Read the manual thoroughly prior to equipment setup, operation, and maintenance.
www.AvantcoRefrigeration.com
User Manual
09/2024
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avantco 178CPW47HC
Summary of Contents for Avantco 178CPW47HC
- Page 1 User Manual 09/2024 Ice Cream Dipping Cabinets White Models: #178CPW47HC 471/8" - 8 Tub #178CPW68HC 673/ 4 " - 12 Tub #178CPW88HC 883/ 4 " - 16 Tub Stainless Steel Models: #178CPSS47HC 471/8" - 8 Tub #178CPSS68HC 673/ 4 " - 12 Tub #178CPSS88HC 883/ 4 "...
-
Page 2: Table Of Contents
User Manual Ice Cream Dipping Cabinets Table of Contents Safety .............................3 Installation ..........................4 Cabinet Location Guidelines ...................4 Product Placement ......................5 Electrical ..........................5 Functions ..........................5 Digital Control Units......................6 Caster Installation ....................... 7 Tub Inserts and Cover Installation .................8 Safety / Warning .........................8 Operation / Maintenance ....................9 Troubleshooting ........................ -
Page 3: Safety
User Manual Ice Cream Dipping Cabinets Safety Warning DANGER – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. TO BE REPAIRED ONLY BY TRAINED SERVICE PERSONNEL. DO NOT PUNCTURE REFRIGERANT TUBING. PELIGRO – RRIESGO DE INCENDIO O EXPLOSION. REFRIGERANTE INFLAMABLE UTILIZADO. PARA SER REPARADO SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO. -
Page 4: Installation
User Manual Ice Cream Dipping Cabinets Installation Read this manual thoroughly prior to equipment setup, operation, and maintenance. This unit is intended for use in a temperature-controlled environment less than 75°F and 60% relative humidity. IMPORTANT – Read Before Installation: •... -
Page 5: Product Placement
User Manual Ice Cream Dipping Cabinets Product Placement • Corners of the freezer will be the coldest due to the cold wall surrounding the tubs on two sides. Tubs that are less than half full in the corners of the case may be hard to scoop. •... -
Page 6: Digital Control Units
User Manual Ice Cream Dipping Cabinets Digital Control Units • Hold “SET” for 1 sec. The display will flash the current minimum temperature. • Use the arrow buttons to adjust the minimum temperature. • Press “SET” again to save your settings. Always remember to calculate the differential if you change the minimum temperature setting. -
Page 7: Caster Installation
User Manual Ice Cream Dipping Cabinets Caster Installation Lay the unit down and loosen the base screw (pay attention to the protection of the product when placing it down). 2. Remove the base. 3. Install the casters. NOTE: After adding the casters, allow the unit to sit upright for 24 hours before plugging into an electrical outlet. -
Page 8: Tub Inserts And Cover Installation
User Manual Ice Cream Dipping Cabinets Tub Inserts and Covers Installation • Insert wire baskets to hold ice cream tubs. • Insert ice cream tubs into baskets with the lids removed. • Place tub covers over ice cream tubs to lock ice cream into place. •... -
Page 9: Operation / Maintenance
User Manual Ice Cream Dipping Cabinets Operation / Maintenance Disconnect the power cord before cleaning any parts of the unit. WARNING: We strongly recommend that any servicing be performed by an authorized service technician. NOTE: Cleaning the Fan Blades and Motor •... -
Page 10: Troubleshooting
User Manual Ice Cream Dipping Cabinets Troubleshooting Issue Possible Cause Possible Solution Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker. Power cord unplugged. Plug in power cord. Compressor is not running. Thermostat set too high. Set thermostat to lower temperature. Cabinet in defrost cycle.
