SIMATIC NET PROFIBUS
Optical Link Module
OLM / P11 V4.0
OLM / P12 V4.0
OLM / P22 V4.0
OLM / P11 V4.0
OLM / G12 V4.0
OLM / G22 V4.0
OLM / G12-EEC V4.0
OLM / G11-1300 V4.0
OLM / G12-1300 V4.0
Operating Instructions
01/2013
C79000-G8976-C270-03
Preface
Introduction
Network Topologies
Product Characteristics
Installation and Maintenance
Approvals and Marks
References
Drawings
1
2
3
4
5
6
7
8
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Siemens SIMATIC NET OLM/P22 V4.0
Summary of Contents for Siemens SIMATIC NET OLM/P22 V4.0
- Page 1 Preface Introduction Network Topologies SIMATIC NET PROFIBUS Optical Link Module Product Characteristics OLM / P11 V4.0 OLM / P12 V4.0 Installation and Maintenance OLM / P22 V4.0 OLM / P11 V4.0 OLM / G12 V4.0 Approvals and Marks OLM / G22 V4.0 OLM / G12-EEC V4.0 References OLM / G11-1300 V4.0...
- Page 2 A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property damage. Disclaimer of Liability Copyright © Siemens AG 2007 - 2013. We have reviewed the contents of this publication to ensure consistency with the hardware All rights reserved and software described.
- Page 3 Please note the following: Warning Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 4: Table Of Contents
Contents Preface ..............................1 Preface............................1 Introduction..............................3 Introduction ............................3 Network Topologies ........................... 7 Linear (bus) Topology ........................8 3.1.1 Linear (bus) topology with fiber-optic link monitoring and segmentation........9 3.1.2 Bus topology without fiber-optic link monitoring................9 Star Topology..........................10 Ring Topology ..........................11 3.3.1 Redundant Optical Ring.......................11 3.3.2 Redundant Optical Ring with two OLMs ..................13... - Page 5 Contents References .............................. 51 References...........................51 Drawings..............................53 Tables Table 2-1 Number of electrical and optical ports per module, ...............4 Table 4-1 Overview of the product characteristics..................20 Table 4-2 DIL-switches in compatibility mode....................24 Table 5-1 Meaning of the LED displays and indication by the signaling contact .........42 Table 5-2 Constants for calculating the slot time for DP-standard (redundant optical ring) ......46 Table 5-3...
-
Page 7: Preface
Preface Preface Purpose of the operating instructions These operating instructions support you when commissioning PROFIBUS OLM devices (Optical Link Module) Validity of these operating instructions These operating instructions are valid for the following devices: SIMATIC NET OLM / P11 V4.0 6GK1 503-2CA00 SIMATIC NET OLM / P12 V4.0 6GK1 503-3CA00... -
Page 8: Further Documentation
Further documentation You will find more information on other SIMATIC NET products that you can use with the OLM V4.0 devices in the “SIMATIC NET PROFIBUS networks SIEMENS AG” manual. Finding information To help you find the information you require more quickly, the manual includes not only the table of contents but also the following sections in the Appendix: •... -
Page 9: Introduction
Introduction Introduction This section provides you with an overview of the functions of the PROFIBUS OLM4.0 product family. What is possible? PROFIBUS OLMs are designed for use in optical PROFIBUS fieldbus networks. They allow the conversion of electrical PROFIBUS interfaces (RS-485 level) into optical PROFIBUS interfaces and vice versa. -
Page 10: Table 2-1 Number Of Electrical And Optical Ports Per Module
Introduction 2.1 Introduction Every module has two (OLM P11, G11), three (OLM P12, G12), or four (OLM P22, G22) independent channels (ports) that consist of transmitter and receiver pairs. The power supply voltage for operation is 24 V DC. To increase operational reliability, a redundant power supply is possible. - Page 11 Introduction 2.1 Introduction The PROFIBUS OLMs comply with the standard EN 50170 /2/ and with the technical guideline “Optical transmission technology for PROFIBUS” published by the PROFIBUS User Organization (PNO). OLM / G12 and OLM / G12-EEC have the same functions. They only differ in the specification of the ambient climatic conditions: the OLM / G12 is suitable for use in the standard temperature range from 0 °C to 60 °C, whereas the OLM / G12-EEC (extended environmental conditions) can be used in the extended temperature range of -25 °C to +60...
