Summary of Contents for SCHUBERTH SC EDGE

  • Page 2: Table Of Contents

    CONTENTS 1. INTRODUCTION ......................... 3 2. GETTING STARTED ......................4 2.1 GETTING TO KNOW YOUR SC EDGE ................4 2.2 CHARGING YOUR SC EDGE ..................4 2.3 SWITCHING YOUR UNIT ON/OFF ................... 5 2.4 USING YOUR SC EDGE ....................6 2.5 PAIRING YOUR UNIT TO BLUETOOTH DEVICES ..............

  • Page 3: Introduction

    If you have not yet installed the SC EDGE unit on your helmet, please install it as described in the Quick Start Guide provided in the package. You can also watch the installation video accessible on this link.

  • Page 4: Getting Started

    2.1 GETTING TO KNOW YOUR SC EDGE 2.2 CHARGING YOUR SC EDGE Make sure that your SC EDGE battery is charged for at least 4 hours before initial use. To charge the unit: 1. Using the supplied USB cable, connect your computer or wall charger (Input: 100-240 V, 50/60 Hz, 0.2 A maximum Output: 5 V DC, 1 A maximum) to the USB port on your SC EDGE.

  • Page 5: Switching Your Unit On/Off

    Remote Control also compatible with 2016 battery The LED confirms your SC EDGE is on: Turn on— LED flashes blue once, then green ● Turn off – LED flashes red ● To switch your SC EDGE off tap once on the power button...

  • Page 6: Using Your Sc Edge

    ● 2.5 PAIRING YOUR UNIT TO BLUETOOTH DEVICES Your SC EDGE has two Bluetooth channels for connection to Bluetooth devices such as mobile phones, GPS devices, and Bike Infotainment. To connect your unit to a Bluetooth device, you must first pair them. Once paired, they automatically recognize each other whenever they are within range.
  • Page 7 3. On your mobile phone, search for Bluetooth devices. 4. When your SC EDGE appears in the list of available devices, select it. If prompted for a PIN or Passkey, enter 0000 (four zeros). If prompted to allow pairing on your phone, allow it.
  • Page 8 4. On the device you are pairing, search for Bluetooth devices. 5. When your SC EDGE appears in the list of available devices, select it. If prompted for a PIN or Passkey, enter 0000 (four zeros). If prompted to allow pairing on your phone, allow it.

  • Page 9: Cardo Connect App

    3. CARDO CONNECT APP The Cardo Connect App enables you to configure the settings of your SC EDGE. In addition, the App offers you remote controlled operation from the screen of your smartphone. 3.1 REGISTERING YOUR UNIT 1. Download the Cardo Connect App.

  • Page 10: Updating Your Unit

    Updating with the latest software keeps your unit free of bugs and provides you with additional new functionalities. Your SC EDGE can be updated Over the Air, via Cardo Connect App, or via computer using the Cardo Update tool.

  • Page 11: On The Road

    Cardo Update on Windows/Mac - minimum requirements - Windows® 7/macOS x10.8. 4. ON THE ROAD SC EDGE makes it easy for you to receive phone calls and listen to music in a convenient and safe manner. 4.1 BASIC AUDIO FUNCTIONS The basic audio functions are the same whether you are listening to music, speaking on the intercom, or having a phone conversation.

  • Page 12: Making And Receiving Phone Calls

    4.2 MAKING AND RECEIVING PHONE CALLS You can use your mobile phone to make and receive phone calls while paired to your SC EDGE. You can make a hands-free call using your mobile phone's voice dial option or using the Cardo speed dial or redial last call options.

  • Page 13: Streaming Music

    Tap the intercom or the media button once or say "Hey Cardo, End Call". ● 4.3 STREAMING MUSIC You can stream music from your paired device to your SC EDGE. To start music streaming from your paired device, first make sure your music app is active in the background. Then: Tap the media button once or say “Hey Cardo, music on”.
  • Page 14 To stop music streaming: Press the media button for 2 seconds or say, "Hey Cardo, music off". ● To skip to the next track (while streaming): Tap the media button once or say, "Hey Cardo, next track". ● To skip back to the previous track (while streaming): Tap the media button twice or say “Hey Cardo, previous track”.

  • Page 15: Listening To Fm Radio

    4.4 LISTENING TO FM RADIO The SC EDGE is equipped with a built-in FM radio. You can store up to 6 preset stations. To turn on the FM radio: Tap media button twice or say, "Hey Cardo, radio on". The unit announces the frequency ●...
  • Page 16 To Auto-Tune 6 presets: 1. Press the Media and “+” buttons for 2 seconds The system will scan and save the first 6 FM available stations To store a scanned station in the active preset: Use the Cardo Connect App on your mobile device. ●...

