CLIMETTE CH1226FR
Owner's Manual
Shop genuine replacement parts for CLIMETTE
CH1226FR
Find Your CLIMETTE Air Conditioner Parts - Select From 63 Models
-------- Manual continues below --------

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CH1226FR and is the answer not in the manual?

Questions and answers

Summary of Contents for Climette CH1226FR

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. CLIMETTE CH1226FR Owner's Manual Shop genuine replacement parts for CLIMETTE CH1226FR Find Your CLIMETTE Air Conditioner Parts - Select From 63 Models -------- Manual continues below --------...
  • Page 2 Installation and Operating Instructions Room Air Conditioners for Double-Hung Windows & Thru the wall installation TABLE OF CONTENTS ENGLISH Important Safety Information ........1 Installation..............3 Operation ..............6 Maintenance ............7 Troubleshooting ............8 How to Obtain Warranty Service or Parts....9 Keep these instructions for future reference For additional questions please call 1-217-347-6459 Features and specifications subject to change without notice.
  • Page 3: Recognize Safety Symbols, Words And Labels

    DANGER RECOGNIZE SAFETY SYMBOLS, Do not store or use gasoline or other flammable vapors WORDS AND LABELS and liquids in the vicinity of this or any other appliance. The fumes can create a fire hazard or explosion. What You Need To Know About DANGER Safety Instructions Important Grounding Requirements...
  • Page 4: Power Cord With Arc Detection Device

    Power Cord with WARNING Arc Detection Device Use two or more people to move and install air The power cord supplied with this air conditioner is conditioner. Failure to do so can result in back or equipped with an Arc Detection Device designed to shut other injury.
  • Page 5: Window Installation

    Installation Window Requirements: This air conditioner is factory prepared for installation in standard double-hung windows with actual opening width of 26 7/8” to 41 5/8” and clear, vertical opening of 15 5/8” minimum from bottom of sash to sill. Unit can be installed in 23 7/8” wide window, if cabinet side seals are removed.
  • Page 6 Window Installation (cont.) Open window, by raising lower window sash, and mark the center of window sill. Carefully place cabinet in window and align center hole on the bottom bar with the center mark on the window sill. Close lower window sash until it touches behind the top bar.
  • Page 7 Installing Cabinet in Minimum Width Window 1. Remove filler panels on air conditioner cabinet. 2. Refer to steps 1 through 3 of Window Installation instructions. 3. Close window until it touches behind air conditioner top bar. 4. Fasten top bar to window frame using 5/8” washer head screw. 5.
  • Page 8 Electronic Control (Cooling Only) Power Control The Power Control turns the unit on and off. Set Temperature/ Timer Display Shows the set temperature when the unit is in operation and hours when the timer is being set. THE TEMPERATURE DISPLAY ONLY SHOWS THE SET TEMPERATURE, NOT THE ACTUAL ROOM TEMPERATURE.
  • Page 9: Air Conditioner Remote Control

    Air Conditioner Remote Control The functions work the same as your air conditioner’s touch controls. Batteries: Remove the cover on the back of the remote controller and insert the batteries with the (+) and (-) poles pointing in the proper direction. WARNING •...
  • Page 10: Troubleshooting Guide

    Troubleshooting Guide To save time and expense, check the following before calling an authorized service station. Occurrence Possible Cause Solutions Air conditioner will not operate • Wall plug disconnected. • Push plug firmly into wall outlet. • House fuse blown or circuit breaker tripped. •...
  • Page 11 How to Obtain Warranty Service Service for your Room Air Conditioner will be provided by CareCo through its network of Authorized Independent Servicers nationwide. Note: Before calling for service, carefully read the "Installation and Operating Instructions" booklet. Then if you need service: 1.
  • Page 12 Manual de instalación y funcionamiento Acondicionadores de aire ambientales para ventanas de guillotina y empotrados en la pared ESPAÑOL Instrucciones importantes de seguridad....1 Instalación..............3 Funcionamiento ............6 Mantenimiento ............8 Localización y Solución de Averías ......9 Cómo obtener servicio o piezas bajo la garantía ..10 Ñ...
  • Page 13 PELIGRO Reconozca los símbolos, No guarde ni use gasolina u otros vapores y líquidos advertencias y etiquetas de inflamables en la vecindad de este o cualquier otro artefacto. Los vapores emitidos pueden crear un riesgo seguridad de incendio o explosión. Información sobre las Instrucciones de PELIGRO Seguridad...
  • Page 14 Cordón con dispositivo de detección de arco ADVERTENCIA eléctrico Emplee a dos o mas personas para mover e instalar el El cordón eléctrico proporcionado con este acondicionador acondicionador de aire. de aire viene equipado con un dispositivo de detección de arco eléctrico diseñado para apagar el suministro eléctrico a la unidad cuando detecta una condición de falla por arco eléctrico.
  • Page 15 Dimensiones de la Ventana Este acondicionador de aire ha sido preparado en la fábrica para su instalación en ventanas de guillotina estándares con aberturas de 26,875” a 41,625” de ancho y una abertura vertical de por lo menos 15,625” mínimo desde la parte inferior de la hoja móvil hasta el umbral.
  • Page 16 Instalacion en la Ventana Abra la ventana y marque el centro del umbral de la ventana. Coloque cuidadosamente el gabinete en la ventana y alinee el agujero central de la barra inferior con la marca central trazada en el umbral de la ventana.
  • Page 17 Instalación del Gabinete en una Ventana de Ancho Mínimo 1.No instale los paneles de relleno en el gabinete. Consulte las instrucciones anteriores desde el paso 1 al 3. Cierre la ventana hasta que toque detrás de la barra superior del acondicionador de aire.
  • Page 18 Panel de Control Electrónico Control Electrónico (Enfriamiento Solamente) Control de Alimentación Este botón pone en marcha y apaga el acondicionador de aire. Indicador de Temperatura de Ajuste/Temporizador El indicador muestra la temperatura de ajuste cuando el acondicionador de aire está en funcionamiento y las horas cuando se ha activado el temporizador. EL INDICADOR DE LA TEMPERATURA SOLAMENTE MUESTRA LA TEMPERATURA DE AJUSTE, NO LA TEMPERATURA AMBIENTE REAL.
  • Page 19: Control Del Temporizador

    Control del Temporizador (El temporizador puede ser Control Electrónico (Enfriamiento Solamente) ajustado ya sea para encender o apagar el acondicionador de aire.) Para PONER MARCHA automáticamente acondicionador de aire usando el modo ‘Timer’: 1. Oprima el botón ‘Timer’ cuando la alimentación eléctrica esté...
  • Page 20: Limpieza Del Filtro Del Aire

    Control Remoto de Acondicionador de Aire Las funciones trabajan igual que los controles manuales de su acondicionador de aire. Pilas: Retire al tapa en la parte trasera del control remoto e inserte las baterías con los polos (+) y (-) en la dirección correcta. PRECAUCION •...
  • Page 21 Localización y Solución de Averías Para ahorrar tiempo y dinero, verifique lo siguiente antes de llamar a un centro de servicio autorizado. Problema Causa Posible Soluciones El acondicionador de aire no • El enchufe mural está desconectado. • Inserte bien el enchufe en el tomacorriente funciona mural.
