Item #633 686
Model #FTS80584
USE AND CARE GUIDE
BELLEVILLE SIDE TABLE
Questions, problems, missing parts? Before returning to the store call
Hampton Bay Customer Service.
8 a.m. - 6 p.m., EST, Monday-Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
n Bay through the purchase of this side table. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY BELLEVILLE FTS80584
Summary of Contents for HAMPTON BAY BELLEVILLE FTS80584
- Page 1 Bay through the purchase of this side table. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Warranty
Table of Contents Table of Contents ............2 Package Contents ..............3 Warranty ................ 2 Assembly ............... 4 What is Covered ..............2 Care and Cleaning ............6 What is Not Covered ..............2 Pre-Assembly ..............2 Planning Assembly ..............2 Hardware Included .............. -
Page 3: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity e l i Table rim Leg connector HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 4 Assembly Connecting the table legs Place the table rim (B) upside down on a soft surface. Connect each of the table legs (D) with M6x20 bolts (BB) and M6 washers (CC) to the table rim (B). NOTE: Loosely tighten the bolts using the hex wrench (DD).
- Page 5 Assembly (continued) Connecting the leg connector to the table legs Align the holes of the leg connector (C) with the holes on the inside of each the table leg (D). Connect the leg connector (C) to the table legs (D) with M6X15 bolts (AA) and M6 washers (CC). Tighten all the bolts.
-
Page 6: Care And Cleaning
Assembly (continued) Adding the tile Turn the table right side up. Ensure that all connections are secure Carefully place the tile (A) on the table. Care and Cleaning For best results, clean the frame with damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. - Page 7 Questions, problems, missing parts? Before returning to the store call Hampton Bay Customer Service. 8 a.m. - 6 p.m., EST, Monday-Friday 1- 855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
