 Step 7 For any further information please contact Simpsons on: 0845 873 5808 Or visit our web-site at www.simpsons-enclosures.co.uk The manufacturer reserves the right to make technical modifications without prior notice.
