2PEKA
I
NSTRUCTION
M
ANUAL
For Car's And Boat's
2 Channel Digital Proportional R/C System
1M23N06101

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2PEKA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FUTABA 2PEKA

  • Page 1 2PEKA NSTRUCTION ANUAL For Car's And Boat's 2 Channel Digital Proportional R/C System 1M23N06101...
  • Page 2 -No part of this manual may be reproduced in any form without prior permission. -The contents of this manual are subject to change without prior notice. -This manual has been carefully written. Please write to Futaba if you feel that any corrections or clarifications should be made.
  • Page 3: Table Of Contents

    Table of Contens 2PEKA Safety Precautions ..............2 Definition of Symbols ......................2 Running Preparations Safety Precautions ..............2 Running Safety Precautions ..................... 3 Storage and Disposal Safety Precautions ............... 4 Other Safety Precautions ....................5 Before Operation ............... 6 System Contents ........................ 6 Nomenclature / Handling ....................
  • Page 4: Safety Precautions

    Safety Precautions 2PEKA For your safety as well as that of others. Please read this manual thoroughly prior to instal- lation and operation of your digital proportional R/C system. Definition of Symbols The following defines the symbols used in this manual.
  • Page 5: Running Safety Precautions

    Running (Sailing) Safety Precautions Warning Conduct Tests Prior to operation always preform a range test. Even one abnormality in the R/C system may cause loss of control. [Range Test Procedure] Have a friend hold the model, or place on a stand where the wheels or prop can not come in contact with any object.
  • Page 6: Storage And Disposal Safety Precautions

    Prohibited Do not operate when you are tired, not feeling well or under the influence of alcohol or drugs. Your judgement is impaired and could result in a dangerous situation that may cause serious injury to yourself and others. Before you turn on the power switch on the transmitter, always check to see that the trigger is at the neutral position.
  • Page 7: Other Safety Precautions

    Always use only genuine Futaba receiver, servos, electronic speed controls along with other optional parts and components. Futaba will not be held responsible for damages caused by other than genuine Futaba parts and components. Use only genuine Futaba parts and components listed in the in- struction manual and catalog.
  • Page 8: Before Operation

    Before Operation 2PEKA System Contents After opening the container, check the contents for the following items. the contents will vary with the system purchased. System with System with System with 1 MC210CB and 1 MC310CB and 2 Servos 1 Servo...
  • Page 9: Nomenclature / Handling

    Nomenclature / Handling Transmitter T2PEKA Power Switch Antenna *When slid upward, the power is turned on. Servo Reversing Switch (P14) Throttle ATV (P14) Steering Wheel *Turn model to left or right. Battery Level Indicator Steering Trim (P13) F R E Q U E N C Y *Three LED display to indicate M O D U L AT I O N *Adjusts the steering in small increments...
  • Page 10 Battery Replacement Caution Battery cover Always be sure you reinsert the batteries in the correct polarity or- Open der. If the batteries are loaded incorrectly , the transmitter may be damaged. When the transmitter will not be used for any short or long period of time, always remove the batteries.
  • Page 11: Assembly / Adjustment

    2PEKA Assembly / Adjustment Receiver and Servo Connection As you connect the receiver, servo's and other components, do so in accordance with the "Assembly Precautions" listed on the next page. Connections when a E.S.C. MC210CB or MC310CB are used. Connects to Motor...
  • Page 12: Assembly Precautions

    Use only genuine Futaba crystal set's as specified in this instruction manual. The use of other than Futaba crystal set's will result in decrease of range as well as loss of control. There are separate crystal's for the Transmitter and Receiver, there are also crystal set's for AM, FM and Dual Conversion FM.
  • Page 13 Caution Disassembly Prohibited Do Not disassemble any part of this system that is not specified in the instruction manual. Futaba will not be responsible for any damage due to improper disassembly of any part of the radio control system.
  • Page 14: Digital Proportional Adjustment

    Digital Proportional Adjustment *When making these settings adjustments , do so with the motor disconnected or the engine not running. Servo Horn Installation Instructions. Connect the receiver, servos, and other components and then turn on the power switches to transmitter and re- ceiver.
  • Page 15: Description Of Functions

    Description of Functions 2PEKA Steering Trim Steering neutral adjustments can be made by moving the Steer- Steering Trim ing trim knob to the left or right. Racers Tip ST.TRIM When you install a servo always check to be sure the servo TH.TRIM...
  • Page 16: Servo Reverse

    Servo Reverse This function reverses the rotation direction of the Steering and Steering Throttle servos. N Side: Normal R Side: Reverse SERVO When the trim position deviates from the center, the de- REV SW Throttle viation will be on the opposite side when the servo is N Side: Normal reversed.
  • Page 17: Reference

    Reference 2PEKA *Specifications and ratings are subject to change without prior notice. Ratings T2PEKA S3003 Transmitter Servo (2 channels, FM transmitter) (standard servo) Transmitting frequency: Power requirement: 27, 29, 40, 41, 72 or 75 MHz 4.8V or 6V (common with receiver)
  • Page 18: Troubleshooting

    If your digital proportional R/C set does not operate, its range is short, it intermit- tently stops operating, or it operates erroneously, take the action shown in the table below. If this does not correct the trouble, please contact a Futaba dealer. Check point...
