Hoshizaki IM-240DME Installation Manual
Modular cuber
Hide thumbs
Also See for IM-240DME:
- Service manual (102 pages) ,
- Installation manual (32 pages) ,
- Instruction manual (26 pages)
Table of Contents
Advertisement
Quick Links
MODULAR CUBER
MACHINE A GLAÇONS MODULAIRE
MODULARER WÜRFELEISBEREITER
IJSBLOKJESMACHINE MET LOSSE OPSLAGBUNKER
FABRICADOR MODULAR DE CUBITOS DE HIELO
CUBETTATRICE MODULARE
INSTALLATION MANUAL
NOTICE D'INSTALLATION
INSTALLATIONSANLEITUNG
INSTALLATIE VOORSCHRIFT
MANUAL DE INSTALACION
MANUALE PER L'INSTALLAZIONE
FOR QUALIFIED INSTALLER ONLY
RESERVE A L'INSTALLATEUR
FÜR DEN INSTALLATEUR
VOOR DE BEVOEGDE INSTALLATEUR
SOLAMENTE PARA INSTALADOR CUALIFICADO
SOLTANTO PER INSTALLATORI QUALIFICATI
IM-240DME
IM-240XME
IM-240DWME
IM-240XWME
92E1CG20D (040309)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hoshizaki IM-240DME
Summary of Contents for Hoshizaki IM-240DME
- Page 1 IM-240DME MODULAR CUBER IM-240XME MACHINE A GLAÇONS MODULAIRE IM-240DWME MODULARER WÜRFELEISBEREITER IM-240XWME IJSBLOKJESMACHINE MET LOSSE OPSLAGBUNKER FABRICADOR MODULAR DE CUBITOS DE HIELO CUBETTATRICE MODULARE INSTALLATION MANUAL NOTICE D’INSTALLATION INSTALLATIONSANLEITUNG INSTALLATIE VOORSCHRIFT MANUAL DE INSTALACION MANUALE PER L’INSTALLAZIONE FOR QUALIFIED INSTALLER ONLY RESERVE A L’INSTALLATEUR...
- Page 2 (Optional) clearance at the right side. Adjustable Legs Fig. 1 5. This appliance is not suitable for installation in an area where a water jet could be used and where dripping is not allowed. Note: This icemaker needs a Storage Bin. Hoshizaki recommends the following Ice Storage Bins: 6. Do not place anything on top of the icemaker or in front of B700SF ------------------ IM-240D/IM-480D the Louver. B800SF ------------------ IM-480D/IM-720D B900SF ------------------ IM-480D/IM-720D 7. This icemaker will not work at subfreezing temperatures. To...
- Page 3 ENGLISH 4) Place the icemaker on the top of the Storage Bin. Be careful not to 6) Before stacking, remove the clear plastic cover on the upper or damage the icemaker frame and the Bin Control Switch. See Fig. 5. middle unit wiring channel. Disconnect the Bin Control Switch leads (with three-way plug). Remove the screws and the Bin 5) Secure the icemaker to the Storage Bin at the rear, by using the Control Switch. When stacking two or three icemakers, the switch mounting brackets and bolts provided. See Fig. 5.
- Page 4 The correct replacement for the detachable fuse cover is identifiable from the manufacturer’s reference number stamped on the plug. 1) Attach the angled end of white flexible inlet hose (accessory) to the Supply of replacement fuse covers can be obtained from Hoshizaki G3/4 fitting on the left side of the icemaker as indicated, ensuring Parts/Service Centres. rubber sealing washer is correctly positioned. Hand tighten sufficiently to provide leak free joint (Fig.
- Page 5 Cooling Water Outlet Rc/2 Fig. 13 Inlet Hose Drain Outlet R3/4 [Water-Cooled Model] * Hoshizaki recommends that the water-cooled Condenser should be connected to a closed circuit recirculating type cooling system utilizing a tower, water chiller or similar (see Fig. 4 and 5). Water make up should be via a ball valve/break tank arrangement. Condenser Cooling Circuit * Whilst connecting a water-cooled Condenser to a mains water (potable) supply will not affect the performance of the machine, it will most certainly cause a high use/waste of a valuable resource and is not recommended.
- Page 6 ENGLISH Potable Water Icemaker Inlet G3/4 Cooling Water /2-3/4 Inlet Rc/2 Nipple Cooling Water Outlet Rc/2 Drain Outlet R3/4 Inlet Hose Outlet Hose Fig. 16 7. START-UP PROCEDURE ) Disconnect the power supply. 2) Open the water tap. 3) Connect the power supply and energise. 4) The following should occur in sequence: a) Compressor will start (Hot Gas Valve open). b) Water Pan will fully open. c) Water Solenoid will open. d) Water Pan will start to close (Hot Gas Valve closed). e) Water Pan fully closed - Pump Motor will start. f) Water Solenoid will close. IMPORTANT . Check the conditions and quality of the ice production. 2. Do not use ice produced in the trial run. It might be contaminated with foreign matter in the water circuit. Discard or flush down the drain.
