visionLINE VL-24 Owner's Manual

Insert electric fireplace heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSERT ELECTRIC FIREPLACE HEATER
OWNER'S MANUAL
MODEL#: VL-24
AC 220-240V 50Hz 1400-1600W
Read and understand this entire owner's manual, including all safety
WARNING
information, before plugging in or using this product. Failure to do so could
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VL-24 and is the answer not in the manual?

Questions and answers

Related Manuals for visionLINE VL-24

Summary of Contents for visionLINE VL-24

  • Page 1 INSERT ELECTRIC FIREPLACE HEATER OWNER’S MANUAL MODEL#: VL-24 AC 220-240V 50Hz 1400-1600W Read and understand this entire owner’s manual, including all safety WARNING information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION! WARNING  Read all instructions before using this fireplace!  DO NOT operate any fireplace with a damaged cord or plug or after the fireplace malfunctions, has been dropped or damaged in any manner. Discard fireplace, or return to authorized service facility for examination and/or repair.
  • Page 3 circuit. If this fireplace trips the circuit breaker, unplug all other appliances on the same circuit before the next use. Avoid plugging other appliances into the same circuit as this fireplace.  NEVER plug this fireplace into an outlet that is old, cracked, or has any loose wires or connections.

  • Page 4: Parts And Hardware

    Preparation This product includes a GLASS panel! Always use extreme caution when using. Failure to do so could result in personal injury or property damage. Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Check the parts list to make sure nothing is missing.

  • Page 5: Specification And Dimension

    Specification and Dimension Description Electric Fireplace 2 Way Installation Unit: Type Recess into Wall and Assemble with mantel Voltage 220V AC Watts MAX 1600W Amps AMP Earthed Circuit Width: 700mm Overall Height: 728.6mm Dimension Depth: 145.6mm Installation and Assembly Your appliance is recessed and/or mantel installed appliance. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and high traffic areas.

  • Page 6: Methods Of Operation

    Methods of Operation This electric fireplace can be operated by the CONTROL PANEL, above the upper right hand glass panel of the fireplace (see figure below), or by the battery-powered REMOTE CONTROL(C). The operation and functions of the two methods are the same. Before operating, please review the IMPORTANT SAFETY INFORMATION on Pages 2 &...
  • Page 7 1. Press once. Indicator lights up. HEATER button: Turns heater on and off. Fan blows cool air for 10 seconds. 750W NOTE: The heater only works when the heater turns on and blows warm air. flame effect is on. If the flame effect is off, 2.

  • Page 8: Temperature Limiting Control

    Temperature Limiting Control This heater is equipped with a Temperature Limiting Control. Should the heater reach an unsafe temperature, the heater will automatically turn OFF. To reset: 1. Unplug the power cord from the outlet. 2. Turn the ON/OFF switch on the CONTROL PANEL to OFF. Wait 5 minutes. 3.

  • Page 9: Maintenance

    Storage:  Store heater in a clean dry place when not in use. WARNING! NO SERVICING of the internal or electrical parts should be performed by the consumer. Do not service the unit yourself. VisionLine 444 Swan Street Richmond, Victoria...
