- Page 1 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD SPARK TIDE SF-X5 USER MANUAL SPARK TIDE USER MANUAL SF-X5...
-
Page 2: Table Of Contents
▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 4.2 SAFETY TIPS ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5 MACHINE OPERATION ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5.1 PREPARATION ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5.1.1 INSTALL MACHINE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A10 5.1.2 FILL IN SPARK FABRICA GRANULE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5.2 CONNECT MACHINE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5.3 INITIAL SETTING ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5.3.1 SET CHANNEL MODE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A14 5.3.2 SET DMX ADDRESS ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪... - Page 3 Please read the manual carefully before installing and using this product. Failure to read or comply with this manual may result in injury to products and personnel, and Spark Fabrica shall not beresponsible for this. This product is a professional machine, we do not assume any responsibility for accidents or lossescaused by the use or maintenance of this product by personnel without professional training anopermission.
-
Page 4: Product Introduction
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 1 PRODUCT INTRODUCTION This product belongs to special effects equipment, only for professional use.This product belongs to the cold fireworks simulation special effects equipment, using CST technologyheating special metal powder, and sparking silver spark fountain which is safer than the traditional coldfireworks.lt has three controllable variables: height, density and duration.This product is widely used in weddings, concerts, sports events, event meetings and so on.Stimulate yourinterest and light up your activity. -
Page 5: Product Accessories
Only the consumables provided by Spark Fabrica are allowed to be used. Spark Fabri- ca shall not be liable for any damage to machines, personnel and property caused by the use of consumables not provided by the company. -
Page 6: Technical Parameter
Update Box Optional 120ohms Terminal Resistance Optional √ Certification ROHS √ Net Weight 14.6kg Weight Gross Weight 17kg Machine Dimensions - L*W*H 294mm*310mm*318mm Dimensions Packing Dimensions - L*W*H 360mm*380mm*410mm Granule Granule Spark Fabrica Granule SPARK TIDE USER MANUAL SF-X5 |... -
Page 7: Screen Operation Guide
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 3 SCREEN OPERATION GUIDE 3.1 BACK PANEL INTRODUCTION LCD SCREEN READY When the equipment is ready, flashing light means that the heating temperature has not reached the set holding temperature, and long light means that the temperature of the movement has reached the spray requirements. -
Page 8: Menu Setting
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD Set Temprature 3.2 MENU SETTING ST：560℃ Set DMX Address 1-512 Temprature DMX ChanneL Mode DMX Address DMX Channel Mode Density Safety Address Set Density Maximum / Moderate / Minimum Set Safety Address Auto Heat Tilt Sensor Working Mode Auto Heat... -
Page 9: Status Icons
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 3.3 STATUS ICONS When the icons are green means the machine is working normally, and yellow means NOTICE abnormal. Blower Motor Shutter On The Nozzle Shaft Motor Temp Over Heat Hopper Motor Tip Over Shutter Motor Rainy Mode Temp Sensor Unconnected... -
Page 10: Operation Notes
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 4 OPERATION NOTES The designed Ingress Protection Rate of this machine is IP55, the machine can be used in rainy weather which is under or similar to the testing condition of IP55. 4.1 WORKING CONDITION REQUIRED Do not mount the product on a flammable surface (linoleum，carpet, wood, paper, carton, plastic, etc). -
Page 11: Safety Tips
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 4.2 SAFETY TIPS Always connect the ground wire to avoid electric shock.The machine cannot be submerged in water while operating it. Ground water entering or covering the bottom of the machine will cause machine failure or electrical leakage risk. -
Page 12: Machine Operation
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5 MACHINE OPERATION 5.1 PERPARATION Install the machine on a firm and level ground, and the maximum tilt angle shall not exceed 15 degrees. = 0° ≤ 15° ≤ 15° 5.1.1 INSTALL MACHINE Install the product on truss by using the attached accessories. SPARK TIDE USER MANUAL SF-X5 |... -
Page 13: Fill In Spark Fabrica Granule
Spark Fabrica Granule is the consumable specially designed for spark machine, to simulate cold fountain fire-works effect for stage. Tear the vacuum package of granule, and fill in the Spark Fabrica Granule through the granule filling port on thetop of the machine. -
Page 14: Connect Machine
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5.2 CONNECT MACHINE Connect power and DMX signal line. *Connect the first machine's power plug. *Connect the other machines in series with the power cable *Connect the other machines in series with DMX connection cable. *Connect PYRO SIM CONTROLLER or DMX512 controller SPARK TIDE USER MANUAL SF-X5 |... -
Page 15: Initial Setting
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD Do not use damaged power plug and power cable.One power plug is recommended to connect 4 units in series at most for this product. Please attach the configured 120 ohm terminal resistor to the outlet of the last machine to enhance the anti-interference of the machine. -
Page 16: Set Channel Mode
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD *Turn on power *Check the machine status icon(refer to icon introductions of 3.3) When the icon shows yellow, it indicates that the machine is abnormal. Please use it after asking the professional to check and repair the machine. *The sparking temperature of the machine is the factory default temperature. -
Page 17: Swipe Rfid Time Card
If the customer breaks the card swiping function or cancels the card swiping function at the customer's request, no quality guarantee and after-sales service will be provided by Spark Fabrica. Spark Fabrica shall not be liable for any accidents and losses about this. START TO SPARK The machine can be controlled by Pyro Sim Controller console or DMX512 console. -
Page 18: Adjust Sparking Height
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5.5.3 ADJUST SPARKING HEIGHT Adjust sparking height through the first channel, and the height adjustment values is DMX parameter values 11-255. Do Not touch the sparks or put finger in the output nozzle. During heating up and operation, do not touch the housing. Keep a minimum distance of 10 ft (3 m) from the machine to the nearest human or flammable material. -
Page 19: Spark Through Remote Controller
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5.5.4 SPARK THROUGH REMOTE CONTROLLER Battery : 23VA 12V Please check the spark machine and remote controller before use. Step 1: Connect the power supply to the device, start the machine, and pull out the antenna in the remote controller. Step 2: Hold down the <... -
Page 20: Clear Material
● Use a damp cloth to remove dust and debris from the surface of the machine ● Unused Spark Fabrica Granule should be stored in a cool, dry place, vacuum packed insealed foil bags, and protected from moisture, heat, hot surface. open fire and other iganition sources... -
Page 21: Machine Maintenance
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD The product is very hot during operation and it remains hot for a long time after operation has stopped. Wear gloves to take out the hopper after cooling down machine. Don't touch the casing of the hopper to avoid scalding. -
Page 22: Failure Handling
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 7 FAILURE HANDLING ERROR CODE DESCRIPTION SOLUTION System Error System error: Storage fail. Replace main board. E0 Storage Fail 1. Restart machine to clear alerts,stop operating for 15 minutes until temperature return to normal. Motor Protect Blower motor protection 2. - Page 23 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD Error Code Description Solution Time Remain Insufficient time. Please scan new RFID card. Temp Over Heat Heating protection due to Stop operating machine until temperature return over-temperature. to normal.Alert will clear off automatically. 1.Inspect wire connection of heating board. Heat Fail Heating process fail.
- Page 24 www.sparkfabrica.com marketing@sparkfabrica.com +86 138 7585 1139...
