- Page 1 CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD TURBO JET SMOKE XO2 SF-XO2 PRO USER MANUAL TURBO JET SMOKE XO2 USER MANUAL SF-XO2 PRO...
-
Page 2: Table Of Contents
CONTENTS PRODUCT INTRODUCTION 1.1 PRODUCTION OVERVIEW 1.2 PRODUCT ACCESSORIES 1.3 SPARK FABRICA LIQUID OIL 1.4 ADVANTAGES SPECIFICATIONS 2.1 BOTTOM SCREWS INSTALLATION ON-SCREEN OPERATING INSTRUCTIONS 3.1 BACK PANEL INTRODUCTION 3.2 KEY AND LED LIGTHS INSTRUCTIONS 3.3 MENU SETTINGS 3.4 MANUAL CONTROL SETTING DMX PARAMENT LIST 4.1 2 CHANNEL MODE... - Page 3 Please read the manual carefully before installing and using this product. Failure to read or comply with this manual may result in injury to products and personnel, and Spark Fabrica shall not be responsible for this. This product is a professional machine, we do not assume any responsibility for accidents or losses caused by the use or maintenance of this product by personnel without professional training and permission.
-
Page 4: Product Introduction
This product is widely used in weddings, concerts, sports events, event meetings, etc. Stimulate your interest and light up your activities. 1.1 PRODUCTION OVERVIEW Lamp Hook Hook Oil Inlet Pipe Oil Tank Storage Box Angle positioning screw Oil Outlet Pipe TURBO JET SMOKE XO2 USER MANUAL |... -
Page 5: Product Accessories
SF-SH nano high concentration fast dispersing gas column oil It is recommended to use only the consumables provided by our company. Machine damage, personal injury and the company does not assume any responsibility for property damage. TURBO JET SMOKE XO2 USER MANUAL |... -
Page 6: Advantages A4
Next Level Smoke Effect – Paired with SF-S professional light gas column oil and SF-SH nano high-concen- ★ tration dispersing oil for thick, fast-dissipating smoke. Unleash the Power–Command the Stage. Dominate the Show. ★ TURBO JET SMOKE XO2 USER MANUAL |... -
Page 7: Specifications A5
Optional Remote DMX Cable √ 3m Hook Safety Ring Bottom Screws √ 120Ωfuse Optional √ Authentication ROHS √ 33kg 50kg G.W(1unit flight case) Machine Dimension 560mm*313mm*436mm 1unit flight case size 602mm*447mm*628mm SF-S\SF-SH Consumption TURBO JET SMOKE XO2 USER MANUAL |... -
Page 8: Bottom Screws Installation A6
CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 2.1 BOTTOM SCREWS INSTALLATION 2*M8NUT TURBO JET SMOKE XO2 USER MANUAL |... -
Page 9: On-Screen Operating Instructions A7
MANUAL STOP always on and the LCD screen Manual timing mode displays an error message. MANUAL Manual long spray HEAT Power and heat indicator. Always on STOP indicates heat in progress Manual stop TURBO JET SMOKE XO2 USER MANUAL |... -
Page 10: Menu Settings
8 : Yellow 9 : Sky blue 10 : color mixing cycle When using a DMX console for control, the settings on this interface will not NOTICE work, and the LED light display color is determined by the console. TURBO JET SMOKE XO2 USER MANUAL |... -
Page 11: Manual Control Setting A9
According to - or + key to modify the parameter. The parameter will flash after NOTICE modification. ENTER key to save the setting. NOTICE Press ENTER to return to the upper menu. TURBO JET SMOKE XO2 USER MANUAL |... -
Page 12: Dmx Parament List A10
LED blue , OFF(0-10), ON(11-255 ) gradually brighten Channel 7 (CH7) LED Color Mixing, OFF (0-10), Color Mixing (11-255) (11-30)White,(31-50)Red,(51-70)Green,(71-90)Blue,(91-110)Pink (111-130)Purple(131-150)Orange(151-170)Yellow(171-190)Sky Blue (191-255)Color mixing cycle Channel 8 (CH8) LED strobe, OFF ( 0-10), Fast Strobe (11-255) TURBO JET SMOKE XO2 USER MANUAL |... -
Page 13: Operating Precautions A11
Please make sure that the power supply voltage is consistent with the rated voltage of the NOTICE device and use it with a grounding socket. Unplug the power cord to turn off the machine. TURBO JET SMOKE XO2 USER MANUAL |... - Page 14 Do not exceed the maximum scale line when placed sideways to prevent the oil from overflowing. When the device is inverted, the upper cover of the oil barrel should be installed facing the sky. TURBO JET SMOKE XO2 USER MANUAL |...
-
Page 15: Operating The Machine
The inverted installation method is as shown in the figure below. The bottom plate of the oil can needs to be disassembled and installed on the other side with the oil can facing upwards. A safety rope needs to be used for hanging. hook TURBO JET SMOKE XO2 USER MANUAL |... -
Page 16: Connecting The Machine
Set the machine DMX address code according to the channel mode: exist In 8-channel mode, please The DMX address code is set to 1, 9, 17, 25 … … … . NOTICE Do not set the address code repeatedly. TURBO JET SMOKE XO2 USER MANUAL |... -
Page 17: Troubleshooting
Clean with a vacuum cleaner or soft brush, dry towel or other tools. It is recommended to heat the device at least once a month to keep it in optimal working condition. TURBO JET SMOKE XO2 USER MANUAL |... -
Page 18: Analysis Of Equipment Atomizer Blockage A15
It has nothing to do with the quality of the equipment. In order to better use the equipment, please use professional and high-quality smoke oil and maintain it in time, so that it can be used healthily and for a long time use. TURBO JET SMOKE XO2 USER MANUAL |... -
Page 19: Warranty Card
*Invoice and warranty card are necessary when applying for maintenance service from SPARK FABRICA. WARRANTY CARD Serial No： Product Name: Purchase Date: Tel: Address: Info.Feedback About The Problem： Actual Problem: Maintenance Detail: Service Engineer: Service Date: TURBO JET SMOKE XO2 USER MANUAL |... - Page 20 www.sparkfabrica.com marketing@sparkfabrica.com +86 138 7585 1139...
