- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. CLIMETTE CA1026TRF Owner's Manual Shop genuine replacement parts for CLIMETTE CA1026TRF Find Your CLIMETTE Air Conditioner Parts - Select From 63 Models -------- Manual continues below --------...
- Page 2 Installation and Operating Instructions Manual de instalación y funcionamiento Manuel de installation et fonctionnement Room Air Conditioners for Through-The-Wall Installation Please read the operating instructions and safety precautions carefully and thoroughly before installing and operating your air conditioner. ENGLISH PAGE 1 Acondicionadores de aire empotrados en la pared...
-
Page 3: Table Of Contents
Table of Contents Power Cord with Arc Detection Device Electrical Requirements & The power cord supplied with this air conditioner is Safety Precautions equipped with an Arc Detection Device designed to shut off power to the unit when it senses an arc fault Power cord with arc detection device ...... -
Page 4: Recommended Wire Sizes
Additional Safety Precautions Warning Warning • Do not cut, alter or remove any of Electrical Shock Hazard Do not operate this air conditioner expanded polystyrene without proper time delay circuit • Plug unit only into (styrofoam) inside this protection (circuit breaker or fuse). grounded electrical outlet. -
Page 5: Installation Requirements
Installation Requirements Before you start Check the location where the air conditioner will be You have purchased a Through-the-Wall style air conditioner. installed. Proper installation is your responsibility. Make This type of air conditioner is designed to be installed inside sure you have read the instructions thoroughly and have a wall sleeve mounted into a wall opening. -
Page 6: Installing The Rear Grille Into A New Wall Sleeve
Installing the rear grille into a new wall sleeve: Wall sleeve A new wall sleeve (sold separately) will ensure the best fit and performance of your new through-the-wall air conditioner. See your local dealer or distributor about purchasing wall sleeve. Follow the installation instructions that are included with your new wall sleeve. -
Page 7: Installing The Rear Grille Into An Existing Wall Sleeve
Installing the rear grille into an existing wall sleeve: 1. Measure the dimensions of your existing wall sleeve. (Fig. 3) Wall Sleeve 2. Locate your wall sleeve in the wall sleeve identification chart below. Height If you have any questions or if your sleeve is not listed please call your dealer You must install the new grille included with your air conditioner. - Page 8 Section A Wall sleeve Dimensions of wall sleeve Wall Sleeve Width Depth Height Manufacturer 26 3/4” 15” 15 3/4” Emerson Quiet Kool 26 3/4” 15” 15 3/4” Fedders 26 3/4” 15” 15 3/4” Maytag 25 1/2” 19” 15 5/8” Sears 25 1/2”...
- Page 9 Section B Remove Tabs Dimensions of wall sleeve Wall Sleeve Width Depth Height Manufacturer 25 7/8” 18” 15 9/16” Carrier (52F series) 25 3/4” 16 7/8” 18 5/8” Carrier (51S Series) 25 7/8” 16”/18”/22” 15 7/8” Frigidaire 25 7/8” 16 23/32” 15 17/32” 25 1/2”...
-
Page 10: Installing The Trim Frame
Installing the air conditioner into the wall sleeve Wall sleeve 1. Replace any damaged foam inside the wall sleeve with replacement foam. Two pieces of adhesive backed replacement foam are provided, one vertical piece (15 3/4” x 3/4” x 1”) and one horizontal (25” x 3/4” x 1”). 2. -
Page 11: Mode Control
Power Control The Power Control turns the unit on and off. Temperature/ Timer Display Set Temperature/Timer Display The Set Temperature/Timer Display shows the set temperature when the unit Temperature/ is in operation and hours when the timer is being set. Timer Hour THE TEMPERATURE DISPLAY ONLY SHOWS THE SET TEMPERATURE, NOT THE Controls... -
Page 12: Directing Airflow
Directing Airflow Adjustable louver (Unit with adjustable louvers) The unit includes adjustable louvers to direct discharge airflow. Louvers are manually adjusted by moving the levers in the direction of desired airflow. (Fig. 13) Air Conditioner Remote Control The functions on the remote control work the same as your air conditioner’s touch controls. -
Page 13: Cleaning The Air Filter
Cleaning the air filter Air filter EVERY TWO WEEKS: Clean the filter. 1. Turn Power OFF. 2. Remove the air filter by grasping the top corners and pulling it up and out of the unit. (Fig. 15) 3. Wash in hot soapy water, rinse and shake dry. 4. -
Page 14: How To Obtain Warranty Service Or Parts
How to Obtain Warranty Service or Parts Note: Before calling for service, carefully read this Installation and Operations manual. For Models Installed in North America : First make the recommended checks in the Troubleshooting guide. Then, if you still need assistance: 1.
