- Page 1 SPARK RAIN PRO SF-01 USER MANUAL SPARK RAIN PRO USER MANUAL...
-
Page 2: Table Of Contents
4.1 WORKING CONDITION REQUIRED 4.2 SAFETY TIPS 5 MACHINE OPERATION 5.1 PREPARATION 5.1.1 INSTALL MACHINE 5.1.2 FILL IN SPARK FABRICA GRANULE 5.2 CONNECT MACHINE 5.3 INITIAL SETTING 5.3.1 SET CHANNEL MODE 5.3.2 SET DMX ADDRESS 5.4 SWIPE RFID TIME CARD 5.5 START TO SPARK... - Page 3 Please read the manual carefully before installing and using this product. Failure to read or comply with this manual may result in injury to products and personnel, and Spark Fabrica shall not be responsible for this. This product is a professional machine, we do not assume any responsibility for accidents or losses caused by the use or maintenance of this product by personnel without professional training and permission.
-
Page 4: Product Introduction
1.1 PRODUCT OVERVIEW QUICK RELEASE HOOK RING AIR OUTLET GRANULE FILLING PORT DMX/CAN OUT DMX/CAN IN POWER IN HANDLE POWER OUT FUSE POWER SWITCH INCREASE LCD SCREEN ENTER/MENU GO BACK DECREASE AIR INLET SPARK RAIN PRO USER MANUAL SF-01... -
Page 5: Product Accessories
A special metal powder has the characteristics of high content, little residue, belonging to a special consumables with no smoke, odor and other harmful gas when sparking. Only the consumables provided by Spark Fabrica are allowed to be used. Spark Fabrica shall not be liable for any damage to machines, personnel and property caused by the use of consumables not provided by the company. - Page 6 Bottom Mounting Screw Software Upgrade Box Optional 120ohms Terminal Resistance Optional Certification ROHS Net Weight Weight Gross Weight 10kg Machine Dimensions - L*W*H 215mm*213mm*257mm Dimensions Packing Dimensions - L*W*H 270mm*250mm*330mm Granule Granule Spark Fabrica Granule SPARK RAIN PRO USER MANUAL SF-01...
-
Page 7: Screen Operation Guide
FAULT Error message indication: when the device runs wrong, the indicator light will turn on and the LCD will display error message. HEAT Movement heating status indicator,long light that is heating. SPARK RAIN PRO USER MANUAL SF-01... -
Page 8: Menu Setting
Press ▲ key or ▼ key to modify parameters. The parameters will be flash after the modifica- NOTICE tion, and please press < 0K > key to save the change. NOTICE Press key will return to previous page. SPARK RAIN PRO USER MANUAL SF-01... -
Page 9: Status Icons
Second Channel Function 0~200 Pre-heat Off 11~39 Emergency Stop 56~200 Clear Material 240~255 Pre-heat On Function Third Channel 0~255 Density Adjustment (0 is Maximum Density) Function Safty Channel 0~200 Control Off 201~255 Control On SPARK RAIN PRO USER MANUAL SF-01... -
Page 10: Operation Notes
Keep people or flammable materials at least 10 feet (3 meters) away from the machine, and make sure that debris does not fall on flammable objects. Do not use the machine at temperature above 122 'F (50℃). SPARK RAIN PRO USER MANUAL SF-01... -
Page 11: Safety Tips
Do Not touch the sparks.During heating up and operation, do not touch the housing. Ensure nothing drop(s) into the nozzle of Spark Rain Pro unit. Do Not cover output nozzle port. The product is very hot during operation and it remains hot for a long time after operation has stopped. -
Page 12: Machine Operation
Keep people or flammable materials at least 10 feet (3 meters) away from the machine, and make sure that debris does not fall on flammable objects. *Specific installation notes please refer to “4 OPERATION NOTES”. SPARK RAIN PRO USER MANUAL SF-01... -
Page 13: Fill In Spark Fabrica Granule
Spark Fabrica Granule is the consumable specially designed for spark machine, to simulate cold fountain fire- works effect for stage. *Tear the vacuum package of granule, and fill in the Spark Fabrica Granule through the granule filling port on the top of the machine. - Page 14 Please calculate all products’ total current required according to the power supply and fuse parameters of the products. The standard length of the power connection line and the signal connection line is 3 meters, and a longer length can be reached by connecting in series. SPARK RAIN PRO USER MANUAL SF-01...
-
Page 15: Initial Setting
Each swipe of the card can be recharged for 12 minutes, and each machine can swipe up to 2 time cards for 24 minutes at most.The card can only be swiped again when the remaining time is less than 20 minutes. SPARK RAIN PRO USER MANUAL SF-01... -
Page 16: Start To Spark
If the customer breaks the card swiping function or cancels the card swiping function at the customer's request, no quality guarantee and after-sales service will be provided by Spark Fabrica. Spark Fabrica shall not be liable for any accidents and losses about this. START TO SPARK The machine can be controlled by Pyro Sim Controller console or DMX512 console. -
Page 17: Adjust Sparking Density
The remote controller can be used after coding when DMX signal is disconnected,or the function will be broken. Sparking stops automatically after 30 seconds,and clearing material stops after 5 seconds. The remote controller has 4 height levels. SPARK RAIN PRO USER MANUAL SF-01... -
Page 18: Clear Material
*Use a damp cloth to remove dust and debris from the surface of the machine. *Unused Spark Fabrica Granule should be stored in a cool, dry place, vacuum packed insealed foil bags, and prote- cted from moisture, heat, hot surface, open fire and other ignition sources. -
Page 19: Failure Handling
Use illegal or copy RFID card will lock the machine. If so ,seller Illegal Card of using illegal or copy will stop providing warranty and after sale service. To unlock Machine Locked RFID card. the machine,please contact seller. SPARK RAIN PRO USER MANUAL SF-01... - Page 20 www.sparkfabrica.com marketing@sparkfabrica.com +86 138 7585 1139...