-
Page 13: Network Topologies
Network Topologies Which network topologies can be implemented? The following network topologies can be implemented with the PROFIBUS OLM: Point-to-point connection • Bus (linear) topology • Star topology • Redundant optical ring • Combinations of these basic types are also possible. To set up the fiber-optic links of these network topologies, cables with two optical fibers are used. -
Page 14: Linear (Bus) Topology
Network Topologies 3.1 Linear (bus) Topology Linear (bus) Topology Figure 3-1 Network structure in a linear (bus) optical topology * If OLM / P22 or OLM / G22 are used, an additional DTE or bus segment can be connected to Ch 0. In a linear or bus structure, the single PROFIBUS OLMs are connected by two-fiber cables. -
Page 15: Linear (Bus) Topology With Fiber-Optic Link Monitoring And Segmentation
Network Topologies 3.1 Linear (bus) Topology 3.1.1 Linear (bus) topology with fiber-optic link monitoring and segmentation Use this mode especially when you want a disrupted fiber-optic cable segment to be separated from the rest of the network (see section 4.2.2.4). Only use this mode, if you only connect PROFIBUS OLM V4.0 or V3/V4.0 with each other. -
Page 16: Star Topology
Network Topologies 3.2 Star Topology Star Topology RS-485 Electrical star segment OLM/G12 OLM/P11 OLM/P11 OLM/G11-1300 Ch 1 Ch 1 Ch 1 Ch 1 Ch 2 Ch 2 Ch 3 Ch 2 Ch 2 Ch 2 Ch 2 Ch 1 Ch 1 Ch 2 Ch 2 Ch 2... -
Page 17: Ring Topology
Network Topologies 3.3 Ring Topology Note: Unused optical channels you intend to use later to expand the network cause a broken fiber- optic cable signal if the monitoring is active. You can avoid this error message by setting unused channels to the mode “bus without fiber-optic link monitoring”. Remember that the optical channels that are not connected must be protected against external light and pollution by protective caps. - Page 18 Network Topologies 3.3 Ring Topology If one module fails, only the DTEs connected to this module or the RS-485 segment are disconnected from the ring. The rest of the network itself stays functional as a bus. The problem is indicated by the LEDs of the two OLMs connected to the disrupted fiber-optic link and by the signaling contacts of these OLMs.
-
Page 19: Redundant Optical Ring With Two Olms
Network Topologies 3.3 Ring Topology 3.3.2 Redundant Optical Ring with two OLMs Setting up a redundant optical ring with two PROFIBUS OLMs can be seen as special case of the redundant optical ring and can be implemented with the following two configurations. Configuration 1 Configuration 2 Figure 3-4... - Page 20 Network Topologies 3.3 Ring Topology Configuration 1 (see Figure 3-4, FOC1 < FOC2) , LED display: 1. Situation, no FOC interruption: OLM 1 OLM 2 SystemLED = lit green SystemLED = lit green CH1/0 LED = lit yellow CH1/0 LED = lit yellow LED = lit yellow LED = is not lit LED = is not lit...
- Page 21 Network Topologies 3.3 Ring Topology 3. Fault, FOC2 interrupted: OLM 1 OLM 2 SystemLED = lit green SystemLED = lit green CH1/0 LED = lit yellow CH1/0 LED = lit yellow LED = lit yellow LED = lit yellow LED = lit red LED = lit red 2.
-
Page 23: Product Characteristics
Product Characteristics Technical Specifications Characteristics Device type OLM P11 V4.0 OLM G11 V4.0 OLM G11-1300 V4.0 OLM P12 V4.0 OLM G12 V4.0 OLM G12-1300 V4.0 OLM P22 V4.0 OLM G22 V4.0 OLM G12-EEC V4.0 Power supply Operating voltage 24 V DC safety extra low voltage permitted voltage range 18..32 V DC NEC Class 2 Current consumption max. - Page 24 Product Characteristics 4.1 Technical Specifications Characteristics Device type OLM P11 V4.0 OLM G11 V4.0 OLM G11-1300 V4.0 OLM P12 V4.0 OLM G12 V4.0 OLM G12-1300 V4.0 OLM P22 V4.0 OLM G22 V4.0 OLM G12-EEC V4.0 Safety IEC regulation IEC 60950 (corresponds to EN 60950 and VDE 0805) UL-approval according to type plate CSA-approval...
- Page 25 Product Characteristics 4.1 Technical Specifications Characteristics Device type OLM P11 V4.0 OLM G11 V4.0 OLM G11-1300 V4.0 OLM P12 V4.0 OLM G12 V4.0 OLM G12-1300 V4.0 OLM P22 V4.0 OLM G22 V4.0 OLM G12-EEC V4.0 with plastic fiber S 980/1000 (0.2 dB/m) Transmit power “reduced“...
