Omega Lift Equipment 33220A Operating Instructions & Parts Manual

Spider jack stands
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Operating Instructions & Parts Manual
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
INCORRECT USE MAY RESULT IN INJURY OR
USE ONLY IN PAIRS AND ON FLAT HARD LEVEL
SURFACES (eg: CONCRETE), ENSURING THE
STAND IS POSITIONED UNDER A SOLID PORTION
OF THE VEHICLE AND THAT THE LOCKING
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
Imported by:
SHINN FU AUSTRALIA PTY. LTD.
15 Viewtech Place, Rowville 3178 VIC Australia
Spider Jack Stands
PRODUCT No.
33220A
33300A
33220A
WARNING
DEATH!
MECHANISM IS FULLY ENGAGED
Working Load Limit
19,954 KG
27,210 KG
33300A
WARNING
!
load supported only by a
hydraulic jack. ALWAYS use
adequately rated jack stands.
PRINTED IN CHINA
33300A_33220A-M0_052021
To avoid crushing
and related injuries:
NEVER work on,
under or around a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 33220A and is the answer not in the manual?

Questions and answers

Related Manuals for Omega Lift Equipment 33220A

Summary of Contents for Omega Lift Equipment 33220A

  • Page 1 Operating Instructions & Parts Manual Spider Jack Stands PRODUCT No. Working Load Limit 33220A 19,954 KG 33300A 27,210 KG 33220A 33300A This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 2: Safety And General Information

    27,210 kg 86 x 86 mm 317 mm 520 mm 280 x 280 x 317 mm 48kg/Pair Saddle Handle Extension Tube Extension Tube Support Bar Height Collar Adjustment Hole Lanyard Support Bar Holder Base Figure 1 - Models 33220A Components...

  • Page 3: Before Use

    PREPARATION Assembly (ref. Figs. 1) 1. Make sure all parts are present. If any part is missing or damaged, do not attempt to assemble or operate the product. Contact Omega Customer service (03) 9755 8277. 2. Insert extension tube to the base. Before Use 1.

  • Page 4: Operation

    OPERATION WARNING: Support areas of vehicle specified by vehicle manufacturer. Use ONLY on vehicles whose support points are compatible with saddle of jack stand. Incompatibility may result in structural damage to vehicle and/or jack stand. 1. Adjust saddle height by pulling up the extension tube, then insert the tube support bar through the hole on extension tube.

  • Page 5: Replacement Parts

    REPLACEMENT PARTS Jack stands are sold as a matched pair. For product labels and owners manual, call or write: SHINN FU AUSTRALIA PTY. LTD. 15 Viewtech Place, Rowville 3178 VIC Australia. E-mail: sales@sfaa. com.au; Tel: (03) 9755 8277. Parts List for 22 Ton Spider Jack Stands Item # Part # Description...
  • Page 6 Parts List for 30 Ton Spider Jack Stands Item # Part # Description Extension Tube ST90300A-00002 Carry Handle Base Section ST90300A-20000 Pin Assem ST90220A-40000 Pin Assem Screw M6x35 ST90300A-K01 E-Ring ST90300A-K02 Spring Swivel Casters Front Handle Spring Lock ST90300A-30000 Behind Handle Assem Handle Sleeve...

  • Page 7: Warranty

    WARRANTY 1. This product is covered by an express warranty for 12 months from the date of purchase by the original purchaser. Subject to the conditions of this warranty Shinn Fu Australia Pty Ltd or its authorised repair agents will replace the product or perform necessary service on the product without charge for parts or labour if the product is found to be faulty within the warranty period.
  • Page 8 NOTES Imported by: SHINN FU AUSTRALIA PTY. LTD. 15 Viewtech Place, Rowville 3178 VIC Australia...
