Summary of Contents for Simpsons DBDSC1060
- Page 1 DBDSC1060 DESIGN DOUBLE PANE BATH SCREEN INSTALLATION INSTRUCTIONS...
-
Page 2: Care And Cleaning
Check the contents of the pack carefully before installation. Simpsons will not be held responsible for any de-fit / re-fit costs before installation, water may soak into the wall behind the wall where faulty product has been fitted. -
Page 3: Tools And Equipment Needed
CONTENTS DOUBLE PANE BATH SCREEN M5 *30mm Screw x 6 Support Bar x 1 Wall Plug x 6 Fixed Part x 1 Waterproof Strip x 1 Cover x 2 M4 *12mm Screw x 4 Allen Key 3mm x 1 Mat x 1 Allen Key 4mm x 1 Washer x 4 Glass Clamp x 1... - Page 4 Please follow diagram below for the correct assembly for Left or Right hand installation. Left - Assemble pivot door (LH) Ensure that the fixed panel with waterproof strip is positioned for assembly, so that the lip of the waterproof strip is going to be on the inside of the bath. Right - Assemble pivot door (RH) Ensure that the fixed panel with waterproof strip is positioned for assembly, so that the lip of the waterproof strip is going to be on the inside of the bath.
- Page 5 Step 1 - FITTING AND POSITIONING WALL CHANNEL Place wall channel in position on the bath (20mm in from the edge of the bath), use a spirit level to ensure that it is vertical, and mark all 4 fixing holes on the wall. Drill holes in the positions marked using a 6mm masonry drill bit.
- Page 6 Step 4 - FITTING THE BRACING BAR Place wall bracket (I) in position (Diagram “ ” for the detail position.) Use a spirit level to check the level. Mark the hole positions on to the wall. Drill holes in the positions marked using a 6mm masonry drill bit.
- Page 7 Step 5 For any further information please contact Simpsons on: 01483 303711 Or visit our web-site at www.simpsons-enclosures.co.uk The manufacturer reserves the right to make technical modifications without prior notice.