-
Page 26: Table 4-1 Overview Of The Product Characteristics
Product Characteristics 4.1 Technical Specifications Characteristics Device type OLM P11 V4.0 OLM G11 V4.0 OLM G11-1300 V4.0 OLM P12 V4.0 OLM G12 V4.0 OLM G12-1300 V4.0 OLM P22 V4.0 OLM G22 V4.0 OLM G12-EEC V4.0 Miscellaneous information Degree of protection IP40 Dimensions 39.5 x 112 x 74.5 mm... -
Page 27: Installation
Product Characteristics 4.2 Installation Installation 4.2.1 Safety related notices Only use the PROFIBUS OLM in the way intended in these operating instructions. In particular, observe all warnings and safety-relevant notices. Run the modules only with a safety extra-low voltage of a maximum of +32 V DC (typically +24 V DC) according to IEC 950 / EN 60 950 / VDE 0805. -
Page 28: General Information On Commissioning
Product Characteristics 4.2 Installation 4.2.2 General information on commissioning Unpack the OLM V4.0 and its accessories and check that the consignment is complete and that there has been no damage during transportation. After unpacking, the device should be acclimatized for some time to avoid condensation after to storage in cold surroundings. First choose the network topology suitable for your requirements. -
Page 29: Setting Compatibility, Mode And Transmit Power
Product Characteristics 4.2 Installation 4.2.3 Setting compatibility, mode and transmit power Please note the following: The OLM must be switched off when changing the mode. You can achieve this for example by disconnecting the 5-pin terminal block. 4.2.3.1 Setting the compatibility With DIL switch S7, you can enable or disable functional compatibility with devices of the previous generation SINEC L2FO OLM / P3, -P4, -S3, -S4, S3-1300 and S4-1300. -
Page 30: Table 4-2 Dil-Switches In Compatibility Mode
Product Characteristics 4.2 Installation The significance of the DIL switches of the OLM when S7=1 for: SINEC L2FO SINEC L2FO SINEC L2FO OLM / P3 and OLM / P4 OLM / S3 and OLM / S4 OLM / S3-1300 and OLM / S4-1300 /P4: Output /P3:... - Page 31 Product Characteristics 4.2 Installation Mode “electrical channel without segment monitoring“ CH1 is set to this mode, when S0 is in position 1. Note: This mode should only be set in the star segment of the star topology. 4.2.3.4 Setting the mode of the electrical channel (CH0) Only for OLM / P22 and OLM / G22 Mode “electrical channel with segment monitoring“...
- Page 32 Product Characteristics 4.2 Installation 4.2.3.6 Reducing the optical transmit power Notice! The following information is only valid for the default setting of S7 (S7=0)! for OLM / P11, OLM / P12, and OLM / P22 The OLM / P11, OLM / P12, and OLM / P22 have a high optical transmit power. Connecting these modules with non-OLM devices via plastic fiber-optic cables can lead to optical overdrive, especially if short cables are used.
-
Page 33: Figure 4-2 Minimum Cable Length For Use Of Plastic Fiber S 980/1000 Without Fixed Attenuator
Product Characteristics 4.2 Installation Figure 4-2 Minimum cable length for use of plastic fiber S 980/1000 without fixed attenuator 4.2.3.7 DIL Switches S5 / S6 in OLM / G11-1300 and OLM / G12-1300 In OLM V4 devices for glass FOC (1300 nm), the DIL switches S5 and S6 do not have a function (reduction of optical transmit power not possible). -
Page 35: Installation And Maintenance
Installation and Maintenance Installation 5.1.1 Installation instructions Electromagnetic compatibility Electromagnetic compatibility involves all questions regarding electric, magnetic and electromagnetic emission effects. To avoid disturbing influences on electrical installations, these effects must be reduced to a minimum. The construction of device, correct connection of bus lines and the suppression of self inductances are essential limitation measures. - Page 36 Installation and Maintenance 5.1 Installation Please note the following: A minimum distance of 15 cm must be maintained between an OLM and a load switching element (e.g. contactor, relay, temperature control, switch, etc.). This minimum clearance is measured between the outside edges of the components and must be adhered to in all directions around an OLM.
