Tools required: Phillips screwdriver
The most current version of these instructions can be found online at www.grahamfield.com.
WARNING: Important! Read and understand these instructions before installing or
using the Bath Seat Basket. If you do not understand any part of these warnings or
instructions, contact a healthcare professional for direction in the use of this product.
If the basket is not properly installed, personal injury and damage to the basket could
result.
WARNING: If components are damaged or missing, contact your GF distributor
immediately. DO NOT use substitute parts. Use only Lumex replacement parts.
WARNING: Notice for California Customers- California Proposition 65 WARNING: This
product contains a chemical known to the State of California to cause cancer and
reproductive or developmental harm.
WARNING: GF Health Products, Inc. assumes no responsibility for any damage or injury
caused by improper assembly, installation or use of this product.
INSTALLATION (REFER TO PICTURES)
Components
Components, shown above, are listed below.
COMPONENT
Basket
Basket mounting clamp
Washer
Short screw (to mount clamps above joints)
Long screw (to mount clamps below joints)
Nut
The basket is shown in these instructions mounted above the leg joint using short screws.
7921R-BSKT-1-INS-LAB-RevA17
7921R-BSKT-1 — BATH SEAT BASKET:
INSTALLATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS FOR FUTURE USE
PARA INSTRUCCIONES EN ESPAÑOL, CONSULTE LA PAGINA 5
short screws
nuts
washers
Basket Components
basket
clamps
long
screws
QUANTITY
1
2
4
4
4
4
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Graham Field LUMEX 7921R-BSKT-1
Summary of Contents for Graham Field LUMEX 7921R-BSKT-1
- Page 1 7921R-BSKT-1 — BATH SEAT BASKET: INSTALLATION INSTRUCTIONS SAVE THESE INSTRUCTIONS FOR FUTURE USE PARA INSTRUCCIONES EN ESPAÑOL, CONSULTE LA PAGINA 5 Tools required: Phillips screwdriver The most current version of these instructions can be found online at www.grahamfield.com. WARNING: Important! Read and understand these instructions before installing or using the Bath Seat Basket.
- Page 2 Mounting the Basket 1. Mount one clamp on each front leg clamp at the same height with hooks facing clamp joint hook joint inward and clamps facing rear as shown at right in Install Clamps. bath seat front legs 2. Install nuts in clamp recesses. 3.
- Page 3 The basket is shown installed on bath seat (above leg joints) at right. OPERATION WARNING: Before each use, ensure all basket-mounting hardware is securely attached and basket is firmly installed on clamp hooks. WARNING: The basket has a maximum weight capacity of 5 lb.
- Page 4 LIMITED WARRANTY SCOPE OF WARRANTY GF Health Products, Inc. (“GF”) warrants to the original purchaser only that it will replace or repair components, at GF’s sole discretion, that are defective in material or workmanship under normal use and service. All warranties are conditioned upon the proper use of the products strictly in accordance with good commercial practice and applicable GF instructions and manuals, including proper use and maintenance.
