- Page 1 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD MOTO SPARK USER MANUAL MOTO SPARK USER MANUAL M3...
-
Page 2: Table Of Contents
5.6 Auto-switch between battery and AC ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 6 MACHINE OPERATION ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 6.1 PREPARATION ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 6.1.1 INSTALL MACHINE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 6.1.2 FILL IN SPARK FABRICA GRANULE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 6.2 CONNECT MACHINE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 6.3 INITIAL SETTING ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 6.3.1 SET CHANNEL MODE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 6.3.2 SET DMX ADDRESS ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪... - Page 3 If the information contained in the manual or the product speci cations are changed, Spark Fabrica will not inform you further and responsible for any errors or omissions.
-
Page 4: Product Introduction
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD PRODUCT INTRODUCTION This product belongs to special e ects equipment, only for professional use. This product belongs to the cold reworks simulation special e ects equipment, using CST technology, heating special metal powder, and sparking silver spark fountain which is safer than the traditional cold reworks.It has three controllable variables: height, density and duration. -
Page 5: Product Accessories
A special metal powder has the characteristics of high content, little residue, belonging to a special consumables with no smoke, odor and other harmful gas when sparking. Only the consumables provided by Spark Fabrica are allowed to be used. Spark Fabrica shall not be liable for any damage to machines, personnel and property caused by the use of consumables not provided by the company. -
Page 6: Technical Parameter
Power Adapter Accessory √ Safety Ring √ Certification √ ROHS √ Net Weight 10Kg Weight Gross Weight 11kg Machine Dimensions - L*W*H 250X240X280mm Dimensions Packing Dimensions - L*W*H 290X290X380mm Granule Granule Spark Fabrica granule MOTO SPARK USER MANUAL M3 |... -
Page 7: Screen Operation Guide
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD SCREEN OPERATION GUIDE 3.1 BACK PANEL INTRODUCTION LCD SCREEN READY When the equipment is ready, flashing light means that the heating ENTER temperature has not reached the set holding temperature, and long INCREASE light means that the temperature of the movement has reached the spray requirements. -
Page 8: Menu Setting
DMX Channel DMX Address RF Channel PT:30℃ DMX:1 ST:680℃ PW:24.7V ClrError Address Le Time:xx H xx S TotaTime:xx H xx M Set SafetyAddr BY SPARK FABRICA Machine Ready SOC:47% Set ClrErrorAddr SPARK FABRICA Battery Charge Setting Charge Batty Advanced RFID RFID... -
Page 9: Status Icons
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 3.3 STATUS ICONS When the icons are green means the machine is working normally, and yellow means NOTICE abnormal. Blower Motor Wireless Connection Hopper Motor Sha Motor Temp Over Heat Temp Sensor Unconnected Tip Over Lack Of Time Sub PCB Connected PCB Too Hot... -
Page 10: Working Condition Required
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 4.1 WORKING CONDITION REQUIRED Do not mount the product on a ammable surface (linoleum, carpet, wood, paper, carton, plastic, etc). Make sure there are no in ammable or combustible materials in the using environment. Ground water entering or covering the bottom of the machine will cause machine failure or electrical leakage risk. -
Page 11: Battery
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD The product is very hot during operation and it remains hot for a long time a er operation has stopped. Do not touch or put nger in the output nozzle. Make sure that children, unauthorized people and animals do not obtain access to the machine. -
Page 12: Auto-Switch Between Battery And Ac
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5.6 Auto-switch between battery and AC When you plug o the power cable, machine will automatically switch to battery mode. When you plug in the power cable, machine will automatically switch to AC mode. MACHINE OPERATION PERPARATION Install the machine on a rm and level ground, and the maximum tilt angle shall not exceed 15 degrees. -
Page 13: Fill In Spark Fabrica Granule
Spark Fabrica Granule is the consumable specially designed for spark machine, to simulate cold fountain re- works e ect for stage. *Tear the vacuum package of granule, and ll in the Spark Fabrica Granule through the granule lling port on the top of the machine. -
Page 14: Initial Setting
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD Do not use damaged power plug and power cable.One power plug is recommended to connect 4 units in series at most for this product. Please attach the con gured 120 ohm terminal resistor to the outlet of the last machine to enhance the anti-interference of the machine. -
Page 15: Set Channel Mode
If the customer breaks the card swiping function or cancels the card swiping function at the customer's request, no quality guarantee and a er-sales service will be provided by Spark Fabrica. Spark Fabrica shall not be liable for any accidents and losses about this. START TO SPARK The machine can be controlled by Pyro Sim Controller console or DMX512 console. -
Page 16: Adjust Sparking Height
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD When using the Pyro Sim Controller controller,the screen will display the real-time temperature of each machine. When the temperature value of the control board turns green, it means that the heating is completed and the machine enters the status of sparking. 6.5.3 ADJUST SPARKING HEIGHT Adjust sparking height through the rst channel, and the height adjustment values is DMX parameter values 11-255. -
Page 17: A15
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD MIDDLE HIGH STANDYBY CODE CLEAN HEAT ON HEAT OFF www.sparkfabrica.com 6.5.5 HOW TO SET THE REMOTE CHANNEL OF REMOTE CONTROLLER The remote controller provides 12 remote channel options. Turn on the power of remote controller, Hold button 8 for 5 seconds until the led light ash, then please choose the 1-12 button on the remote controller, hold the selected button for 8 seconds. -
Page 18: A16
*Use a damp cloth to remove dust and debris from the surface of the machine. *Unused Spark Fabrica Granule should be stored in a cool, dry place, vacuum packed insealed foil bags, and prote- cted from moisture, heat, hot surface, open re and other ignition sources. -
Page 19: Failure Handling
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 8 FAILURE HANDLING Error Code Description Solution Bat Voltage LOW Battery voltage Replace main board UN-normal 1.Restart machine to clear alerts,stop operating for 15 minutes until temperature return to normal. Blower motor protection/ Motor Protect 2.Check wire connection of motor E1 M1 disconnected... - Page 20 www.sparkfabrica.com marketing@sparkfabrica.com +86 138 7585 1139...
