USE AND CARE GUIDE
BELLEVILLE DINING TABLE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1
8 -
5 5
H -
D
H -
A
M
P
O T
N
HAMPTONBAY.COM
THANK YOU
ay through the purchase of these dining table. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Related Manuals for HAMPTON BAY BELLEVILLE FTS80635
Summary of Contents for HAMPTON BAY BELLEVILLE FTS80635
- Page 1 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
- Page 2 Table of Contents Table of Contents ............2 Package Contents ..............3 Warranty ................ 2 Assembly ............... 4 What is Covered ..............2 Care and Cleaning ............6 What is Not Covered ..............2 Pre-Assembly ..............2 Planning Assembly ..............2 Hardware Included ..............
- Page 3 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Tile Stamped metal Table rim Leg connector Table leg HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 4 Assembly Connecting the table leg Place the table rim (C) upside down on a soft surface. Connect each of the table legs (E) with M6x20 combination bolts (BB) to the table rim (C). NOTE: Loosely tighten the bolts using the hex wrench (CC).
- Page 5 Connecting the leg connector to the table legs Align the holes of the leg connector (D) with the holes on the inside of each the table leg (E). Connect the leg connector (D) to the table legs (E) with M6x15 combination bolts (AA). Tighten all the bolts.
- Page 6 Assembly (continued) Adding the tiles Turn the table right side up. Ensure all connections are secure. Carefully place the tiles (A) and stamped metal (B) onto the table rim (C). NOTE: The stamped metal (B) can be replaced by the tile (A) if desired. Care and Cleaning For best results, clean the frame with damp cloth and dry thoroughly.
- Page 7 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1- 855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
