- Page 1 LUXURY CURVED QUADRANT S UPRE ME INSTALLATION INSTRUCTIONS...
- Page 2 Check the contents of the pack carefully before installation. MUST be level and fully sealed to the tiles before installation. If Simpsons will not be held responsible for any de-fit / re-fit costs you do not fit the enclosure onto a tiled surface, or seal the tiles where faulty product has been fitted.
- Page 3 CONTENTS CURVED QUADRANT Cover & cap x 4 Plastic clip x 4 Plastic plug x 12 Top roller x 4 Bottom roller x 4 Handle x 2 Magnetic seal x 2 Plastic strip x 2 Water seal x 4 Wide flap seal x 2 10mm Screw x 4 30mm Flat screw x 16 Narrow flap seal x 2...
- Page 4 LUXURY CURVED QUADRANT Step 1 Fix the top and bottom tracks to the first side profile using 4 x 30mm flat screws (C) as shown. Repeat with the second side profile. Ensure they are the correct way around, as shown below. Step 2 Slide the wall channels fully onto the frame side profiles.
- Page 5 LUXURY CURVED QUADRANT Step 3 Remove the frame from the tray and remove both wall channels from the frame. Place each wall channel in the marked position on the tray, use a spirit level to ensure they are vertical and mark all 8 fixing holes onto the walls. Drill holes in the positions marked using a 6.5mm masonry drill bit.
- Page 6 LUXURY CURVED QUADRANT Step 5 Inside Carefully position each side panel inside the enclosure. Insert the plastic strip (L) edge of the panels into the slot in the side profiles. Ensure the side panels fully insert and sit squarlly. From inside the enclosure, push fit a plastic clip (F) onto the top and bottom corners of the side panels as shown.
- Page 7 LUXURY CURVED QUADRANT Step 7 a: Inside the enclosure, hang the doors onto the top rail (ensure the magnetic seals are in the middle). b & c: Push the buttons down on the bottom rollers and position the rollers into the bottom rail and release the buttons.
- Page 8 FINISHING Apply lubricant (P) to the inside of the top and bottom tracks (where rollers make contact), wipe off any excess. For any further information please contact Simpsons on: 01483 303711 Or visit our web-site at: www.simpsons-enclosures.co.uk The manufacturer reserves the right to make technical...
