Item # 000 000
Model # FCS70357CS
USE AND CARE GUIDE
STATESVILLE SLING PADDED SWIVEL CHAIR 2-PK
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of these chairs. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STATESVILLE FCS70357CS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HAMPTON BAY STATESVILLE FCS70357CS

Summary of Contents for HAMPTON BAY STATESVILLE FCS70357CS

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of these chairs. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............3 Product Caution ..............2 Safety Warnings ..............2 Package Contents ..............4 Assembly ............... 5 Warranty ................

  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description M6x30 bolt...

  • Page 4: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Chair bucket Left arm Right arm Support bar Front connection bar Rear connection bar Swivel base...

  • Page 5: Assembly

    Assembly Connecting the support bar to the chair bucket Place the chair bucket (A) upside down on a soft surface. Attach the support bar (D) to the chair bucket (A) using M8x20 hex bolt (DD), M8 spring washers (EE) and M8 washers (FF), as shown below. NOTE : Loosely tighten all bolts using the wrench (HH).
  • Page 6 Assembly (continued) Connecting the left arm to the chair bucket and the connection bars Attach the left arm (B) to the chair bucket (A) using M6x30 bolts (AA) and M6 washers (CC). Attach the front connection bar (E) and rear connection bar (F) to the left arm (B) using M6x18 bolts (BB) and M6 washers (CC). NOTE : Loosely tighten all bolts using the hex wrench (GG).
  • Page 7 Assembly (continued) Connecting the right arm to the chair bucket and the connection bars Attach the right arm (C) to the chair bucket (A) using M6x30 bolts (AA) and M6 washers (CC). Attach the front connection bar (E) and rear connection bar (F) to the right arm (C) using M6x18 bolts (BB) and M6 washers (CC). NOTE : Loosely tighten all bolts using the hex wrench (GG).
  • Page 8 Assembly (continued) Tightening all bolts, connecting the support bar to the swivel base Once all bolts are in place, fully tighten all bolts including screws preassembled by factory. Insert the support bar (D) into the swivel base (G).

  • Page 9: Care And Cleaning

    Assembly (continued) Checking the chairs Ensure all connections are secure before use. Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. Do not clean with abrasive materials, bleach, or solvents.
  • Page 10 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
