visionLINE VL42-S2 Owner's Manual

Slim wall mounted & wall recessed fireplace
Hide thumbs
Table of Contents

Advertisement

Quick Links

SLIM WALL MOUNTED & WALL RECESSED FIREPLACE
Model# :
42"/50"/60"/72"/84"/100" Wall Mounted / Built-in
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could
WARNING
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.
VL42-S2
VL72-S2
OWNER'S MANUAL
Electric Fireplace
AC 220-240V 50Hz 1400-1600W
VL60-S2
VL50-S2
VL100-S2
VL84-S2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VL42-S2 and is the answer not in the manual?

Questions and answers

Related Manuals for visionLINE VL42-S2

Summary of Contents for visionLINE VL42-S2

  • Page 1 SLIM WALL MOUNTED & WALL RECESSED FIREPLACE Model# : VL42-S2 VL60-S2 VL50-S2 VL72-S2 VL100-S2 VL84-S2 OWNER’S MANUAL 42"/50"/60"/72"/84"/100" Wall Mounted / Built-in Electric Fireplace AC 220-240V 50Hz 1400-1600W Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could WARNING result in fire, electric shock, or serious personal injury.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION! WARNING When using electrical appliances basic precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Read all instructions before using this heater.  This heater is hot when in use. To avoid burning, do not touch hot surface. If provided, use ...

  • Page 3: Parts And Hardware

    Preparation This product includes a GLASS panel! Always use extreme caution when handling glass. Failure to do so could result in personal injury or property damage. Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Parts and assembly steps are grouped for wall-hanging or recessing use.

  • Page 4: Installation And Assembly

    VL42-S2 (BEF-42WM03A) VL50-S2 (BEF-50WM03A) VL60-S2 (BEF-60WM03A) VL72-S2 (BEF-72WM03A) VL84-S2 (BEF-84WM03A) VL100-S2 (BEF-100WM03A) Installation and Assembly Your appliance is a wall-mounted, recessed and/or mantel installed appliance. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and high traffic areas.
  • Page 5 C. Remove the front glass (see “front glass removal / installation” section). D.Hold the appliance up to ensure it will fit into the framing. Finishing Material Framing Hole Size Model No. 1030mm 150mm VL42-S2(BEF-42WM03A) 440mm 1232mm 150mm 440mm VL50-S2(BEF-50WM03A) 1488mm...
  • Page 6 Front Glass Panel Removal A. Take off the screws on both side.(Fig. 1-1 ) B. Carefully lift the front trim up and away from the appliance (Fig. 1-2 ). Place it face down on a soft, non-abrasive surface. C. Reverse these steps to install the front glass. Fig.
  • Page 7 Wall Recessed Installation A.Take off the screws (1 per side) from the sides of the fireplace. Set the screws aside (Fig. 2-1 ) B.Remove the two brackets and set them aside.(Fig. 2-2 ) Fig. 2-1 Fig. 2-2 C.Power the fireplace by plug-into the wall receptacle. D.
  • Page 8 Fig. 2-4 Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance on the wall. A.Select a location that is not prone to moisture and is located at least 36" (914mm) away from combustible materials such as curtain drapes, furniture, bedding, paper, etc.
  • Page 9 Fig 3 BEF-42/50/60WM Wall Bracket Illustrated VL42-84-S2 Wall Bracket Illustrated VL100-S2 Wall Bracket Illustrated...

  • Page 10: Hard Wiring Installation

    “L” Shape Bracket Installation A.Remove the silver screw at the bottom of the appliance. (Fig 4-1). Set the screw aside. Fig 4-1 Fig 4-2 B.Using the screw previously removed, attached the L-bracket (supplied) to the bottom of the fireplace box.(Fig 4-2) Fig 4-3 C.Install the plastic anchor (C) into the drywall, then install the screw B (supplied) into the hole of the L-bracket into the wall anchor to secure the fireplace from coming off the hooks.(Fig 4-3)
  • Page 11 Fig 5-1 Fig 5-2 Remove the cover plate from the right side Remove the wire connectors from the power bottom of the appliance by removing the three cord. The power cord may be discarded. Fig 5-2 screws, as shown above. Fig 5-1 Take the new cover plate, supplied in the hardware bag.

  • Page 12: Operation

    Fig 6-1. (Log-set) Fig 6-2. (Plastic Strip) Fig 6-3. (Clear Crystals) Operation Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, fire, serious injury, or death. Power Plug the power cord into a 220-240 Volt 15 Amp grounded outlet (see IMPORTANT SAFETY INFORMATION on Pages 2 and 3).
  • Page 13 Touch-on Control Panel Remote control Touch-on Control Panel Operation BUTTON FUNCTION ACTION & INDICATION ON: Enables control panel functions and 1. Press once. Indicator light turns on. remote control. Turns on flame effect. Power turns on. All functions enabled. OFF: Disables control panel functions and 2.
  • Page 14 Remote Control Operation BUTTON FUNCTION ACTION & INDICATION ON: Enables control panel functions and 1. Press once. Indicator light turns on. remote control. Turns on flame effect. Power turns on. All functions enabled. OFF: Disables control panel functions and 2. Press again. Flame effect turns off. Unit POWER remote control.

  • Page 15: Care And Maintenance

    Press once. The display becomes active and shows the LED Down light button ( 1 ): Makes the temperature level. color on TOP effect changing. press again until the desired temperature setting is reached. NOTE: Down light color effect stays on until The digital display shows the settings as shown in the table below.
  • Page 16 When replacing old appliances with new ones, the retailer is legally obligated to take back your old appliance for disposals at least free of charge. VisionLine 444 Swan Street Richmond, Victoria...
