- Page 1 Pro Strength Single Arm Row - Standing (PL-PS-SAR) Installation Manual V2018051...
- Page 2 Table of Contents 01/ Safety instructions 02/ Installation steps diagram and checklist 03/ Product description 04/ Product specifications 05/ Maintenance guide...
- Page 3 01/Safety Instructions Thank you for choosing our machine, proper use of the machine is important to keep you convenient and away from danger. Please read the instruction before operating the machine: 1. Please read all user manuals before operating the machine, and operate the machine according to the instructions.
- Page 4 02/Installation chart Step 1 Attach the Base component(A#) , Bottom connection through component(G#) and Top connection through component(F#) and Left frame component(B#) and Right frame component(E) together and secure them with 24pcs M12×85 hex bolt（14#）、24 pcs washer（A22#）、24cps washer Φ12（A23#），4pcs Long base plate（L），4pcs Barbell plate hanger rod component （M）...
- Page 5 Step 2 Attach the Handrail component(H#) and Bottom connection through component(G#) together and secure them with 2pcs allen bolt (2#) and 2pcs Shaft end washer (A5#) AND 2PCS Deep groove ball bearing(B2#).
- Page 6 Step 3 Attach the Left movable arm component(C#) to Left frame component (B#) , Attach right movable arm component (D#) to the right frame component(E#) together with the 4 pcs M12*25 allen bolt (2#) and 4 pcs Shaft end washer(A5#) and 2 pcs end cap (A16#).
- Page 7 Exploded Diagram List for this step Model Name Spec...
- Page 8 Base component Weld assembly Left frame component Weld assembly Left movable arm component Weld assembly Right movable arm component Weld assembly Right frame component Weld assembly Top connection through component Weld assembly Bottom connection through Weld assembly component Handrail spindle Component Handrail component Weld assembly...
- Page 9 03/ Product description This equipment is for indoor use, in order to improve your cardio and muscles. It trains your chest muscles and others. You can choose the stack weight in order to get the weights or resistance you need. You can read the placards in order to use the equipment properly.
