- Page 1 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD KUNGFUPAO SF-K1 USER MANUAL SF-K1 KUNGFUPAO USER MANUAL...
-
Page 2: Table Of Contents
CONTENTS DISCLAIMER ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A1 PREFACE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A1 1 PRODUCT INTRODUCTION ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A2 1.1 PRODUCT OVERVIEW ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A2 1.2 PRODUCT ACCESSORIES ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A3 ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A3 1.3 BUTANE GAS 2 TECHNICAL PARAMETER ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A4 3 SCREEN OPERATION GUIDE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A5 3.1 BACK PANEL INTRODUCTION ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A5 3.2 DMX PARAMETER LIST ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A6 4 SAFETY NOTICE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A6 5 MACHINE OPERATION... -
Page 3: Preface ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A1
If the information contained in the manual or the product speci cations are changed, Spark Fabrica will not inform you further and responsible for any errors or omissions. -
Page 4: Product Introduction
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD PRODUCT INTRODUCTION Kungfupao is a new spark device without gunpowder and reworks invented by Changsha Spark Technology Electronics Co.,Ltd. It is a new product which produce istant spark e ect. This product can be widely used in weddings, opening celebration, meeting, sports events, concert and so on. -
Page 5: Product Accessories
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 1.2 PRODUCT ACCESSORIES 1.6M Power Plug User Manual 3 Meters Power Pair Cable (optional) 3 Meters DMX Pair Cable NOTICE Open the package carefully and check to make sure the goods are in good condition. 1.3 BUTANE GAS Granule for this product is lique ed butagas, and the gas cylinder is universal portable butagas cylinder. -
Page 6: Technical Parameter
CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 2 TECHNICAL PARAMETER Brand SPARK FABRICA Identification Name Kungfupao/SF-K1 Input Voltage & Frequency 100-260V，50 / 60HZ Battery Quantity AC Power Battery Mode 18650 Lithium Battery Power Granule Composite Ti (medium) Powder Consumption (100% Output) -
Page 7: Screen Operation Guide
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 3 SCREEN OPERATION GUIDE 3.1 BACK PANEL INTRODUCTION : Error Indicator ： DMX Signal Indicator : Working Indicator MENU ENTER : Menu : Enter Decrease Increase DMX OUT : DMX Output POWER DMX IN : Power : DMX Input POWER OUT... -
Page 8: Dmx Parameter List
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 3.2 DMX PARAMETER LIST First Channel Function Fire off 10-255 Fire on Second Channel Function Close gas loading 10-255 Start gas loading 4 SAFETY NOTICE Do not mount the product on a ammable surface (linoleum，carpet, wood, paper, carton, plastic, etc). - Page 9 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD Always connect the ground wire to avoid electric shock.The machine cannot be submerged in water while operating it. Ground water entering or covering the bottom of the machine will cause machine failure or electrical leakage risk. Make sure the bottom of the machine is at a safe distance from the surface water in rainy weather to avoid surface the machine from the bottom.
-
Page 10: Machine Operation
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD The nozzle of this product has a strong air pressure, please do not place other items on the nozzle. It is necessary to remove the gas tank when the product is stored in outdoor with high temperature for a long time. -
Page 11: Adjust Angle
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5.2 ADJUST ANGLE * The angle of gun tube can be adjusted freely. There are 5 angles, and each angle is spaced 15 degrees apart. Please install safety shaft to the position required before adjustment and pull up lock pin to adjust the angle. -
Page 12: Install Butane Gas
If the tank can’t be installed successfully,please check buckle is in the right place. 5.5 FILL GRANULE Spark Fabrica Granule is the consumable specially designed for spark machine,to simulate cold fountain re works eect for stage. *Tear the vacuum package of granule,and fill the granule into the nozzle of Kungfupao. -
Page 13: Start To Operate
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD START TO OPERATE 6.1 TURN ON MACHINE’S POWER *Use AC power: After connecting power, switch power to ON. Then power light and digital tube light will be ON. *Use DC power: Digital tube light and power light will be ON after connecting DC power. -
Page 14: Failure Handling
Check the leakage and replace the pipe Gas leakage fault WARRANTY INSTRUCTIONS Sincere thanks for your choosing Kungfupao SF-K1, you will receive quality service from us. The product warranty period is 3 year. If there are any quality problems within 7 days a er shipping out from our factory, we can exchange a brand new same model machine for you. -
Page 15: Warranty Card
CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD NOTICE For product damage not included in warranty range, we can provide paid service. *Invoice and warranty card are necessary when applying for maintenance service from SPARK FABRICA. WARRANTY CARD WARRANTY CARD Serial No：... - Page 16 www.sparkfabrica.com marketing@sparkfabrica.com +86 138 7585 1139...
