Summary of Contents for veise VE008

  • Page 1 Installation Manual Model No. VE008...
  • Page 2: Table Of Contents

    Content Parts List Step 5: Install Batteries Installation Guide How to Reset Step 1: Prepare the Door and Check Dimensions Step 2: Install the Latch and Strike Step 3: Install Exterior Assembly Step 4: Install Interior Assembly...
  • Page 3: Installation Overview

    Installation Overview Interior Assembly (F) NOTE: Latch (B) Batteries are not included. Exterior Assembly (A) Long Screws (G) Strike (C) Dust Cover (D) Latch & Strike (Optional) Mechanical Key Screws (E)
  • Page 4: Parts List

    Parts List If any parts are missing or damaged, please contact us at +1(855)400-3853. Exterior Latch x1 Strike x1 Assembly x1 Interior Dust Cover x1 Latch & Strike Assembly x1 (Optional) Screws x4 Long Screws x2 Mechanical Keys x2...
  • Page 5: Installation Guide

    Installation Guide Step 1: Prepare the Door and Check Dimensions 1-1/5" to 2-1/8" 2-3/8" or 2-3/4" (30mm to 55mm) (60 or 70mm) B a c k s e 1" 2-1/8" 25mm (54mm) Depth: 1" (25mm) The hole in the door is The backset is either 2-3/8"...
  • Page 6: Step 2: Install The Latch And Strike

    Installation Guide Step 2: Install the Latch and Strike Latch backset adjustment. Backset is the distance from the door edge If the backset of your door is to the center of the hole in the door. 2-3/4" (70mm), please adjust the latch as shown in below images.
  • Page 7 Installation Guide Step 2: Install the Latch and Strike Install the latch. Install the latch. Latch (B) Latch Screws (E) Opening outwards Opening inwards Chiseled...
  • Page 8 Installation Guide Step 2: Install the Latch and Strike Install strike on the door frame. Important: Make sure the hole in door frame is drilled a minimum of 1" (25mm) deep. Strike Screws (E) Opening outwards Dust Cover (D) Opening inwards (Optional) NOTE: The bevel of the latch shall be aligned to the bevel of the strike.
  • Page 9: Step 3: Install Exterior Assembly

    Installation Guide Step 3: Install Exterior Assembly Route the cable over the latch and insert the Torque Blade through the slot in the latch. Torque Blade (Vertical) Don’t put the Mechanical Key in the keyhole during the installation. NOTE: The “UP” label mark on the rosette facing up, and the keyhole facing down.
  • Page 10: Step 4: Install Interior Assembly

    Installation Guide Step 4: Install Interior Assembly Battery Cover Built-in screws Connect the two cables by attaching Loosen the screws on the Interior in Battery Cover two connectors with each other firmly and Assembly and remove the Battery completely. Cover. (Actual Size)
  • Page 11 Installation Guide Step 4: Install Interior Assembly Insert the Long Screws into the circular holes and The Torque Blade going through the square hole tighten them to secure the rosette. on the Interior Assembly. (Actual Size) NOTE: The “UP” mark on the rosette facing up. Long Screws (G) x2...
  • Page 12: Step 5: Install Batteries

    Installation Guide Step 5: Install Batteries Important: Please install the batteries correctly according to the positive and negative poles showing below. Thumb Turn Built-in screws Insert 4 AAA alkaline batteries and put on the Battery Cover (the Battery in Battery Cover Cover pillar should be inserted into the corresponding hole), secure the Battery Cover with two screws.
  • Page 13: How To Reset

    How to Reset Rotate the Thumb Turn from “ ” to “ ” on the ”. Repeat the step 5 times. left, then turn it to “ Rotate the Thumb Turn from “ ” to “ ” on the right, then turn it to “ ”.
