- Page 1 Pro Strength Leg Extension PL-PS-LE Installation Manual...
- Page 2 Table of Contents 01/ Safety instructions 02/ Installation steps diagram and checklist 03/ Product description 04/ Product specifications 05/ Maintenance guide...
- Page 3 01/ Safety Instructions Welcome to choose our product. It is a guarantee to your safety and convenience if you use our product properly. Please read the followings carefully before using our product: Please read all the instructions carefully before using our product. Follow the rules strictly, and keep this manual within the lifetime of this product.
- Page 4 02/ Installation chart & list 1） Step 1...
- Page 5 Model Name Spec Left frame component Weld assembly Seat supporting component Weld assembly Adjustment handrail component Weld assembly Back pad fixed component Weld assembly Middle connection through Weld assembly component Left spindle Component Right frame component Weld assembly Left movable arm component Weld assembly Leg extension adjustment Component...
- Page 6 Hex locknut Outer hex bolt M12*25 Outer hex bolt M12*75 Screw cap Φ12 Fixed plate Φ12 Flat gasket Φ42*34*M8 Mushroom head bolt cap Φ17*31 Compressed spring Φ40*30 Flat pipe close M12*30 Hex flat head bolt M12*70 Hex flat head bolt Φ140*231 Foam 355*60*5...
- Page 7 03/ Product description This equipment is for indoor use, in order to improve your cardio and muscles. It trains your chest muscles and others. You can choose the stack weight in order to get the weights or resistance you need. You can read the placards in order to use the equipment properly.
