ESSEX CURVED BENCH - 83"
ASSEMBLY INSTRUCTIONS
COMPONENTS
Right Arm Assembly
Quantity: 1
5
Seat
Quantity: 1 (Right Shown)
Quantity: 1 (Left)
HARDWARE
A
Dowels
Quantity: 36
FINISHING ITEMS
Medium Grit Sandpaper
NOTE: If the furniture is going to be placed on a concrete or tile patio, it should first be rinsed well
to remove the sawdust that may cause some staining.
NOTE: A hammer and a phillips head screwdriver (not provided) will be needed for the assembly of this bench.
15 Kingbrook Parkway, Suite 100 Simpsonville, KY 40067 p. 877.866.3331
Left Arm Assembly
Quantity: 1
Front Rail
6
Quantity: 1 (Right Shown)
Quantity: 1 (Left)
B
Phillip-Head Wood Screws
Quantity: 4
Center Brace Assembly
Quantity: 1
7
Right Corner Brace
Quantity: 2
C
Allen Head Screw
Quantity: 4
Back
Quantity: 1 (Right Shown)
Quantity: 1 (Left)
Left Corner Brace
8
Quantity: 2
D
E
Bolts
Quantity: 2
f. 502.719.8888 oxfordgarden.com
Ver. 06.30.20
Allen Wrench
Quantity: 1
