TAURUS - AU
freestanding
INSTALLATION AND OWNERS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TAURUS - AU and is the answer not in the manual?

Questions and answers

Related Manuals for visionLINE TAURUS - AU

Summary of Contents for visionLINE TAURUS - AU

  • Page 1 TAURUS - AU freestanding INSTALLATION AND OWNERS MANUAL...
  • Page 2 WOODFIRE COMPLIANCE LABEL This appliance has been TESTED TO AS/NZS4013 for Hardwood by ASFT Report 20009 Date tested: FEBRUARY 2020 VisionLINE Taurus Freestanding and Inbuilt OVERALL AVERAGE EFFICIENCY WHEN TESTED IN ACCORDANCE WITH AS/NZS 4012..61% AVERAGE PARTICULATE EMISSION FACTOR WHEN TESTED IN ACCORDANCE WITH AS/NZS 4013..1.3 G/KG MAXIMUM AVERAGE HEAT OUTPUT ..15.4 KW...
  • Page 3 Central AIR INTAKE – 100mm Central – secondary – tertiary AIRCONTROL Ø172 Ø110mm 1042 1042 The Taurus firebox weighs approx. 310kg including base. To safety lift the unit onto the base for positioning, the unit should be stripped of as much weight as possible by removing all bricks, baffles and the door assembly.
  • Page 4 The VisionLINE Taurus may require an insulating Floor Protector depending on the installation type. It is tested and complies with the minimum Floor Protector requirements of AS/NZS 2918:2018. See below for Hearth specifications. Note: ▪ The minimum Floor Protector sizes are specified in the clearance chart, see Table 1 & 2.
  • Page 5 FIREBOX INSTALLATION WARNING Fire Risk. 1. If a separate floor protector is being VisionLINE fireplaces disclaims any used position now. Place the firebox on responsibility for, and the warranty the floor protector that is at least 6mm will be voided by, the following...

  • Page 6: Install Guide

    Install Guide Getting Started...

  • Page 7: Inspection Of Appliance And Components

    WARNING WARNING Fire Risk. Fire Risk. Inspect appliance and components for damage. VisionLINE fireplaces disclaims any Damaged parts may impair safe operation. responsibility for, and the warranty will be • Do NOT install damaged components. voided by, the following actions: •...

  • Page 8: Install Checklist

    Manual bag and all of its contents are removed from inside/under the appliance ______________________________________ and given to the party responsible for use and operation. VisionLINE fireplaces recommends the following: • Photographing the installation and copying this checklist for your file.
  • Page 10 (AS/NZS 2918:2018) VisionLINE fireplaces recommends using either VisionLINE Default flue kits or VisionLINE AIR insulated flue kits.

  • Page 11: Minimum Height Of Flue System Exit

    MINIMUM HEIGHT OF FLUE SYSTEM EXIT 3000 More than 3000 or less 6000 600 min. 3000 increase from 1000mm min until clear within 3000 of flue top increase as necessary until nothing within 6000mm of flue top Any nearby structure...

  • Page 12: Installing The Flue

    Installing The Flue The flue seats over the flue starter spigot, the flue crimp will slide down and rest in the lower channel. Friction fitment secures the flue on the spigot, no sealant required Lower channel Flue seated correctly. Remove crimp if connection is slack or not fitting tight against the spigot.
  • Page 13 AS/NZS 2918:2018 General Notes WARNING: THE APPLIANCE AND FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH AS/NZS 2918 AND THE APPROPRIATE REQUIREMENTS OF THE RELEVANT BUILDING CODE OR CODES. WARNING: APPLIANCES INSTALLED IN ACCORDANCE WITH THIS STANDARD SHALL COMPLY WITH THE REQUIREMENTS OF AS/NZS 4013 WHERE REQUIRED BY THE REGULATORY AUTHORITY, I.E.

  • Page 14: Combustion Air

    Avoid opening the door when there is visible smoke/ VisionLINE fireplaces recommends the VisionLINE AIR flame to reduce this symptom. It is good practice to only insulated flue system to create a balanced flue reload when fuel is at coaling phase.

  • Page 15: Unit Operation

    Unit Operation Over firing the unit and continuously running the unit on high with an overloaded firebox for extended periods of time can damage the unit. This picture shows the firebox fully loaded. Note the red line which indicates a gap between the loaded fuel and the baffle top and the clear path to the tertiary air tube at the rear.

  • Page 18: Option 2 Raised Hearth

    Installing Optional Rear Fans Optional fans can be installed in two locations depending on how the unit is being installed, the lower location can be used when the unit is being installed on the optional base. If you wish to install the unit on raised hearth, the higher fan mounting location can be used.
  • Page 19 Installing Optional Rear Fans Optional fans require a standard double 240v GPO situated on the wall directly behind the fireplace. Optional fans should not be used within 45 minutes of starting the fireplace, this allows the firebox to warm up prior to heat being pulled from the heat exchanger. Using the optional fans prior will reduce the heat output of the fire and delay the warm up process dramatically.

  • Page 20: Other Rights

    VisionLINE warrants to the original owner of the VisionLINE appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the VisionLINE appliance will be free from defects in materials and workmanship at the time of manufacture.

  • Page 21: How To Claim

    VisionLINE and Jetmaster VIC will assess your claim. VisionLINE or Jetmaster VIC may need to inspect the product as part of the assessment of your claim. If the product requires inspection, VisionLINE or Jetmaster will discuss with you the best way for this to occur.
