  • Page 1 Installation and Owners Manual Keep these instructions for future reference Freestanding Phoenix Inbuilt Masonry Insulated Zero Clearance Manual version 2025-4-v1...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these instructions may result in a fire hazard and will void the warranty. Compliance Components Dimensions Installation Flue and Venting Operating Instructions Warranty Information Visionline Phoenix...
  • Page 3: Compliance

    Compliance As/NZS 4012/4013 General Installation...
  • Page 4 This appliance has been TESTED TO AS/NZS4013 for Hardwood by ASFT Report 21076 Date tested: 29 SEPTEMBER 2021 not followed exactly, a fire could result causing property damage, personal VisionLINE Phoenix Freestanding and Inbuilt injury, or death. OVERALL AVERAGE EFFICIENCY WHEN TESTED IN ACCORDANCE WITH AS/NZS 4012 ..61%...
  • Page 5: Getting Started

    It is a good idea to plan your installation on paper, using escape routes. exact measurements for clearances and floor protection, VisionLINE ASSUMES NO RESPONSIBILITY FOR THE before actually beginning the installation. If you are not 5. A plan to deal with a chimney fire as follows: In the...
  • Page 6 Installation and use of any damaged appliance. • Modification of the appliance. • Do NOT install damaged components. • Installation other than as instructed by VisionLINE fireplaces. • Do NOT install incomplete components. • Installation and/or use of any component part not approved by •...
  • Page 7: Components

    Components Phoenix Freestanding Phoenix Inbuilt- Zero Clearance Phoenix ZC Flue...
  • Page 8 2. Components - Phoenix Freestanding Phoenix Inbuilt - Zero Clearance NCLUDED OR NCLUDED OR RODUCT ESCRIPTION RODUCT ESCRIPTION OPTION OPTION PHOENIX Phoenix wood stove PHOENIX Phoenix wood stove Phoenix wood storage Phoenix insulated PED-PHOENIX Option ZC-INPH required pedestal zero clearance case...
  • Page 9: Vent Options

    2. Components - Phoenix Inbuilt - Zero Clearance RELIEF VENT KITS DESCRIPTION COMPRISING VENT OPTIONS Phoenix ZC REG Relief INPH-FRVK Forward Facing Vent Vent kit - FWD Facing The insulated zero clearance box requires relief venting (in and out) for the zero clearance box and 2x 540-900mm adjustable pipe chimney breast.
  • Page 10 2. Components - Phoenix ZC flue Product Code Description VFKIT6-ZC1 VFKIT6-ZC1 - INSULATED ZC AFETY ENT KIT ONLY XTRA OMPONENTS VF-3-60-201 AIR FLUE 6" SAFETY VENT 250MM VF-3-60-202 AIR FLUE 6" SAFETY VENT 500MM VF-3-60-203 AIR FLUE 6" SAFETY VENT 1000MM VF-3-60-245 AIR FLUE 6"...
  • Page 11: Dimensions

    Dimensions Unit and Base Zero Clearance Case Relief Vents...
  • Page 12 FLUE SPIGOT 147.8mm Note: • The Phoenix Firebox weighs approx. 270kg including base. • To safely lift the unit on the base for positioning, the unit should be stripped of as much weight as possible by removing all bricks and the door assembly.
  • Page 13 3. Dimensions - Zero clearance case Safety vent twist Lock Flue ONLY Relief vents Zero box ventilation DO NOT COVER Page 13 Visionline Phoenix...
  • Page 14 3. Dimensions - Relief Vents Front Rear ZC-IN-LVPH ZC-IN-SV ZC-IN-IV Forward facing vent Side facing vent - 2x required Side intake vent - 2x required Page 14 Visionline Phoenix...
  • Page 15: Installation

    Installation Hearth and Clearances FS Rear Heat Shield Hearth and Clearances Inbuilt ZC Framing for Insulated ZC Assembly of Insulated ZC Masonry Insert Consideration...
  • Page 16 4. Installation - Hearth and Clearances - Freestanding The VisionLINE Phoenix may require an insulating Floor Protector depending on the Minimum depth (F) will mean there is space behind the appliance where a floor protector installation type. It is tested and complies with the minimum Floor Protector requirements isn’t required but may be desired aesthetically.
  • Page 17 Additional rear unit heat shield must be installed unless against a non-combustible wall. 8” MESH 8” SOLID PHOENIX - C ORNER POSITIONING CASING CASING LEARANCE FROM FIREBOX TO CORNER WALL IN DEPTH OF FLOOR PROTECTOR ISTANCE FROM FIREBOX OPENING TO FLOOR PROTECTOR...
  • Page 18 If optional fans are used, ensure there is provision for 2x power points. Power cord The Phoenix can be connected to outside air via the central air intake at the rear or base requires a single 240v 10amp GPO each.
  • Page 19 4. Installation INSTALLING REAR HEAT SHIELD VisionLINE Taurus shown; instructions and images still applicable for Phoenix • Remove the 4x 10mm bolts holding the internal shield onto the fireplace and place (inner surface up) on a flat working surface. Ensure to retain the 10mm bolts to re-install.
  • Page 20 4. Installation - Hearth and Clearance - Inbuilt ZC The Phoenix Inbuilt and Zero Clearance box must only be installed with a Visionline Maintain the following clearances to combustible material from the zero clearance box; Safety Vent Air (6”) flue kit. Refer to page 26 for these instructions.
  • Page 21: Timber Framing

