- Page 1 DBVSC1060 DESIGN VIEW BATH SCREEN INSTALLATION INSTRUCTIONS...
-
Page 2: Care And Cleaning
Simpsons will not be held responsible for any de-fit / re-fit costs profiles. where faulty product has been fitted. - Page 3 CONTENTS DESIGN VIEW BATH SCREEN Waterproof Strip x 1 Wall Profile Cover x 1 M4 *12mm Screw x 4 Cover x 4 Top Pivot Cover x 1 Waterproof Strip(LH) x 1 Top Pivot Kit (RH) x 1 M3.5 *25mm Screw x 4 Bottom Pivot Cover (LH) x 1 Bottom Pivot Kit (RH) x 1 Top Pivot x 1...
- Page 4 Please follow diagram below for the correct assembly for Left or Right hand installation. Left - Assemble pivot door (LH) Ensure that the fixed panel with waterproof strip is positioned for assembly, so that the lip of the waterproof strip is going to be on the inside of the bath. Right - Assemble pivot door (RH) Ensure that the fixed panel with waterproof strip is positioned for assembly, so that the lip of the waterproof strip is going to be on the inside of the bath.
- Page 5 Step 1 - FITTING AND POSITIONING WALL CHANNEL Place wall channel in position on the bath (20mm in from the edge of the bath), use a spirit level to ensure that it is vertical, and mark all 4 fixing holes on the wall. Drill holes in the positions marked using a 6mm masonry drill bit.
-
Page 6: Step 4 - Hinge Assembly
Step 4 - HINGE ASSEMBLY Fix hinges to the pivot door. Support the pivot door and fix hinges to the remaining glass panel. Do not fully tighten. Check that the door closes and that the 2 panels are fully aligned. Fully tighten screws. Step 5 - FITTING SEALS Inside Cut Line... - Page 7 Step 6 For any further information please contact Simpsons on: 0845 873 5808 Or visit our web-site at www.simpsons-enclosures.co.uk The manufacturer reserves the right to make technical modifications without prior notice.