  • Page 17: Voice Commands

    You can use voice commands for hands-free operation of certain SC EDGE features. Voice commands use natural voice operation. You say a command and SC EDGE performs the action. Voice commands are available in various languages. English is the default language. You can change the language to another available language via the Cardo Connect App.

  • Page 18: Riding With Others

    Intercom on page 23. If the SC EDGE communication system is installed on full carbon helmets, the maximum communication range is limited to 400 meters in open terrain without obstacles, due to the electromagnetic interference shielding properties of the carbon fiber.

  • Page 19: Using Dmc Intercom

    You can use the DMC bridging feature to add a non-DMC participant to the intercom group. To bridge a non-DMC participant: To add a Bluetooth participant, use the Cardo Connect App: The participant needs to start Bluetooth intercom pairing. Adding non-DMC participant using your SC EDGE:...
  • Page 20 Press the Intercom button for 5 seconds Start Bluetooth intercom pairing on the non-DMC participant unit, followed by a voice announcement “Rider A/B pairing”. After pairing is successful, switch your SC EDGE back to DMC mode • Press the Media and Intercom buttons for 5 seconds...
  • Page 21 To start a private chat: 1. In Cardo Connect App, select the rider you want to speak to in private 2. Once selected in the App, private chat starts automatically. 3. To end/start the private chat using the unit’s buttons, tap the Intercom button twice. The unit will confirm with a voice announcement “Private Chat on/off”.

  • Page 22: Bluetooth Intercom

    The SC EDGE can use parallel audio streaming to stream audio from two connected sources simultaneously, so that you can listen to your music or the FM radio while in an active DMC Intercom conversation. SC EDGE automatically manages your music and FM radio volume while using DMC Intercom. SC EDGE also automatically manages DMC Intercom volume with mobile phone calls and GPS.
  • Page 23 • Pairing a channel replaces any existing paired unit on that channel with the new unit. • The Intercom range with other models is limited to the distance of the unit with the shorter range. 5.4.1 SETTING UP NON-DMC INTERCOM DMC is always the best way to connect a group of riders.
  • Page 24 Bluetooth intercom pairing needs to be initiated on the other device. 3. To add a 3rd rider: Using your unit: 1. Start Bluetooth intercom pairing by pressing the intercom button for 5 seconds 2. Tap once on the intercom button, followed by a voice announcement “Rider B pairing”. Bluetooth intercom pairing needs to be initiated on the other device.
  • Page 25 To set up a non-DMC intercom – NON Cardo: 1. Start Bluetooth intercom pairing on the SC-EDGE unit, followed by a voice announcement “Rider A/B pairing”. 2. Start Universal intercom pairing on the Non-Cardo unit and wait for them to pair. * If not succeeded, Start mobile phone pairing on Non-Cardo unit instead of the universal pairing 5.4.2 USING THE BLUETOOTH INTERCOM 5.4.2.1 STARTING/ENDING BLUETOOTH INTERCOM...

  • Page 26: Sharing Music

    5.5 SHARING MUSIC You can share music with a participant. • Music can be shared with only one participant. • Bluetooth intercom calls are disabled when sharing music. • If you paired your unit to two mobile phones, music will be shared from the mobile phone through which you last played music.

  • Page 27: Switching Between Intercom Modes

    3.To start/stop sharing, press the intercom button for 2 seconds. 5.6 SWITCHING BETWEEN INTERCOM MODES Your SC EDGE unit can work in only one intercom mode at a time. The current intercom mode is indicated by the color of the LED on the main unit: When in DMC intercom mode, the LED flashes green at approximately 4-second intervals.

  • Page 28: Troubleshooting

    6. TROUBLESHOOTING 6.1 REBOOT If your SC EDGE stops responding, reset it in one of these ways: Turning it off and then on again (see Switching Your Unit On/Off). ● To Reboot the unit, gently insert a paperclip into the hole and tap the Pinhole Fault Reset Button with ●...

  • Page 29: Personalizing Your Device

    7. PERSONALIZING YOUR DEVICE Get the most out of your SC EDGE by changing the settings and customizing your unit according to your own personal preferences, using the Cardo Connect App on iOS or Android devices. 7.1 USING PARALLEL AUDIO STREAMING With parallel audio streaming, you can hear GPS instructions during a mobile or Bluetooth intercom call, or while listening to other audio sources, such as music or FM radio.

  • Page 30: Support

    All rights reserved. CARDO and SCHUBERTH, the CARDO and SCHUBERTH logo and other CARDO and SCHUBERTH marks are owned by CARDO and SCHUBERTH and may be registered. All other trademarks are the property of their respective owners. Cardo Systems and SCHUBERTH assumes no responsibility for any errors...
