Travis Industries Lopi DVS EmberGlo GSR2 Manual

Inbuilt
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
(4 ) AA Ba tte rie s
WARNING: FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
-
Installation and service must be performed by a qualified installer, service agency, or the gas supplier.
! DANGER
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed for the protection of children
and other at-risk individuals.
This appliance may be installed in an aftermarket, permanently located, manufactured home
(USA only), or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. A conversion
kit is supplied with the appliance.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Dragon Wholesaling Pty. Ltd., Unit 2, 16 Lexington Drive, Bella Vista NSW 2153, Australia
 Copyright 2020, T.I.
DVS EmberGlo™
GSR2 Inbuilt
Manual
HOT GLASS WILL CAUSE
BURNS
DO NOT TOUCH GLASS
UNTIL COOLED
NEVER ALLOW CHILDREN
TO TOUCH GLASS
$10.00
12/23/2024
(AUST)
• Direct Vent Fireplace Inbuilt
• Residential or Mobile Home
Listed by
AS/NZS 5263.1.8
GMK10034
IAPMO-R&T OCEANA
100-01547

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lopi DVS EmberGlo GSR2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Travis Industries Lopi DVS EmberGlo GSR2

Summary of Contents for Travis Industries Lopi DVS EmberGlo GSR2

  • Page 1 DVS EmberGlo™ GSR2 Inbuilt (AUST) Manual (4 ) AA Ba tte rie s WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