-
Page 37: Shield Connections
Installation and Maintenance 5.1 Installation Please note the following points when connecting Shield connections the cable shield: Connect the shield braid with cable clamps made of metal. The clamps must surround the shield making good contact over a large area (see Figure 5-2). - Page 38 Installation and Maintenance 5.1 Installation Example: OLM / G12, wavelength 860 nm, fiber 62.5/200 µm = 13 dBm send = 28 dBm receiver optical link margin = 28 dBm -13 dBm= 15 dBm max. line length = 3 km attenuation = 3.5 dB/km @ 860 nm max.
-
Page 39: Connecting Optical Cables
Installation and Maintenance 5.1 Installation 5.1.2 Connecting optical cables Connect the single modules via a two-core fiber-optic cable with BFOC/2.5 connectors. Make sure – that the end faces of the optical connectors are clean. – that always one optical input and one optical output are interconnected (“crossover connection“). -
Page 40: Installation Of The Modules
Installation and Maintenance 5.2 Installation of the Modules Installation of the Modules Installation options The OLMs can either be mounted on a 35 mm rail according to DIN EN 50022 or on a flat surface with the help of a mounting plate. ... -
Page 41: Figure 5-5 Installation Of A Module With A Mounting Plate
Installation and Maintenance 5.2 Installation of the Modules Installation on a mounting plate Unscrew the 3 screws on the right side of the OLM (the side with the type label). Fix with this screws the mounting plate (MLFB: 6GK1503-8AA00). ... -
Page 42: Connection Of The Electrical Rs-485 Bus Cables
Installation and Maintenance 5.3 Connection of the Electrical RS-485 Bus Cables 10,15 37,35 60,15 3x Ø3,5 Figure 5-6 Drilling measures for the mounting plate, all dimensions are millimeter Connection of the Electrical RS-485 Bus Cables The modules are equipped with one or two electrical ports with RS-485 level. - Page 43 Installation and Maintenance 5.3 Connection of the Electrical RS-485 Bus Cables Only use shielded twisted pair for the RS-485 bus cables as described in the manual “SIMATIC NET PROFIBUS Networks”. Do not exceed the segment lengths specified there. Connect the RS-485 bus segment via a PROFIBUS connector. If the module is at the beginning or at the end of a bus segment, this connector must have an active bus terminator.
-
Page 44: Connecting Of The Operating Power Supply
Installation and Maintenance 5.4 Connecting of the Operating Power Supply Connecting of the Operating Power Supply The terminal block can be removed from the device to allow cables to be connected. Supply the module only with a stabilized safety extra-low ... -
Page 45: Receive Level Of The Optical Channels
Installation and Maintenance 5.6 Receive Level of the Optical Channels Receive Level of the Optical Channels The receive level of the two optical channels CH2 und CH3 can be measured using a standard voltmeter via the measurement sockets. The voltmeter can be connected and disconnected while the device is operating. -
Page 46: Led Displays And Troubleshooting
Installation and Maintenance 5.7 LED Displays and Troubleshooting Notes: For a valid measurement, that the partner OLM at the other end of the fiber-optic cable must send normal PROFIBUS frames. This can be recognized by the LED display of the partner OLM (see section 5.7.1). - Page 47 Installation and Maintenance 5.7 LED Displays and Troubleshooting LED display Possible causes Signaling contact System lit green - The transmission rate was detected and the voltage supply is ok does not signal not lit - Voltage supply outage (complete outage, with a redundant supply, outage signals down of both supply voltages) - Voltage supply connected wrongly...