    Avoid light coloured paint finishes as it can lead to smoke and heat staining from normal use. *Note: For side exit relief venting, outer framing width should be no less than 1247mm PLAN VIEW *1247mm min for side exit relief venting to allow for kit configuration to fit. Page 21 Visionline Phoenix...
  • Page 22 4. Installation - Assembly of Insulated ZC 1. Position ZC box within cavity on top of 2. Position Phoenix into ZC case centrally. Mechanical lifting aids may be required to assist Cement sheet as per page 19 and secure Ensure outside air intake engages to channel at and safely install.
  • Page 23 It is recommended to have a minimum 5-10mm gap around the sides and top of the fireplace to the masonry structure for expansion and contraction. If not using the Phoenix FS base, this can be covered with a custom made trim if required.
  • Page 24: Flue And Venting

    Flue and Venting General Installation Insulated Zero Clearance Insulated ZC Relief Venting...
  • Page 25: Installing The Flue

    INSTALLING THE FLUE DEFAULT 6” FLUE KIT On All Visionline units, the flue seats over the flue spigot and will slide down and rest The following drawing is meant as a guide only. Your wood heater must be installed by a in the lower channel.
  • Page 26 General Instructions (above). Extend the flue pipe above the outer casing to suit the casing cover/cowl assembly. If the inner casing has not been installed, install now. Refer to 7 above for minimum height. Install the cowl assembly, i.e. Top spacer, casing cover and cowl. Page 26 Visionline Phoenix...
  • Page 27 1 & C WIST UPPORT EILING XAMPLE If elbows are required, use the supplied locking bands with elbow support kit VF-3-60-246. Additional internal and external support are available. Refer to the flue installation guide for completion. LBOW UPPORT Page 27 Visionline Phoenix...
  • Page 28 • Secure adjustable pipe once fitted to length with 3 stainless steel self tapping screws. Twist clockwise to lock Fill material Fix on lower section of pipe Page 28 Visionline Phoenix...
  • Page 29: Operating Instructions

    Operating Instructions Considerations General Operating Over-fire Warnings Cleaning and Inspection...
  • Page 30 BROKEN COMPONENTS, e.g. GLASS PANELS OR CERAMIC TILES, MAY A FUEL CAN BE HAZARDOUS. RENDER THE INSTALLATION UNSAFE. WARNING: ANY MODIFICATION OF THE APPLIANCE THAT HAS NOT BEEN APPROVED IN WRITING BY THE TESTING AUTHORITY IS CONSIDERED AS BREACHING AS/NZS 4013. Page 30 Visionline Phoenix...
  • Page 31 This occurs due to a VisionLINE fireplaces recommends the VisionLINE AIR insulated flue system to pressure imbalance when opening the door as cool air rushes in. Opening the flue damper create a balanced flue ensuring adequate air supply balance.
  • Page 32 Over-firing can be identified by a warped baffle bypass system as well as the baffle bypass cover shedding layers of steel. This is not covered by warranty. Crossflow rear baffle openings Baffle bypass (exhaust damper) Baffle bypass Secondary Air Do not block Primary air control Page 32 Visionline Phoenix...
  • Page 33 • The surface of the stove can be cleaned with a damp cloth or if necessary, with a mild soap solution. Touch up paint can be available from your nearest Visionline dealer. The Colour match is Anthracite Grey by PLP coatings.
  • Page 34 6. Operation instructions - Cleaning and inspection Internal rear baffle can be inspected via this plate Page 34 Visionline Phoenix...
  • Page 35: Warranty Information

    Warranty Information...
  • Page 36: Other Rights

    VisionLINE authorised dealer. The VisionLINE manufacturer’s warranty is in addition to other rights and remedies that VisionLINE warrants to the original owner of the VisionLINE appliance at the site of you may have under Australian law.
  • Page 37: How To Claim

    However, if you do not have your • Any part of a pre-existing fireplace system in which an insert appliance is installed. original proof of purchase VisionLINE or Jetmaster may accept other evidence of the date of purchase. •...
