- Page 1 IM-240DNS MODULAR CUBER IM-240XNS INSTRUCTION MANUAL (original instructions) FOR END USER No.15 Qingqiu Street,Suzhou Industrial Park,Suzhou,215126 China L1M140101 (011025)
-
Page 2: Table Of Contents
IMPORTANT SAFETY INFORMATION ............................1 I. INSTALLATION INSTRUCTIONS ..............................3 1. CONSTRUCTION ..................................3 2.ACCESSORIES....................................3 3. LOCATION ....................................3 4. ELECTRICAL CONNECTIONS ..............................4 5. WATER SUPPLY AND DRAIN CONNECTIONS ........................5 II. OPERATING INSTRUCTIONS ..............................5 1. START UP ....................................5 2. PREPARING THE ICEMAKER FOR LONG STORAGE ......................5 III. -
Page 3: Important Safety Information
This is a commercial icemaker, and should be destined only to be used for the purpose for which it has been expressly designed and attached to a suitable storage bin as specified by Hoshizaki. Any other use should be considered improper and therefore dangerous. The manufacturer will not be held liable or responsible for any damage caused by improper, incorrect and unreasonable use. - Page 4 * If the supply cord is damaged, it must be replaced by a replacement cord available from Hoshizaki Parts/Service Centres. * Do not touch the electrical parts or operate the switches with damp hands. * This appliance is not intended for use by persons (including children) with reduced physical,...
-
Page 5: Installation Instructions
Louver, Air Filter Power Cord (Air-cooled Model) Front Cover Top Kit IMD Bin Door Storage Bin Handle Adjustable Legs 2.ACCESSORIES IM-240DNS IM-240XNS INLET HOSE OUTLET HOSE BRACE HEX HEAD BOLT INLETHOSE OUTLET HOSE BRACE HEX HEAD BOLT HEX HEAD BOLT... -
Page 6: Electrical Connections
The correct replacement for the detachable fuse cover is identifiable from the manufacturer’s reference number stamped on the plug. Supply of replacement fuse covers can be obtained from Hoshizaki Parts/Service Centres. Fuses should be rated at 13A and approved to BS 1362. -
Page 7: Water Supply And Drain Connections
Supply or Water Fittings Regulations. * Icemaking water must be potable water. Where scaling can be caused by water quality: - Installation of an external filter or softener is recommended. Contact your local water treatment professional or Hoshizaki service agent. -
Page 8: Maintenance
[c] Storage Bin Interior Cleaning/Sanitisation (Weekly) 1) Open the storage bin door, and remove all ice. Note: Hoshizaki recommends various types of storage bin for the icemaker which vary in size and design. The following instructions are therefore for general guidance only. -
Page 9: Before Calling For Service
* The power is supplied to the unit. * The water is turned on. * The air filter is clean (air-cooled model). * The cooling water circuit has a proper flow (water-cooled model). For further assistance or advice, contact your local Hoshizaki service agent. -
Page 10: Disposal
4. WARRANTY Hoshizaki warrants to the original owner/user that all Hoshizaki branded products shall be free of defects in material and/or workmanship for the duration of the “warranty period”. The warranty shall be effective for two years from the date of installation. -
Page 11: Specifications
ENGLISH SPECIFICATIONS Model IM-240DNS IM-240XNS Type Air-cooled, cube ice Air-cooled, cube ice Power Supply 1 phase 220 - 240V 50Hz 1 phase 220 - 240V 50Hz Electric Consumption 1330W 1330W Ice Production per 24h 220kg (5mm) / 240kg (15mm) 220kg (5mm) / 240kg (15mm) (ambient temp 10°C, water temp 10°C)
