TRAVIRA CAFE' TABLES
ASSEMBLY INSTRUCTIONS
COMPONENTS
Table Top Assembly
Quantity: 1
HARDWARE
Short Allen Head Bolt
A
Quantity: 9
Allen Wrench
F
Quantity: 1
NOTES
Table top, or base may vary from illustrations but the assembly is the same for all Travira Cafe' bar & bistro tables.
For long & medium bolts,170 inch pounds for the bolt torque is recommended for commercial installations.
15 Kingbrook Parkway, Suite 100 Simpsonville, KY 40067 p. 877.866.3331
Café Legs
Quantity: 4
Long Allen Head Bol
t
B
Quantity: 9
4
3
Base Ring
Aluminum Umbrella
Quantity: 1
Hole Protector Ring
Quantity: 1
Lock Washer
Flat Washer
D
C
Quantity: 16
Quantity: 16
5
Aluminum Umbrella Hole
Reducer - Optional
Quantity: 1
Bolt Cap
E
Quantity: 16
f. 502.719.8888 oxfordgarden.com
Ver. 06.30.20
Advertisement
Related Manuals for Oxford Garden TRAVIRA
Summary of Contents for Oxford Garden TRAVIRA
- Page 1 Quantity: 1 NOTES Table top, or base may vary from illustrations but the assembly is the same for all Travira Cafe’ bar & bistro tables. For long & medium bolts,170 inch pounds for the bolt torque is recommended for commercial installations.
- Page 2 INSTRUCTIONS STEP 1 STEP 1 (detail) Lay table top upside down on clean smooth surface. Using the allen wrench provided, loosely attach THREE legs to table top using the SHORT bolts , lock washers and flat washers provided as shown. STEP 2 STEP 2 (detail) Carefully insert base ring...