-
Page 48: Table 5-1 Meaning Of The Led Displays And Indication By The Signaling Contact
Installation and Maintenance 5.7 LED Displays and Troubleshooting LED display Possible causes Signaling contact not lit Transmission rate not detected yet – LED “System“ flashes red does not signal - There is no transmitting bus node - Transmit and receive fiber-optic cables swapped over -No partner module connected or partner module is not turned on - Connected partner module is defective Transmission rate is detected –... -
Page 49: Troubleshooting
Installation and Maintenance 5.7 LED Displays and Troubleshooting 5.7.2 Troubleshooting This section will help you to localize the problem after an error message (LED or signaling contact). Refer to the description of the LED displays in section 5.7.1. 5.7.2.1 Error display of the System LED See description of the LED displays in section 5.7.1. -
Page 50: Maintenance
OLM V4.0 (DIL switches). If there are any signs of changes, the OLM V4.0 should be replaced. If any other fault develops, please send the device to your SIEMENS service center for repair. Repairs on-site are not possible. -
Page 51: Cleaning
Installation and Maintenance 5.9 Cleaning Cleaning If it becomes necessary to clean the device, this must be done with a dry, lint-free cloth. Do not use water or solvent! If liquids get into the device, it must be deactivated. When cleaning the device, make sure that no dirt enters the optical transmission path or gets onto the optical components. -
Page 52: Table 5-2 Constants For Calculating The Slot Time For Dp-Standard (Redundant Optical Ring)
Installation and Maintenance 5.10 Configuration The factors a, b and c depends on the transmission speed and can be found in the following table: Data rate 12 Mbps 1651 6 Mbps 3 Mbps 1.5 Mbps 500 Kbps 187.5 Kbps 3.75 93.75 Kbps 1.875 45.45 Kbps... -
Page 53: Approvals And Marks
Approvals and Marks CE Mark Product name SIMATIC NET SIMATIC NET OLM / P11 V4.0 6GK1 503-2CA00 SIMATIC NET OLM / P12 V4.0 6GK1 503-3CA00 SIMATIC NET OLM / P22 V4.0 6GK1 503-4CA00 SIMATIC NET OLM / G11 V4.0 6GK1 503-2CB00 SIMATIC NET OLM / G12 V4.0 6GK1 503-3CB00 SIMATIC NET OLM / G22 V4.0... -
Page 54: C-Tick
Networks” /1/ manual when installing and operating the device. Conformity certificates The EC Declaration of Conformity is available for the responsible authorities according to the above-mentioned EC Directive at the following address: Siemens Aktiengesellschaft Industry Sector Industry Automation Division Industrielle Kommunikation (I IA SC CI) Postfach 4848 D-90026 Nürnberg, Germany... -
Page 55: Fm Approval
Approvals and Marks 6.4 FM approval FM approval CL.1, DIV.2, GP. A,B,C,D, T4 CL.1, Zone 2, GP. IIC, T4 Ta: -20 °C .. +60 °C (model OLM / G12 EEC, only) Ta: 0 °C .. +60 °C (all other models) Ex approval Models: OLM / P11 V4.0, OLM / P12 V4.0, OLM / P22 V4.0, OLM / G11 V4.0, OLM / G12 V4.0, OLM / G22 V4.0, OLM / G12-EEC V4.0... -
Page 56: Shipbuilding Approvals
The devices of the OLM V4.0 series also meet several requirements for shipbuilding. For the respectively valid approvals call our hotline +49-911-895-7222. Furthermore you can gather information at: http://support.automation.siemens.com SIMATIC NET PROFIBUS Optical Link Module OLM V4.0 Operating Instructions, 01/2013, C79000-G8976-C270-03... -
Page 57: References
References References Sources of information and other documentation 1. SIMATIC NET PROFIBUS networks order numbers: C79000-G8900-C124-03 German C79000-G8976-C124-03 English C79000-G8977-C124-03 French C79000-G8972-C124-03 Italian 2. EN 50170-1-2 1996: “General Purpose Field Communication System“, Volume 2 “Physical Layer Specification and Service Definition“ 3. -
Page 59: Drawings
Drawings SIMATIC NET PROFIBUS Optical Link Module OLM V4.0 Operating Instructions, 01/2013, C79000-G8976-C270-03... - Page 60 Drawings SIMATIC NET PROFIBUS Optical Link Module OLM V4.0 Operating Instructions, 01/2013, C79000-G8976-C270-03...
- Page 61 Glossary BFOC Bayonet Fiber Optic Connector Deutsches Institut für Normung [German Institute for Standardization] Extended Environmental Conditions Electronic Industries Association European standard Electromagnetic Compatibility HCS™ Hard Polymer Cladded Silica Fiber (registered trademark of Ensign-Bickford) Highest Station Address International Electrotechnical Commission Light Emitting Diode Optical Bus Terminal Optical Link Module...
- Page 63 Index ATEX, 47 Network topology bus (linear) topology, 7 point-to-point-connection, 7 redundant optical ring, 7 ring topology, 11 CE mark, 45 star topology, 7, 10 Compatibility, 22 C-tick mark, 46 Optical link power budget, 29 Optical star topology, 3 DIL switch, 22 overdrive, optical, 25, 40 Electromagnetic compatibility, 27 Redundant ring, 11...
- Page 64 Index SIMATIC NET PROFIBUS Optical Link Module OLM V4.0 Index-58 Operating Instructions, 01/2013, C79000-G8976-C270-03...
