TRAVIRA BACKLESS BENCH - 48"
ASSEMBLY INSTRUCTIONS
COMPONENTS
Right Leg Assembly
Quantity: 1
4
Support Rail
Quantity: 1
HARDWARE
A
Long Bolts
Quantity: 13
B
Allen Wrench
Quantity: 1
NOTES
8 of the 13 bolts are pre-assembled into protective slat. SEE STEP 1 You will remove these 8 bolts shown below off of
protective slats off both ends of the seat assembly using the allen wrench provided. Protective slats are to be removed
and discarded but can be recycled.
DO NOT DISCARD BOLTS; these will be the remaining 8 bolts of the 13 bolts total you will need to assemble this bench.
A
A
15 Kingbrook Parkway, Suite 100 Simpsonville, KY 40067 p. 877.866.3331
2
Left Leg Assembly
Quantity: 1
Protective Slat
3
Seat
Quantity: 1
f. 502.719.8888 oxfordgarden.com
Ver. 06.30.20
Advertisement
Table of Contents
Related Manuals for Oxford Garden TRAVIRA
Summary of Contents for Oxford Garden TRAVIRA
- Page 1 Ver. 06.30.20 TRAVIRA BACKLESS BENCH - 48” ASSEMBLY INSTRUCTIONS COMPONENTS Right Leg Assembly Left Leg Assembly Seat Quantity: 1 Quantity: 1 Quantity: 1 Support Rail Quantity: 1 HARDWARE Long Bolts Quantity: 13 Allen Wrench Quantity: 1 NOTES 8 of the 13 bolts are pre-assembled into protective slat. SEE STEP 1 You will remove these 8 bolts shown below off of protective slats off both ends of the seat assembly using the allen wrench provided.
- Page 2 INSTRUCTIONS STEP 1 STEP 2 Lay seat assembly on a clean flat surface. Using the Connect the right leg assembly to the seat using allen wrench provided, remove the protective slat. Do not the four bolts that were removed from the protective discard bolts , you will use them for the assembly of the slat in Step 1.
