Graham Field LUMEX Versaframe 6460A Assembly & Operation Instructions

Note: The most current version of these instructions can be found online at
WARNING: Important! Read and understand these instructions before installing or using
the Versaframe Toilet Safety Frame. If you do not understand any part of these warnings,
cautions or instructions, contact a healthcare professional for direction in the use of this
product. If the Versaframe is not properly assembled and installed, personal injury and
damage to the Versaframe could result.
WARNING: If components are damaged or missing, contact your dealer immediately. DO
NOT use substitute parts. Use only Lumex replacement parts. Non-Lumex replacement
parts could cause personal injury and damage to the Versaframe.
WARNING: This product has a weight limit of 250 lb.
WARNING: Users who have limited physical capabilities must be assisted or supervised
when using the Versaframe.
WARNING: GF Health Products, Inc. assumes no responsibility for any damage or injury
caused by improper assembly, installation or use of this product.

INSTALLATION

Unpacking

Remove Versaframe from carton and
protective packaging. Check for obvious
damage to the carton or its contents. If
damage is evident, do not use the prod-
uct; please notify the carrier and your
Graham-Field authorized distributor for
further instruction.
Installation
1. Remove existing toilet seat.
2. Place mounting bracket on flat surface
of bowl and align holes. Ensure that
the tube on the bracket is to the rear,
closest to the tank.
3. Replace toilet seat, inserting bolts
through mounting bracket holes and
into toilet seat mounting holes. Re-
place original nuts and tighten.
4. Depress push buttons and install arms
in mounting bracket as shown.
5. Adjust width of Versaframe arms by
engaging push buttons in desired
holes in mounting bracket tube.
WARNING: Ensure that mounting
bracket push buttons are locked in
place before use.
6460-INS-LAB-RevA09
6460A / 6460R / 6465A-1: ADJUSTABLE VERSAFRAME TOILET
SAFETY FRAME ASSEMBLY & OPERATION INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE USE
push
button
arm
mounting
bracket
lower leg
tip
www.grahamfield.com
Versaframe toilet
safety frame
1
